NRSX391K6.3V8X11.5TRF: DescriptionAluminum Electrolytic Capacitor, Polarized, Aluminum (wet), 6.3V, 10% +Tol, 10% -Tol, 390uF, Through Hole Mount, RADIAL LEADED, ROHS COMPLIANT; CategoryPassive components capacitor; File Size156KB，6 Pages; ManufacturerNIC Components Corp; Environmental Compliance

Download Datasheet Parametric Compare View All

NRSX391K6.3V8X11.5TRF Overview

Aluminum Electrolytic Capacitor, Polarized, Aluminum (wet), 6.3V, 10% +Tol, 10% -Tol, 390uF, Through Hole Mount, RADIAL LEADED, ROHS COMPLIANT

NRSX391K6.3V8X11.5TRF Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Objectid	2031686152
package instruction	,
Reach Compliance Code	compliant
ECCN code	EAR99
capacitance	390 µF
Capacitor type	ALUMINUM ELECTROLYTIC CAPACITOR
dielectric materials	ALUMINUM (WET)
JESD-609 code	e3
leakage current	0.0246 mA
Installation features	THROUGH HOLE MOUNT
negative tolerance	10%
Number of terminals	2
Maximum operating temperature	105 °C
Minimum operating temperature	-55 °C
Package shape	CYLINDRICAL PACKAGE
method of packing	TR
polarity	POLARIZED
positive tolerance	10%
Rated (DC) voltage (URdc)	6.3 V
ripple current	280 mA
surface mount	NO
Delta tangent	0.22
Terminal surface	Matte Tin (Sn)
Terminal shape	WIRE

Preview

Download Datasheet

View All

Miniature Aluminum Electrolytic Capacitors

VERY LOW IMPEDANCE AT HIGH FREQUENCY, RADIAL LEADS,

POLARIZED ALUMINUM ELECTROLYTIC CAPACITORS

FEATURES

• VERY LOW IMPEDANCE

• LONG LIFE AT 105°C (1000 ~ 7000 hrs.)

*See Part Number System for Details

• HIGH STABILITY AT LOW TEMPERATURE

• IDEALLY SUITED FOR USE IN SWITCHING POWER SUPPLIES &

..CONVERTORS

NRSX Series

RoHS

Compliant

CHARACTERISTICS

Rated Voltage Range

Capacitance Range

Operating Temperature Range

Capacitance Tolerance

After 1 min.

Max. Leakage Current @ (20

After 2 min.

6.3 ~ 50 VDC

1.0 ~ 15,000

µF

-55 ~ +105°C

20% (M)

0.03CV or 4

A, whichever if greater

0.01CV or 3

A, whichever if greater

W.V. (Vdc)

6.3

S.V. (Vdc)

C < 1,200

µF

0.22

0.19

0.16

0.14

C = 1,500

µF

0.23

0.20

0.17

0.15

C = 1,800

µF

0.23

0.20

0.17

0.15

C = 2,200

µF

0.24

0.21

0.18

0.16

C = 2,700

µF

0.25

0.22

0.19

0.17

C = 3,300

µF

0.26

0.23

0.20

0.18

C = 3,900

µF

0.27

0.24

0.21

0.19

C = 4,700

µF

0.28

0.25

0.22

0.20

C = 5,600

µF

0.30

0.27

0.24

C = 6,800

µF

0.32

0.29

0.26

C = 8,200

µF

0.35

0.32

0.29

C = 10,000

µF

0.38

0.35

C = 12,000

µF

0.42

C = 15,000

µF

0.48

Z-25°C/Z+20°C

Z-40°C/Z+20°C

Capacitance Change

Tan

Leakage Current

Max. Tan

@ 120Hz/20°C

0.12

0.13

0.14

0.15

0.16

0.10

0.11

0.12

Low Temperature Stability

Impedance Ratio @ 120Hz

Load Life Test at Rated W.V. & 105°C

7,000 Hours: 16 ~ 18

∅

5,000 Hours: 12.5

∅

4,000 Hours: 10

∅

3,000 Hours: 6.3 ~ 8

∅

2,500 Hours: 5

∅

1,000 Hours: 4

∅

Shelf Life Test

105°C 1,000 Hours

No Load

Max. Impedance at 100Khz & -20°C

Applicable Standards

PART NUMBER SYSTEM

NRSX 101 M 25V 6.3X11 TR F

Within +

20% of initial measured value

Less than 200% of specified maximum value

Less than specified maximum value

Capacitance Change

Within +

20% of initial measured value

Tan

Less than 200% of specified maximum value

Leakage Current

Less than specified maximum value

Less than 2 times the impedance at 100Khz & +20°C

JIS C5141, C5102 and IEC 384-4

RIPPLE CURRENT CORRECTION FACTOR

Cap. (

1.0 ~ 330

390 ~ 1000

1200 ~ 2200

2700 ~ 15000

Frequency (Hz)

120

0.40

0.50

0.70

0.90

0.68

0.76

0.85

0.95

10K

0.78

0.87

0.90

1.00

100K

1.00

Pb-free/RoHS Compliant

TR = Tape & Reel (optional)

TB = Tape & Box (optional)

Case Size (mm)

Working Voltage

Tolerance Code M=20%, K=10%

Capacitance Code in

µF

Series

*"F" suffix denotes RoHS compliant parts

NIC COMPONENTS

www.niccomp.com

www.lowESR.com

www.RFpassives.com

NRSX391K6.3V8X11.5TRF Related Products
