TLP3100
TOSHIBA Photocoupler Photorelay
TLP3100
Measurement Equipment
FA (Factory Automation)
Power Line Control
The Toshiba TLP3100 consists of an aluminum gallium arsenide infrared
emitting diode optically coupled to a photo-MOSFET in a SOP, which is
suitable for surface-mount assembly. The TLP3100 features high
ON-state current and low ON-state resistance, hence the TLP3100 is
suitable to control a power line.
•
6-pin SOP (2.54SOP6): 2.1 mm high, 2.54 mm pitch
•
•
•
•
•
•
•
•
Normally opened (form A) device
Peak OFF-state voltage: 20 V (min)
Trigger LED current: 3 mA (max)
ON-state current: 2.5 A (max) (Ta=50℃)
ON-state resistance: 0.02
Ω
(typ.), 0.05
Ω
(max)
Capacitance: 1000 pF (typ.)
OFF-state current: 10 nA (max)
Isolation voltage: 1500 V
rms
(min)
TOSHIBA
11-7C1
Unit: mm
Pin Configuration
(top view)
Weight: 0.13 g (typ.)
1:
2:
3:
4:
5:
6:
Anode
Cathode
N.C.
Drain D1
Source
Drain D2
1
6
2
5
3
4
Schematic
Start of commercial production
1
2008/04
2014-09-01
TLP3100
Absolute Maximum Ratings
(Ta
=
25°C)
Characteristics
Forward current
LED
Forward current derating (Ta
≥
25°C)
Reverse voltage
Junction temperature
Off-state output terminal voltage
A connection
On-state
current
Detector
B connection
C connection
A connection
On-state
current
B connection
derating
(Ta
≥
50°C) C connection
Junction temperature
Storage temperature
Operating temperature
Lead soldering temperature (10 s)
Isolation voltage
(AC, 1 minute, R.H.
≤
60%)
(Note 1)
ΔI
ON
/°C
T
j
T
stg
T
opr
T
sol
BV
S
I
ON
Symbol
I
F
ΔI
F
/°C
V
R
T
j
V
OFF
Rating
30
−0.3
5
125
20
2.5
2.5
5.0
−33.3
−33.3
−66.7
125
−55
to 125
−40
to 85
260
1500
°C
°C
°C
°C
Vrms
mA/°C
A
Unit
mA
mA/°C
V
°C
V
Note: Using continuously under heavy loads (e.g. the application of high temperature/current/voltage and the
significant change in temperature, etc.) may cause this product to decrease in the reliability significantly even if
the operating conditions (i.e. operating temperature/current/voltage, etc.) are within the absolute maximum
ratings.
Please design the appropriate reliability upon reviewing the Toshiba Semiconductor Reliability Handbook
(“Handling Precautions”/“Derating Concept and Methods”) and individual reliability data (i.e. reliability test
report and estimated failure rate, etc.).
Note 1: Device considered a two-terminal device: Pins 1 and 2 shorted together, and pins 3 and 4 shorted together.
Caution
This device is sensitive to electrostatic discharge. When using this device, please ensure that all tools and equipment
are earthed.
Recommended Operating Conditions
Characteristics
Supply voltage
Forward current
Operating temperature
Symbol
V
DD
I
F
T
opr
Min
⎯
5
-20
Typ.
⎯
10
⎯
Max
20
20
65
Unit
V
mA
°C
Note: Recommended operating conditions are given as a design guideline to obtain expected performance of the
device. Additionally, each item is an independent guideline respectively. In developing designs using this
product, please confirm specified characteristics shown in this document.
