321497-000 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> The resistor> 321497-000

321497-000: DescriptionRESISTOR, TEMPERATURE DEPENDENT, PTC RESETTABLE FUSE, SURFACE MOUNT; CategoryPassive components The resistor; File Size95KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric View All

321497-000 Overview

RESISTOR, TEMPERATURE DEPENDENT, PTC RESETTABLE FUSE, SURFACE MOUNT

321497-000 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Objectid	1632502235
package instruction	,
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	RESISTANCE RANGE(MIN-MAX): 0.022-0.039
Manufacturer's serial number	VTP
Installation features	SURFACE MOUNT
Number of terminals	2
Maximum operating temperature	85 °C
Package shape	RECTANGULAR PACKAGE
method of packing	BULK
Rated (AC) voltage (URac)	16 V
Rated power dissipation(P)	1.5 W
Resistor type	PTC RESETTABLE FUSE
surface mount	YES
Terminal location	AXIAL
Terminal shape	FLAT
Thermistor Applications	TEMPERATURE SENSING

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

PolySwitch Resettable Devices

Product Feature Selector

> Product Details

VTP200U Product Details

PolySwitch Resettable Devices

Always ELV C om plia nt

(

Find R oHS C om plia nt Alte rna te s

Sta te m e nt of

C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

VTP200U

T E I nternal N umber: 3 2 1 4 9 7 - 0 0 0

Product Highlights:

Strap Battery Application

Family Name = VTP

Weldable Strap C onstruction

IH (Room Temperature) = 2 Amps.

IT (Room Temperature) = 4.70 Amps.

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Obsolete

C ontact Product Information C enter

Buy P roduc t

Documentation & Additional Information

Product Drawings:

VTP200U

(PDF, English)

Catalog Pages/Data Sheets:

None Available

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

UL Recognized = File No. E74889

C SA File No. = 78165C

Electrical Characteristics:

IH (Room Temperature) (Amps.)

= 2

IT (Room Temperature) (Amps.)

= 4.70

Vmax Operating (V)

= 16

Rmin (?)

= 0.022

Rmax (?)

= 0.039

R1 Max [Post Trip] (?)

= 0.078

Power Dissipation (Typical) (W) = 1.50

Termination Related Features:

C onstruction = Weldable Strap

Body Related Features:

Lead Type = Untaped

Contact Related Features:

Family Name

= VTP

Configuration Related Features:

C oating = Untaped

Industry Standards:

RoHS/ELV C ompliance

= ELV compliant

Lead Free Solder Processes

= Not relevant for lead free process

RoHS/ELV C ompliance History = Always was ELV compliant

Conditions for Usage:

Operating Temperature (Max.) (?C )

= 85

Operation/Application:

Application = Strap Battery

Packaging Related Features:

Packaging Method = Bulk

Other:

Brand = Raychem

Additional Information:

Product Line Information
