BNC TOOL CRIMP
Bulk Packed 75
Ω
BNC Plugs...
Trompeter offers Tool Crimp BNC’s bulk packed in conve-
nient vacuum-formed plastic trays. Bulk packaging is
perfect for OEM and high-volume, on-site installations.
Contact the factory or your local representative for infor-
mation on how to order bulk packaging of any Trompeter
product.
Bulk Packed
75Ω BNC plugs
Part Number
UPL220-XXX/T50
1
$159.50
2
$140.50
5
$135.00
-XXX = Cable Group
Contact our technical support personell at (818)865-6534 if
you are uncertain about your cable group selection.
The bulk package includes:
v
(50) Body Assemblies
v
v
v
Order bulk packaging using the following format...
Example:
UPL220-020 / T50
(51) Crimp Sleeves
(52) Center Contact Pins
Assembly Instructions
BNC part number
Vacuum Tray part number
(Not available for cable groups -016, -017)
Triax Patching....
Trompeter’s patching products are also designed to meet
the broadcast industry’s requirements for patching triax
camera cable with cost effective connections. This ap-
proach allows patching directly from the cameras through
patch panels for distribution to other locations. This is ideal
for cable management, from cameras directly to monitors,
recorders, or displays, allowing complete routing through
the system. Trompeter’s panel design accommodates coax
jacks as well as triax jacks allowing for multiple cable types
through the same panel.
1.135/1.716
.096/.130
.156 DIA MTG HOLE
1.268
.570
.812
.375
.438/.625 HEX
.500/.750 BODY DIA
.438/.688 WRENCH FLATS
.281
.380
DIA
.445
DIA
Triax Cable Plug
Part Number
1
PL75-7
13.27
PL75-33
13.27
(Call factory for other cables)
.562
10
10.95
10.95
25
9.49
9.49
100
8.13
8.13
Triax Patch Jack
Part Number
1
J72
$13.27
10
$10.95
25
$9.49
100
$8.13
