ITV Series
1 Watts
• Single & Dual Output
• SIP Package
• Full Load at 95 °C Ambient
• 3000 VDC Isolation
• Class B Radiated Emissions
• MTBF >3.5 MHrs
• 3 Year Warranty
• 40 °C to +105 °C Operation
DC-DC Converter
xxx Series
Dimensions:
ITV:
0.76 x 0.24 x 0.39” (19.5 x 6.0 x 10.0 mm)
Models & Ratings
Input Voltage
Output Voltage
5V
12 V
5V
15 V
±5 V
±12 V
±15 V
5V
12 V
12 V
15 V
±5 V
±12 V
±15 V
5V
12 V
24 V
15 V
±5 V
±12 V
±15 V
Output Current
200 mA
83.3 mA
66.7 mA
±100 mA
±41.6 mA
±33.3 mA
200 mA
83.3 mA
66.7 mA
±100 mA
±41.6 mA
±33.3 mA
200 mA
83.3 mA
66.7 mA
±100 mA
±41.6 mA
±33.3 mA
Input Current
(1)
No Load
Full Load
30 mA
30 mA
30 mA
30 mA
30 mA
30 mA
15 mA
15 mA
15 mA
15 mA
15 mA
15 mA
7 mA
7 mA
7 mA
7 mA
7 mA
7 mA
253 mA
253 mA
253 mA
253 mA
250 mA
250 mA
106 mA
106 mA
104 mA
106 mA
106 mA
104 mA
53 mA
53 mA
53 mA
53 mA
53 mA
53 mA
Maximum
Capacitive Load
(2)
220 µF
100 µF
100 µF
±100 µF
±47 µF
±47 µF
220 µF
100 µF
100 µF
±100 µF
±47 µF
±47 µF
220 µF
100 µF
100 µF
±100 µF
±47 µF
±47 µF
Efficiency
(3)
80%
80%
80%
80%
81%
81%
80%
80%
81%
80%
80%
81%
80%
80%
80%
80%
80%
80%
Model Number
ITV0505SA
ITV0512SA
ITV0515SA
ITV0505S
ITV0512S
ITV0515S
ITV1205SA
ITV1212SA
ITV1215SA
ITV1205S
ITV1212S
ITV1215S
ITV2405SA
ITV2412SA
ITV2415SA
ITV2405S
ITV2412S
ITV2415S
Notes
1. Input currents measured at nominal input voltage.
2. Maximum capacitive load is per output.
3. Measured at nominal input voltage and full load.
1
www.xppower.com
ITV Series
Input
Characteristic
Input Voltage Range
Input Filter
Input Reflected Ripple
Input Surge
Minimum
4.5
10.8
21.6
Capacitor
15
9
18
30
Typical
Maximum
5.5
13.2
26.4
DC-DC Converter
Units
VDC
VDC
VDC
mA pk-pk
VDC for 1000 ms
VDC for 1000 ms
VDC for 1000 ms
Notes & Conditions
5 V nominal
12 V nominal
24 V nominal
Through 12 µH inductor and 47 µF capacitor
5 V models
12 V models
24 V models
Output
Characteristic
Output Voltage
Initial Set Accuracy
Minimum Load
Line Regulation
Load Regulation
Cross Regulation
Ripple & Noise
Short Circuit Protection
Maximum Capacitive Load
Temperature Coefficient
0.02
%/ ˚C
10
±1.2
+5, -2.5
±5
60
Minimum
5
Typical
Maximum
15
±5
Units
VDC
%
%
%/1%Vin
%
%
mV pk-pk
From 10% to full load from 70% load point
On dual output models when one load is varied between
25% and 100% and other is fixed at 100%
20 MHz bandwidth. Measured using 0.1 µF ceramic capacitor
Continuous, with auto recovery
See Models and Ratings table
Notes & Conditions
See Models and Ratings table
At 70% load
Minimum load required to meet specification. Operation at
no load will not cause damage.
General
Characteristic
Efficiency
Isolation: Input to Output
Switching Frequency
Isolation Resistance
Isolation Capacitance
Power Density
Mean Time Between Failure
Weight
3.6
0.0053 (2.4)
3000
40/50
10
9
Minimum
Typical
80
Maximum
Units
%
VDC
Notes & Conditions
See Models and Ratings table
5 V/12-24 V input
50/70
50
14
kHz
pF
Win
3
MHrs
lb (g)
Ω
MIL-HDBK-217F, +25 °C GB
Environmental
Characteristic
Operating Temperature
Storage Temperature
Case Temperature
Humidity
Cooling
Minimum
-40
-55
Typical
Maximum
+105
+125
+115
95
Units
°C
°C
°C
%RH
Non-condensing
Natural convection
Notes & Conditions
Derate from 100% load at +95 °C to 90% at +105 °C
www.xppower.com
2
ITV Series
EMC: Emissions
Phenomenon
Conducted
Radiated
Standard
EN55022
EN55022
Test Level
Class B
Class B
DC-DC Converter
Notes & Conditions
See Application Note
EMC: Immunity
Phenomenon
ESD Immunity
Radiated Immunity
EFT/Burst
Surges
Conducted Immunity
Magnetic Fields
Standard
EN61000-4-2
EN61000-4-3
EN61000-4-4
EN61000-4-5
EN61000-4-6
EN61000-4-8
Test Level
3
10 Vrms
3
1
3 V rms
1 A/m
Criteria
A
A
A
A
A
A
External input capacitor required 330 µF/100 V
External input capacitor required 330 µF/100 V
Notes & Conditions
Mechanical Details
0.76
(19.5)
0.24
(6.00)
Pin Connections
Pin
1
2
4
5
6
7
Notes
Single
+Vin
-Vin
No Pin
-Vout
No Pin
+Vout
Dual
+Vin
-Vin
No Pin
-Vout
Common
+Vout
Printed Face
0.37
(9.50)
0.02
(0.50)
0.39
(10.0)
0.12
(3.05)
0.10
(2.54)
0.60
(15.24)
0.02
(0.50)
0.24
(6.00)
0.05
(1.25)
0.02
(0.50)
0.01
(0.25)
1.
2.
3.
4.
5.
All dimensions are in inches (mm)
Weight: 0.0053lbs (2.4 g) approx.
Pin diameter: 0.02±0.002 (0.5±0.05)
Pin pitch tolerance: ±0.014 (±0.35)
Case tolerance: ±0.02 (±0.5)
Application Note
EMI Filter
+ Vout
6.8 µH
4.7 µF/50 V
+ Vin
ITV
Load
-Vin
-Vout
1206 Chip Capacitor, placed as close as possible to the input pins
3
www.xppower.com
08 Dec 14
