MO-9000A
1-110 MHz Low Power Oscillator
Features
• Any frequency between 1 MHz and 110 MHz accurate to 6 decimal places
• Low power consump on of 3.6 mA typical
• CMOS compa ble output
• Industry-standard packages: 2.0 x 1.6, 2.5 x 2.0, 3.2 x 2.5, 5.0 x 3.2, 7.0 x 5.0 mm
Applications
• Ideal for DSC, DVC, DVR, IP CAM, Tablets, e-Books,
SSD, GPON, EPON
• Ideal for high-speed serial protocols such as: USB,
SATA, SAS, Firewire, Ethernet, etc.
Performance Specifica ons
Parameter and Condi ons
Output Frequency Range
Frequency Stability
Symbol
f
F_stab
Min.
1
-20
-50
–1.5
-20
-40
1.62
2.25
2.52
2.7
2.97
–
–
–
–
–
45
–
–
90%
–
70%
–
–
2
–
–
–
–
–
Typ.
–
–
–
–
–
–
1.8
2.5
2.8
3.0
3.3
3.9
3.6
2.5
2.5
1
–
1.2
1.5
–
–
–
–
100
–
–
–
2
2
1.5
Max.
110
+20
+50
1.5
+70
+85
1.98
2.75
3.08
3.3
3.63
4.5
3.9
5
5
1.2
55
2
3
–
10%
–
30%
250
–
5
5
3
4
2
Unit
MHz
PPM
PPM
PPM
°C
°C
V
V
V
V
V
mA
mA
μA
μA
μA
%
ns
ns
Vdd
Vdd
Vdd
Vdd
kΩ
MΩ
ms
ms
ps
ps
ps
Condi on
Inclusive of Ini al tolerance at 25°C, and varia ons over opera ng
temperature, rated power supply voltage and load.
1st year at 25°C
Extended Commercial
Industrial
Other supply voltages between 2.5V and 3.3V can be supported.
Contact Vectron for addi onal informa on.
Aging
Opera ng Temperature Range
Supply Voltage
Ag
T_use
Vdd
Current Consump on
Standby Current
Idd
I_std
Duty Cycle
Rise/Fall Time
Output High Voltage
Output Low Voltage
Input High Voltage
Input Low Voltage
Input Pull-up Impedence
Startup Time
Resume Time
RMS Period Ji er
RMS Phase Ji er (random)
DC
Tr, Tf
VOH
VOL
VIH
VIL
Z_in
T_start
T_resume
T_ji
T_phj
No load condi on, f = 20 MHz, Vdd = 2.5V, 2.8V, 3.0V or 3.3V
No load condi on, f = 20 MHz, Vdd = 1.8V
ST = GND, Vdd = 3.0V or 3.3V, Output is Weakly Pulled Down
ST = GND, Vdd = 2.5V or 2.8V, Output is Weakly Pulled Down
ST = GND, Vdd = 1.8V, Output is Weakly Pulled Down
All Vdds
20% - 80% Vdd = 2.5V, 2.8V, 3.0V or 3.3V
20% - 80% Vdd =1.8V
IOH = -4 mA (Vdd = 3.0V or 3.3V) IOH = -3 mA (Vdd = 2.8V and Vdd =
2.5V) IOH = -2 mA (Vdd = 1.8V)
IOL = 4 mA (Vdd = 3.0V or 3.3V) IOL = 3 mA (Vdd = 2.8V and Vdd =
2.5V) IOL = 2 mA (Vdd = 1.8V)
Pin 1, OE or ST
Pin 1, OE or ST
Pin 1, OE logic high or logic low, or ST logic high
Pin 1, ST logic low
Measured from the me Vdd reaches its rated minimum value
Measured from the me ST pin crosses 50% threshold
f = 20 MHz, Vdd = 2.5V, 2.8V, 3.0V or 3.3V
f = 20 MHz, Vdd = 1.8V
Integra on bandwidth = 12 kHz to 20 MHz
Page 1 of 6
Vectron Interna onal • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • h p://www.vectron.com
Rev 1.2 Aug 2014
Pin Func onality
Pin Connec ons
Pin Symbol
1
OE/ ST
Output Enable
Standby
Func onality
H or Open*: specified frequency output L: output is high
impedance. Only output driver is disabled.
H or Open*: specified frequency output L: output is low (weak
pull down). Device goes to sleep mode. Supply current reduces
to I_std.
Electrical ground
Oscillator output
Power supply voltage
Top View
OE/ST
1
4
VDD
2
3
4
GND
OUT
VDD
Power
Output
Power
GND
2
3
OUT
* A pull-up resistor of <10 kΩ between OE/ ST pin and Vdd is recommended in high noise environment
Environmental
Environmental Compliance
Parameter
Mechanical Shock
Mechanical Vibra on
Temperature Cycle
Solderability
Moisture Sensi vity Level
Condi on/Test Method
MIL-STD-883F, Method 2002
MIL-STD-883F, Method 2007
JESD22, Method A104
MIL-STD-883F, Method 2003
MSL1 @ 260°C
Absolute Maximum Ra ngs
Maximum Ra ngs
Parameter
Storage Temperature
VDD
Electrosta c Discharge
Soldering Temperature (follow standard Pb free soldering guidelines)
Min.
-65
-0.5
–
–
Max.
150
4
2000
260
Unit
°C
V
V
°C
Thermal Data
Thermal Considera ons
Package
7050
5032
3225
2520
2016
θJA,
4 Layer Board (°C/W)
191
97
109
117
124
θJA,
2 Layer Board (°C/W)
263
199
212
222
227
θJC,
Bo om (°C/W)
30
24
27
26
26
Page 4 of 6
Vectron Interna onal • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • h p://www.vectron.com
Rev 1.2 Aug 2014
Ordering Informa on
MO - 9000A E - 7 F - E E - 25M0000000
Frequency
Product
MO: MEMS XO
Family
9000A: Low Power Clock
Temp Range
J: -20/70°C
E: -40/85°C
Package
2: 4 pin 7.0mm x 5.0mm
4: 4 pin 5.0mm x 3.2mm
6: 4 pin 3.2 x 2.5mm
7: 4 pin 2.5 x 2.0mm
9: 4 pin 2.0 x 1.6mm
Supply Voltage
E: +3.3 Vdc
F: +3.0 Vdc
G: +2.8 Vdc
H: +2.5 Vdc
Stability
E: ±20ppm J: +1.8 Vdc
F: ±25ppm
K: ±50ppm
Feature Pin
E: Enable/Disable
S: Standby
Notes:
1. Not all op ons and codes are available at all frequencies.
2. Unless otherwise stated all values are valid a er warm-up me and refer to typical condi ons for supply voltage, frequency
control voltage, load, temperature (25°C).
3. Subject to technical modifica on.
4. Contact factory for availability.
Page 5 of 6
Vectron Interna onal • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • h p://www.vectron.com
Rev 1.2 Aug 2014
