SD140P: Description1.0 Amp Schottky Barrier Rectifiers; CategoryDiscrete semiconductor diode; File Size36KB，2 Pages; ManufacturerTaiwan Semiconductor; Websitehttp://www.taiwansemi.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

SD140P Overview

1.0 Amp Schottky Barrier Rectifiers

SD140P Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Taiwan Semiconductor
Reach Compliance Code	compli
ECCN code	EAR99
Configuration	SINGLE
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	0.52 V
Humidity sensitivity level	1
Maximum non-repetitive peak forward current	20 A
Number of components	1
Maximum operating temperature	150 °C
Maximum output current	1 A
Maximum repetitive peak reverse voltage	40 V
surface mount	YES
technology	SCHOTTKY

Preview

Download Datasheet

View All

SD120P

THRU

SD1100P

1.0 Amp Schottky Barrier Rectifiers

Voltage Range

20 to 100 Volts

Current

1.0 Amperes

Features

Low forward voltage

Extremely Low thermal resistance

High Current Capability

For surface mount application

Higher temp soldering: 260

for 10 seconds at

terminals

0.053(1.35)

Max.

SOD-123

0.022(0.55)

Typ. Min.

0.152(3.85)

0.140(3.55)

0.112(2.85)

0.100(2.55)

0.010(0.25)

Min.

Mechanical Data

Case: SOD-123, plastic

Polarity: Cathode band

Lead: Axial leads, solderable per MIL-STD-202,

method 208 guaranteed

Mounting position: Any

Marking: As below table

0.006(0.15)

Typ. Min.

0.067(1.70)

0.55(1.40)

0.004(0.10)

Max.

Dimensions in inches and (millimeters)

Maximum Ratings and Electrical Characteristics

Rating at 25℃ambient temperature unless otherwise specified.

Maximum Ratings and Electrical Characteristics

Symbol

Type Number

120P

130P

Marking Code

Maximum Recurrent Peak Reverse Voltage

Working Peak Reverse Voltage

Maximum DC Blocking Voltage

Average Forward Current (I

F(AV)

@ T

=90

Peak Forward Current (I

FSM

@ 8.3ms half sine)

Maximum Instantaneous Forward Voltage @ 1.0A

Maximum DC Reverse Current at Rate DC Blocking

Voltage

Typical Junction Capacitance

Operating and Storage Temperature Range

140P

160P

190P 1100P

Units

RRM

RMS

(AV)

FSM

STG

1.0

0.65

0.3

100

0.45

0.52

0.83

-50 to + 150 / -65 to + 175

- 48 -

SD140P Related Products

	SD140P	SD120P	SD1100P	SD190P	SD160P	SD130P
Description	1.0 Amp Schottky Barrier Rectifiers	1.0 Amp Schottky Barrier Rectifiers	1.0 Amp Schottky Barrier Rectifiers	1.0 Amp Schottky Barrier Rectifiers	1.0 Amp Schottky Barrier Rectifiers	1.0 Amp Schottky Barrier Rectifiers
Is it Rohs certified?	conform to	-	-	conform to	conform to	conform to
Maker	Taiwan Semiconductor	-	-	Taiwan Semiconductor	Taiwan Semiconductor	Taiwan Semiconductor
Reach Compliance Code	compli	-	-	compli	compli	compli
ECCN code	EAR99	-	-	EAR99	EAR99	EAR99
Configuration	SINGLE	-	-	SINGLE	SINGLE	SINGLE
Diode type	RECTIFIER DIODE	-	-	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE
Maximum forward voltage (VF)	0.52 V	-	-	0.83 V	0.65 V	0.52 V
Humidity sensitivity level	1	-	-	1	1	1
Maximum non-repetitive peak forward current	20 A	-	-	20 A	20 A	20 A
Number of components	1	-	-	1	1	1
Maximum operating temperature	150 °C	-	-	150 °C	150 °C	150 °C
Maximum output current	1 A	-	-	1 A	1 A	1 A
Maximum repetitive peak reverse voltage	40 V	-	-	90 V	60 V	30 V
surface mount	YES	-	-	YES	YES	YES
technology	SCHOTTKY	-	-	SCHOTTKY	SCHOTTKY	SCHOTTKY
