1.5 Watts
ISL Series
•
•
•
•
•
•
•
DC-DC
xppower.com
Single & Dual Regulated Outputs
4:1 Input Range
SMD Package
Industry Standard Pinout
1500 VDC Isolation
Short Circuit Protection
3 Year Warranty
Specification
Input
Input Voltage Range
Input Reverse Voltage
Protection
Input Surge
• 24 V (9-36 VDC)
48 V (18-72 VDC)
• None
• 24 V: 40 VDC for 100 ms
48 V: 80 VDC for 100 ms
24 VDC
Input
Voltage
Output
Voltage
3.3 V
5.0 V
9.0 V
12.0 V
15.0 V
±5.0 V
±12.0 V
±15.0 V
48 VDC
5.0 V
Output
Current
455 mA
300 mA
167 mA
125 mA
100 mA
±150 mA
±63 mA
±50 mA
300 mA
Efficiency
(typ)
72%
76%
78%
79%
80%
74%
78%
80%
76%
Model
Number
(5)
ISL2403A
ISL2405A
ISL2409A
ISL2412A
ISL2415A
ISL2405
ISL2412
ISL2415
ISL4805A
Output
Output Voltage
•
Minimum Load
•
Line Regulation
•
Load Regulation
•
Setpoint Accuracy
•
Ripple & Noise
•
Temperature Coefficient
•
Short Circuit Protection
•
See table
10%
(1)
±0.2% typical
±0.5% typical
±1%/±3% typical, positive/negative output
100 mV pk-pk 20 MHz bandwidth
0.03%/°C
Continuous, automatic recovery
Mechanical Details
0.94 (23.86)
0.31
(8.00)
0.29
(7.50)
Side View
0.51 (13.10)
0.12
(3.04)
0.10
(2.54)
A
A
0.713 (18.10)
0.54 (13.70)
General
Efficiency
Isolation Voltage
Isolation Resistance
Isolation Capacitance
Switching Frequency
MTBF
Recommended Solder
Profile
•
•
•
•
•
•
•
See table
1500 VDC
10
9
Ω
1000 pF typical
550 kHz typical at nominal input, full load
>1 MHrs to MIL-HDBK-217F at 25 ºC, GB
IPC/JEDEC J-STD-020D.1
Top View
1
0.60 (15.24)
78
0.05
(1.35)
Recommended footprint
Top view grid: 0.1 x 0.1 in (2.54 x 2.54 mm)
Pin
1
7
8
9
10
16
Single
-Vin
N.C.
N.C.
+Vo
0V
+Vin
Dual
-Vin
N.C.
0V
+Vo
-Vo
+Vin
16
10 9
Environmental
Operating Temperature
• -40 °C to +85 °C, derate from 100% load
at 70 °C to 0% load at 100 °C
Storage Temperature
• -55 °C to +125 °C
Case Temperature
• 100 °C max
Cooling
• Convection-cooled
Lead Temperature
• 240 ºC, 0.06 in (1.5 mm) from case, 10 s
Notes
1.
Operation at no load will not damage unit but it may not meet all specifications.
1
7 8
0.079
(2.00)
0.039
(1.00)
N.C. Not connected
Notes
1. All dimensions in inches (mm)
2. Tolerance: ±0.010 (±0.25)
3. Weight: 0.011 lbs (5.2 g)
4. Pin tolerance: ±0.004 (±0.10 mm)
5. For optional tape & reel option add
suffix -TR to the end of the p/n. Reel
quantity = 200
0.02
(0.50)
5 º max
16
10 9
0.01
(0.25)
30 Oct 17
