2.4 to 2.5 GHz 1 Watt Power Amplifier

Preview

Download Datasheet

View All

CMM2321

Preliminary Product Information

April 1997

(1 of 4)

2.4 to 2.5 GHz

1 Watt Power Amplifier

Functional Block Diagram

V g2

Vg1

RF OUT/Vd2

Vd1

N/C

Back plane is ground and

must be soldered to thermally

conductive ground plane.

Features

48% Power Added Efficiency

31.5 dBm Output Power

Low Distortion

Low Cost SO-8 Surface Mount Package

Applications

Wireless Datacom

Wireless Bar Code Scanners

Inter-Building Campus Networks

GND

RF IN

Description

The CMM2321 is a power amplifier intended for use

in 2.4 GHz ISM band applications such as wireless datacom

equipment, wireless bar code scanners and inter-building cam-

pus networks. This flexible amplifier can be biased to support

the requirements of frequency hopping or direct sequence sys-

tems. The CMM2321 is packaged in a low-cost, space effi-

cient SO-8 power package that gives excellent electrical sta-

bility and thermal handling performance with a R

of less

than 18° C/W. The part is designed to require minimal exter-

nal circuitry for bias matching, simplifying design and keep-

ing board space and cost to a minimum.

Absolute Maximum Ratings

Parameter

Rating

Parameter

Rating

Parameter

Rating

Drain Voltage (+Vd)

Drain Current (Id)

RF Input Power

DC Gate Voltage (-Vg)

+9.0 V*

1.8 A

+15 dBm*

-4.0 V*

Power Dissipation

Thermal Resistance

Storage Temperature

18°C/W

-65°C to +150°C

Operating Temperature

Channel Temperature

Soldering Temperature

-40°C to +100°C

175°C

260°C for 5 Sec.

* Max (+Vd) and (-Vg) under linear operation. Max potential difference across the device in RF compression (2Vd + |-Vg|) not to exceed the minimum breakdown voltage (Vbr) of +18V.

Recommended Operating Conditions

Parameter

Typ

Units

Parameter

Typ

Units

Drain Voltage (+Vd)

4.5 to 5.1

Volts

Operating Temperature (PC Board)

-30 to +80

°C

Electrical Characteristics

The following specifications are guaranteed at room temperature with drain voltage (+Vd) = 4.8 V @ 2.45 GHz in Celeritek test fixture.

Parameter

Condition

Min

Typ

Max

Units

Frequency Range

P-1dB

OUT

Saturated

Efficiency (PAE)

Gain

Harmonics

Noise Figure

Return Loss

Negative Supply Current (-Ig)

Positive Supply Current (Id)

= +14 dBm

@ Saturation

2nd @ Pout = +30 dBm

3rd @ Pout = +30 dBm

2.4

2.5

30.5

31.5

-35

-40

5.0

0.5

675

-30

-35

1.0

@ P-1dB

GHz

dBm

dBc

3236 Scott Boulevard

Santa Clara, California 95054

Phone: (408) 986-5060

Fax: (408) 986-5095