2
2014-09-01
TLP3100
Circuit Connections
1
2
3
6
5
4
LOAD
AC
or
DC
1
2
3
6
5
4
LOAD
1
2
3
6
5
4
LOAD
DC
DC
A connection
B connection
C connection
Individual Electrical Characteristics
(Ta
=
25°C)
Characteristics
Forward current
LED
Reverse current
Capacitance
Detector
OFF-state current
Capacitance
Symbol
V
F
I
R
C
T
I
OFF
C
OFF
Test Condition
I
F
=
10 mA
V
R
=
5 V
V
=
0, f
=
1 MHz
V
OFF
=
20 V
V
=
0, f
=
1 MHz
Min
1.18
⎯
⎯
⎯
⎯
Typ.
1.33
⎯
70
⎯
1000
Max
1.48
10
⎯
10
⎯
Unit
V
μA
pF
nA
pF
Coupled Electrical Characteristics
(Ta
=
25°C)
Characteristics
Trigger LED current
Return LED current
A connection
On-state resistance
B connection
C connection
R
ON
Symbol
I
FT
I
FC
Test Condition
I
ON
=
100 mA
I
OFF
=
10
μA
I
ON
=
2.0 A, I
F
=
5 mA, t<1s
I
ON
=
2.0 A, I
F
=
5 mA, t<1s
I
ON
=
4.0 A, I
F
=
5 mA, t<1s
Min
⎯
0.1
⎯
⎯
⎯
Typ.
⎯
⎯
0.02
0.01
0.005
Max
3
⎯
0.05
0.025
⎯
Ω
Unit
mA
mA
Isolation Characteristics
(Ta
=
25°C)
Characteristics
Capacitance input to output
Isolation resistance
Symbol
C
S
R
S
Test Condition
V
S
=
0 V, f
=
1 MHz
V
S
=
500 V, R.H.
≤
60%
AC, 1 minute
Isolation voltage
BV
S
AC, 1 second (in oil)
DC, 1 minute (in oil)
Min
⎯
5
×
10
10
Typ.
0.8
10
14
Max
⎯
⎯
⎯
⎯
⎯
Unit
pF
Ω
Vrms
Vdc
1500
⎯
⎯
⎯
3000
3000
3
2014-09-01
TLP3100
Switching Characteristics
(Ta
=
25°C)
Characteristics
Turn-ON time
Turn-OFF time
Symbol
t
ON
t
OFF
Test Condition
R
L
=
200
Ω
V
DD
=
10 V, I
F
=
5 mA
(Note 2)
Min
⎯
⎯
Typ.
1.5
0.1
Max
5.0
1.0
Unit
ms
I
F
1
2
4
6
R
L
V
DD
I
F
V
OUT
V
OUT
10%
t
ON
t
OFF
90%
Note 2: Switching time test circuit
4
2014-09-01
TLP3100
I F
─
Ta
50
I ON
─
Ta
6
(A)
(mA)
40
IF
ION
5
4
3
2
1
0
-20
C connection
30
Allowable On-sate current
Allowable forward current
20
A and B connections
10
0
-20
0
20
40
60
Ambient temperature
80
100
Ta (°C)
120
0
20
40
60
80
Ambient temperature Ta (°C)
100
I F
─
VF
100
3
I ON
─
VON
T
a
= 25℃
A connection
I
F
= 5mA
T
a
= 25℃
(mA)
(A)
2
Forward current
On-sate current
I ON
IF
10
1
0
1
-1
-2
-3
-0.08
0.1
0.6
0.8
1.0
1.2
1.4
1.6
1.8
-0.04
0
0.04
0.08
Forward voltage
VF
(V)
On-sate voltage
VON
(V)
R ON
─
Ta
0.20
0.18
I FT
─
Ta
1.0
0.9
I
ON
=
2.0 A
I
F
=
5 mA
t<1s
A connection
(mA)
I
ON
=
100m A
t<1s
(Ω)
0.16
0.14
0.12
0.10
0.08
0.06
0.04
0.02
0
-40
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
RON
Trigger LED current
-20
0
20
40
60
80
100
On-sate resistance
I FT
0
-40
-20
0
20
40
60
80
100
Ambient temperature
Ta
(°C)
Ambient temperature
Ta
(°C)
5
2014-09-01
