ITQ Series
6 Watts
• Single & Dual Outputs
• 4:1 Input Range
DC-DC Converter
xxx Series
• Operating Temperature -40 °C to +100 °C
• 1500 VDC Isolation
• Optional 3000 VDC Version
• Fully Regulated Output
• No Minimum Load Required
• Remote On/Off
• 3 Year Warranty
Dimensions:
ITQ:
0.86 x 0.36 x 0.44” (21.9 x 9.2 x 11.1 mm)
Models & Ratings
Input Voltage
Output Voltage
3.3 V
5V
9V
12 V
9-36 V
15 V
24 V
±5 V
±12 V
±15 V
3.3 V
5V
9V
12 V
18-75 V
15 V
24 V
±5 V
±12 V
±15 V
Output Current
1500 mA
1200 mA
666 mA
500 mA
400 mA
250 mA
±600 mA
±250 mA
±200 mA
1500 mA
1200 mA
666 mA
500 mA
400 mA
250 mA
±600 mA
±250 mA
±200 mA
Input Current
(1)
No Load
Full Load
6 mA
6 mA
6 mA
6 mA
6 mA
6 mA
6 mA
6 mA
6 mA
6 mA
6 mA
6 mA
6 mA
6 mA
6 mA
6 mA
6 mA
6 mA
261 mA
298 mA
290 mA
287 mA
287 mA
287 mA
298 mA
291 mA
287 mA
131 mA
151 mA
147 mA
144 mA
144 mA
144 mA
152 mA
147 mA
145 mA
Maximum
Capacitive Load
(2)
4700 µF
2200 µF
1000 µF
470 µF
220 µF
100 µF
±330 µF
±220 µF
±100 µF
4700 µF
2200 µF
1000 µF
470 µF
220 µF
100 µF
±330 µF
±220 µF
±100 µF
Efficiency
79%
84%
86%
87%
87%
87%
84%
86%
87%
79%
83%
85%
87%
87%
87%
82%
85%
86%
Model Number
(3)
ITQ2403SA
ITQ2405SA
ITQ2409SA
ITQ2412SA
ITQ2415SA
ITQ2424SA
ITQ2405S
ITQ2412S
ITQ2415S
ITQ4803SA
ITQ4805SA
ITQ4809SA
ITQ4812SA
ITQ4815SA
ITQ4824SA
ITQ4805S
ITQ4812S
ITQ4815S
Notes
1. Input currents measured at nominal input voltage.
2. Maximum capacitive load is per output.
3. For optional 3000VDC isolation add suffix '-H' to model number.
1
www.xppower.com
ITQ Series
Input
Characteristic
Input Voltage Range
Input Filter
Input Reflected Ripple
Input Surge
Minimum
9
18
Capacitor
20/40
50
100
Typical
Maximum
36
75
DC-DC Converter
Units
VDC
VDC
mA pk-pk
VDC for 100 ms
VDC for 100 ms
Notes & Conditions
24 V nominal
48 V nominal
24/48 V input. Through 12 µH inductor and 47 µF capacitor
24 V models
48 V models
Output
Characteristic
Output Voltage
Initial Set Accuracy
Minimum Load
Line Regulation
Load Regulation
Cross Regulation
Transient Response
Ripple & Noise
Short Circuit Protection
Maximum Capacitive Load
Temperature Coefficient
Remote On/Off
0.02
%/ ˚C
0
±0.2
±0.5
±1
±5
±5/±3
125
Minimum
3.3
Typical
Maximum
24
±1
Units
VDC
%
A
%
%
%
%
% deviation
mV pk-pk
Single output
Dual output
On dual output models when one load is varied between
25% and 100% and other is fixed at 100%
For 3V3 & 5V output models / all other models.
Recovery within 2% in less than 2ms for a 25% load change
20 MHz bandwidth. Measured using 0.1 µF ceramic capacitor
Continuous, with auto recovery
See Models and Ratings table
Output is on if Remote On/Off (pin 3) is open
Output turns off if 2-4 mA is applied to Remote On/Off (pin 3). Referenced to -Vin.
No minimum load required
Notes & Conditions
See Models and Ratings table
General
Characteristic
Efficiency
Isolation: Input to Output
Switching Frequency
Isolation Resistance
Isolation Capacitance
Power Density
Mean Time Between Failure
Weight
0.8
0.01 (4.8)
10
9
Minimum
1500
Typical
87
580
50
Maximum
Units
%
VDC
kHz
pF
Win
3
MHrs
lb (g)
Ω
Notes & Conditions
See Models and Ratings table
3000 VDC option. Add ‘-H’ to model number
44
MIL-HDBK-217F, +25 °C GB
Environmental
Characteristic
Operating Temperature
Storage Temperature
Case Temperature
Humidity
Cooling
Minimum
-40
-55
Typical
Maximum
+100
+125
+100
95
Units
°C
°C
°C
%RH
Non-condensing
Natural convection
Notes & Conditions
Derate from 100% load at +70 °C to no load at +100 °C
www.xppower.com
2
ITQ Series
EMC: Emissions
Phenomenon
Conducted
Radiated
Standard
EN55022
EN55022
Test Level
Class A
Class A
DC-DC Converter
Notes & Conditions
External components required. See suggested filter below.
EMC: Immunity
Phenomenon
ESD Immunity
Radiated Immunity
EFT/Burst
Surges
Conducted Immunity
Magnetic Fields
Standard
EN61000-4-2
EN61000-4-3
EN61000-4-4
EN61000-4-5
EN61000-4-6
EN61000-4-8
Test Level
3
20 Vrms
3
Installation class 2
3 V rms
1 A/m
Criteria
A
A
A
A
A
A
External input capacitor required 330 µF/100 V
External input capacitor required 330 µF/100 V
Notes & Conditions
Safety Approvals
Safety Agency
UL
CSA
Safety Standard
UL60950-1, UL62368-1
CAN/CSA C22.2 No.60950-1
Notes & Conditions
Application Notes
EMI Filter
C1 & C2
ITQ24
ITQ48
10 µF (35 V)
2.2 µF (100 V)
L
12 µH
12 µH
C3 & C4
470 pF (3 kV)
1000 pF (3 kV)
C5
n/a
1000 pF (3 kV)
Mechanical Details
0.86
(21.85)
0.36
(9.20)
Printed Face
0.42
(10.60)
0.02
(0.50)
0.44
(11.10)
0.12
(3.00)
1
2
3
5
6
7
8
0.10
(2.54)
0.70 (17.78)
Pin
1
2
3
5
6
7
8
Pin
1
2
3
5
6
7
8
Pin Connections
Single
Dual
-Vin
-Vin
+Vin
+Vin
Remote On/Off
Remote On/Off
N/C
N/C
+Vout
+Vout
-Vout
Common
N/C
-Vout
Pin Connections
Single -H
Dual -H
-Vin
-Vin
+Vin
+Vin
Remote On/Off
Remote On/Off
No Pin
No Pin
+Vout
+Vout
-Vout
Common
N/C
-Vout
0.02
(0.50)
0.36
(9.20)
0.13
(3.20)
0.02
(0.50)
0.01
(0.25)
Notes
1. All dimensions are in inches (mm)
2. Weight: 0.01lbs (4.8 g) approx.
3. Pin diameter: 0.02±0.002 (0.5±0.05)
4. Pin pitch tolerance: ±0.014 (±0.35)
5. Case tolerance: ±0.02 (±0.5)
3
www.xppower.com
