Diamond Power Products
Advance
Product Bulletin
BG1A
Universal High Power IGBT Module Gate Driver Boar
d
BG1A-F kit contents: M57160AL gate driver and VLA106-15242 DC/DC converter.
BG1A-KA kit contents: VLA504 gate driver and VLA106-15242 DC/DC converter.
*The VLA504 replaces the older M57962L gate driver and the VLA106-15242 replaces the M57145L-01
DC/DC converter.
VLA504 / M57160AL
BG1A is a fully isolated gate drive
circuit board designed for use
with high current single IGBT
modules. When the board is
populated, a VLA504 hybrid gate
driver supplies the gate drive with
complementary emitter follower
power booster to provide efficient
switching of modules rated up to
1200A. The hybrid gate drivers
also provide protection against
unexpected short circuit
conditions. Isolated control
power for the driver is supplied by
an onboard VLA106-15242
regulated DC/DC converter. The
fault feedback signal is also
optically isolated.
See application note “
Hybrid
Circuits Simplify IGBT Module Gate
Drive” at
www.pwrx.com.
Description
Features
•
•
•
•
•
20A Peak Output Current
2500VRMS Isolation
Direct Mounting to IGBT
+15V to –8.5V Output
Voltage Swing
Wide Input Voltage Range
+12V to +18V
use with the following Powerex
Single IGBT Modules
•
CM600HU-12H/F
•
CM400/600HU-24H/F
•
CM800/1000HA-24H
•
CM800/1000HA-28H
•
CM1200HA-24J
Applications
Designed for
VLA106-15242
Schematic Diagram
Rapid Design - Component List
Designation
C1,C2
C3,C4
C5
C6
R1
R2
RG
D1, D2
DZ1, DZ2
DZ3
Q1
Q2
OP1
CN1
CN2
J1
Description
Power supply decoupling
capacitors. Low impedance
long life type.
Low ESR polyester film or
ceramic decoupling capacitors
DC to DC converter input
decoupling capacitor. Low
impedance long life type
Optional - For adjustment of
short circuit protection trip time.
Current limit for fault opto
Pull up for fault output
Series gate resistor - See
Powerex IGBT application
notes
Collector voltage detection
diodes. Vrrm greater than
IGBT Vces rating.
Gate protection zeners
Detect pin protection zener
NPN Booster transistor
PNP Booster transistor
Opto for fault signal isolation
MTA100 6 position right angle
header with locking ramp
5/16” Ring Lug on 3.5” wire
Insert when using M57160AL
with F-Series IGBT modules
and omit D1, D2, DZ1-DZ3
Value
150µF
35V
1µF
50V
150µF
35V
0 to 200pF
50V
4.7K .25W
4.7K .25W
0.5Ω to
33Ω
0.5 to 2W
1A, 1000V
t
rr
<100ns
17V, 0.5W
30V, 0.5W
15A, 80V
15A, 80V
Example Type
Panasonic FC
EEUFC1V151
Panasonic
ECQV1H105J
L
Panasonic FC
EEUFC1V151
muRata RPE
Series
+V
L
IN
NC
FO
+V
S
GND
CN1
+
C5
R2
R1
Q2
C3
1
OP1
14 13
10
VLA504
C6
+
+ C1 C2
1
DZ3
Q1
C4
R
G
D1 D2 CN2
C
J1
G
DZ1
DZ2
E
E
IGBT
Module
11
VLA106-15242
8
3
1
Motorola
MUR1100E
1N5247
1N5256
ONSemi
D44VH10
Motorola
D45VH10
NEC PS2501
AMP
640457-6
AMP 34151
T ypic al Interfac e C irc uit
+ 12 to
+ 18V
+ 5V
1
+V
L
IN
NC
FO
+V
S
GND
C N1
Open C ollec tor
Buffer/D river
To logic level
c ontrol c irc uits
RC Filter to
remove noise
on fault signal
06/29/06
Page 1
DB-00004C
