TLP763J
TOSHIBA Photocoupler
GaAs Ired & Photo−Triac
TLP763J
Office Machine
Household Use Equipment
Triac Driver
Solid State Relay
The TOSHIBA TLP763J consists of a GaAs infrared LED optically
coupled to a zero voltage crossing turn-on photo-triac in a 6 lead plastic
DIP.
•
•
•
•
•
•
Peak off-state voltage: 600 V (min)
Trigger LED current: 10 mA (max)
On-state current: 100 mA (max)
Isolation voltage: 4000 Vrms (min)
UL recognized: UL1577, file No. E67349
BSI approved: BS EN60065: 2002,
Certificate No. 8945
BS EN60950-1: 2002,
Certificate No. 8946
•
SEMKO approved: SS EN60065 (EN60065, 1993)
SS EN60950 (EN60950, 1992)
SS EN60335 (EN60335, 1988)
Certificate No. 9522145
•
Option (D4) type
VDE approved: DIN EN 60747-5-2
Certificate No. 40009373
Maximum operating insulation voltage : 890 V
Pk
Highest permissible over voltage
: 6000 V
Pk
(Note) When an EN60747-5-2 approved type is needed,
please designate the “option (D4)”.
1
2
3
ZC
1 : Anode
2 : Cathode
3 : N.C.
4
6
Unit: mm
TOSHIBA
11−7A10
Weight: 0.42g (typ.)
Pin configuration (top view)
•
Creepage distance
Clearance
Insulation thickness
7.62mm pitch
TLP763J type
: 7.0mm (min)
: 7.0mm (min)
: 0.5mm (min)
10.16mm pitch
TLP763JF type
8.0mm (min)
8.0mm (min)
4.0mm (min)
0.5mm (min)
4 : Terminal 1
6 : Terminal 2
Internal creepage path : 4.0mm (min)
Start of commercial production
1994/06
1
2014-09-22
TLP763J
Absolute Maximum Ratings
(Ta
=
25°C)
Characteristic
Forward current
Forward current derating (Ta
≥
53°C)
LED
Peak forward current (100
μs
pulse, 100 pps)
Reverse voltage
Junction temperature
Off−state output terminal voltage
On−state RMS current
Detector
Ta = 25°C
Ta = 70°C
Symbol
I
F
∆I
F
/°C
I
FP
V
R
T
j
V
DRM
I
T(RMS)
∆I
T
/°C
I
TP
I
TSM
T
j
T
stg
T
opr
T
sol
BV
S
Rating
50
−0.7
1
5
125
600
100
50
−1.1
2
1.2
115
−55
to 125
−40
to 100
260
4000
Unit
mA
mA/°C
A
V
°C
V
mA
mA/°C
A
A
°C
°C
°C
°C
Vrms
On−state current derating (Ta
≥
25°C)
Peak on−state current (100μs pulse, 120pps)
Peak non-repetitive surge current
(PW = 10 ms)
Junction temperature
Storage temperature range
Operating temperature range
Lead soldering temperature (10s)
Isolation voltage (AC, 1 minute, R.H.≤ 60%)
Note: Using continuously under heavy loads (e.g. the application of high temperature/current/voltage and the
significant change in temperature, etc.) may cause this product to decrease in the reliability significantly even if
the operating conditions (i.e. operating temperature/current/voltage, etc.) are within the absolute maximum
ratings.
Please design the appropriate reliability upon reviewing the Toshiba Semiconductor Reliability Handbook
(“Handling Precautions”/“Derating Concept and Methods”) and individual reliability data (i.e. reliability test
report and estimated failure rate, etc.).
Recommended Operating Conditions
Characteristic
Supply voltage
Forward current
Peak on−state current
Operating temperature
Symbol
V
AC
I
F
I
TP
T
opr
Min
―
15
―
−25
Typ.
―
20
―
―
Max
240
25
1
85
Unit
V
ac
mA
A
°C
Note: Recommended operating conditions are given as a design guideline to obtain expected performance of the
device. Additionally, each item is an independent guideline respectively. In developing designs using this
product, please confirm specified characteristics shown in this document.
2
2014-09-22
TLP763J
RESTRICTIONS ON PRODUCT USE
•
Toshiba Corporation, and its subsidiaries and affiliates (collectively "TOSHIBA"), reserve the right to make changes to the information
in this document, and related hardware, software and systems (collectively "Product") without notice.
•
This document and any information herein may not be reproduced without prior written permission from TOSHIBA. Even with
TOSHIBA's written permission, reproduction is permissible only if reproduction is without alteration/omission.
