TRS12E65C
5. Thermal Characteristics
Characteristics
Thermal resistance (junction-to-case)
Thermal resistance (junction-to-ambient)
Symbol
R
th(j-c)
R
th(j-a)
Test Condition
Max
1.9
89
Unit
/W
6. Electrical Characteristics (Unless otherwise specified, T
a
= 25
)
Characteristics
Peak forward voltage
Repetitive peak reverse current
Junction capacitance
Symbol
V
FM(1)
V
FM(2)
I
RRM(1)
I
RRM(2)
C
j
Test Condition
I
F
= 6 A (pulse measurement)
I
F
= 12 A (pulse measurement)
V
RRM
= 300 V (pulse measurement)
V
RRM
= 650 V (pulse measurement)
V
R
= 650 V, f = 1 MHz
Min
Typ.
1.27
1.54
0.008
0.43
65
Max
1.70
90
pF
µA
Unit
V
7. Marking
Fig. 7.1 Marking
Note:
A line under a Lot No. identifies the indication of product Labels.
[[G]]/RoHS COMPATIBLE or [[G]]/RoHS [[Pb]]
Please contact your TOSHIBA sales representative for details as to environmental matters such as the RoHS
compatibility of Product.
The RoHS is the Directive 2011/65/EU of the European Parliament and of the Council of 8 June 2011 on the
restriction of the use of certain hazardous substances in electrical and electronic equipment.
Part Number
TRS12E65C
Abbreviation Code
S12E65C
8. Usage Considerations
(1)
The absolute maximum ratings are rated values that must not be exceeded during operation, even for an
instant. The following are the recommended general derating methods for designing a circuit board using
this device.
V
RRM
: V
RRM
has a temperature coefficient of 0.1 %/.
Take this coefficient into account when designing a circuit board that will be operated
in a low-temperature environment.
I
F(DC)
: We recommend that the worst-case current be no greater than 80 % of the absolute maximum
rating of I
F(DC)
and that the worst-case junction temperature, T
j
, be kept below 140
.
I
FP
:
I
2
t:
T
j
:
(2)
We recommend that the worst-case current be no greater than 80 % of the absolute maximum
rating of I
FP
and that the worst-case junction temperature, T
j
, be kept below 140
.
This rating specifies a non-repetitive limit value.
This only applies to an abnormal operation, which seldom occurs during the lifespan of a device.
Derate device parameters in proportion to this rating in order to ensure high reliability.
We recommend that the junction temperature (T
j
) of a device be kept below 140
.
For other design considerations, see the Rectifiers databook or the Toshiba Semiconductor website.
2
2014-03-17
Rev.5.0