•
Though TOSHIBA works continually to improve Product's quality and reliability, Product can malfunction or fail. Customers are
responsible for complying with safety standards and for providing adequate designs and safeguards for their hardware, software and
systems which minimize risk and avoid situations in which a malfunction or failure of Product could cause loss of human life, bodily
injury or damage to property, including data loss or corruption. Before customers use the Product, create designs including the Product,
or incorporate the Product into their own applications, customers must also refer to and comply with (a) the latest versions of all
relevant TOSHIBA information, including without limitation, this document, the specifications, the data sheets and application notes for
Product and the precautions and conditions set forth in the "TOSHIBA Semiconductor Reliability Handbook" and (b) the instructions for
the application with which the Product will be used with or for. Customers are solely responsible for all aspects of their own product
design or applications, including but not limited to (a) determining the appropriateness of the use of this Product in such design or
applications; (b) evaluating and determining the applicability of any information contained in this document, or in charts, diagrams,
programs, algorithms, sample application circuits, or any other referenced documents; and (c) validating all operating parameters for
such designs and applications.
TOSHIBA ASSUMES NO LIABILITY FOR CUSTOMERS' PRODUCT DESIGN OR APPLICATIONS.
•
PRODUCT IS NEITHER INTENDED NOR WARRANTED FOR USE IN EQUIPMENTS OR SYSTEMS THAT REQUIRE
EXTRAORDINARILY HIGH LEVELS OF QUALITY AND/OR RELIABILITY, AND/OR A MALFUNCTION OR FAILURE OF WHICH
MAY CAUSE LOSS OF HUMAN LIFE, BODILY INJURY, SERIOUS PROPERTY DAMAGE AND/OR SERIOUS PUBLIC IMPACT
("UNINTENDED USE").
Except for specific applications as expressly stated in this document, Unintended Use includes, without
limitation, equipment used in nuclear facilities, equipment used in the aerospace industry, medical equipment, equipment used for
automobiles, trains, ships and other transportation, traffic signaling equipment, equipment used to control combustions or explosions,
safety devices, elevators and escalators, devices related to electric power, and equipment used in finance-related fields.
IF YOU USE
PRODUCT FOR UNINTENDED USE, TOSHIBA ASSUMES NO LIABILITY FOR PRODUCT.
For details, please contact your
TOSHIBA sales representative.
•
Do not disassemble, analyze, reverse-engineer, alter, modify, translate or copy Product, whether in whole or in part.
•
Product shall not be used for or incorporated into any products or systems whose manufacture, use, or sale is prohibited under any
applicable laws or regulations.
•
The information contained herein is presented only as guidance for Product use. No responsibility is assumed by TOSHIBA for any
infringement of patents or any other intellectual property rights of third parties that may result from the use of Product. No license to
any intellectual property right is granted by this document, whether express or implied, by estoppel or otherwise.
•
ABSENT A WRITTEN SIGNED AGREEMENT, EXCEPT AS PROVIDED IN THE RELEVANT TERMS AND CONDITIONS OF SALE
FOR PRODUCT, AND TO THE MAXIMUM EXTENT ALLOWABLE BY LAW, TOSHIBA (1) ASSUMES NO LIABILITY
WHATSOEVER, INCLUDING WITHOUT LIMITATION, INDIRECT, CONSEQUENTIAL, SPECIAL, OR INCIDENTAL DAMAGES OR
LOSS, INCLUDING WITHOUT LIMITATION, LOSS OF PROFITS, LOSS OF OPPORTUNITIES, BUSINESS INTERRUPTION AND
LOSS OF DATA, AND (2) DISCLAIMS ANY AND ALL EXPRESS OR IMPLIED WARRANTIES AND CONDITIONS RELATED TO
SALE, USE OF PRODUCT, OR INFORMATION, INCLUDING WARRANTIES OR CONDITIONS OF MERCHANTABILITY, FITNESS
FOR A PARTICULAR PURPOSE, ACCURACY OF INFORMATION, OR NONINFRINGEMENT.
•
GaAs (Gallium Arsenide) is used in Product. GaAs is harmful to humans if consumed or absorbed, whether in the form of dust or vapor.
Handle with care and do not break, cut, crush, grind, dissolve chemically or otherwise expose GaAs in Product.
•
Do not use or otherwise make available Product or related software or technology for any military purposes, including without limitation,
for the design, development, use, stockpiling or manufacturing of nuclear, chemical, or biological weapons or missile technology
products (mass destruction weapons). Product and related software and technology may be controlled under the applicable export
laws and regulations including, without limitation, the Japanese Foreign Exchange and Foreign Trade Law and the U.S. Export
Administration Regulations. Export and re-export of Product or related software or technology are strictly prohibited except in
compliance with all applicable export laws and regulations.
•
Please contact your TOSHIBA sales representative for details as to environmental matters such as the RoHS compatibility of Product.
Please use Product in compliance with all applicable laws and regulations that regulate the inclusion or use of controlled substances,
including without limitation, the EU RoHS Directive.
TOSHIBA ASSUMES NO LIABILITY FOR DAMAGES OR LOSSES
OCCURRING AS A RESULT OF NONCOMPLIANCE WITH APPLICABLE LAWS AND REGULATIONS.
