2.5V ~ 3.3V SM TCXO CMOS
Specifications
2011/65/EU
GTXO-C75
GTXO-C75J: 2.5V supply
GTXO-C75K: 2.8V supply
GTXO-C75L: 3.3V supply
Variant
J
4.0 ~ 54.0MHz
3.1
3.7
4.2
4.6
5.5
3.4
4.1
4.7
5.2
6.0
4.0
4.8
5.5
6.0
7.0
K
L
K
J
R
C
N
S
I
Parameters
7.20
(max)
Option
Codes
Frequency range:
Calibration tolerance:
±0.5ppm @ +25°C ±2°C
5.20
(max)
Temperature stability:
Temperature range:
PAD
CONNECTION
Enable/Disable
Ground
Output
Supply
±3.0ppm
±2.5ppm
0 to +50°C
-10 to +60°C
-20 to +70°C
-30 to +75°C
-40 to +85°C
1.40
±0.10
5.08
1.40
1
2
3
4
Storage temperature range:
-40 to +125°C
3
2.00
2.20
1
2
2.60
4
Ageing:
±1.0ppm max first year
+2.5V (±5%)
+2.8V (±5%)
+3.3V (±5%)
Supply voltage (V
DD
):
4
3
1
2
2.00
1.80
3.28
TOP VIEW
1.80
Features
Supply current (mA):
4.0 ~ 10.0MHz
>10.0 ~ 20.0MHz
>20.0 ~ 30.0MHz
>30.0 ~ 40.0MHz
>40.0 ~ 54.0MHz
Frequency vs supply voltage:
±0.2ppm, V
DD
±5%
Driving ability:
15pF CMOS
Supply voltages from 2.5V ~ 3.3V
Low power consumption
Enable / disable tristate function
Low phase noise and jitter
Excellent frequency stability
Logic levels:
‘0’ level = 10%V
DD
max
‘1’ level = 90%V
DD
min
Waveform symmetry:
45:55 @ 50%V
DD
Rise / fall time:
5ns max
Frequency vs load:
±0.2ppm, Z
L
±10%
Enable / disable function:
Tristate (control via pad 1)
Output (pad 3)
Enabled
Enabled
High Impedance
Standby current:
10μA max
Enable / Disable Function
Input (pad 1)
Open
‘1’ level
‘0’ level
Phase noise (typ):
-145dBc/Hz @ 10kHz
Period jitter RMS:
3ps typ
Standard.
Optional - Please specify required code(s) when ordering
Ordering Information
Product name + variant + option codes + frequency
Option codes must be included to properly specify a model.
eg:
GTXO-C75L/JS 24.00MHz
3.3V supply, ±2.5ppm -30+75°C
GTXO-C75K/KN 40.0MHz
2.8V supply, ±3.0ppm -20+70°C
Option code X (eg GTXO-C75L/X) denotes a custom spec.
Tel:
+44 1460 256 100
16 Jun 2015
Fax:
+44 1460 256 101
E-mail:
sales@golledge.com
Web:
www.golledge.com
Product Information
Construction
GTXO-C75
Ceramic body with gold-plated pads
Metal lid, seam sealed
Composition
This product is lead-free, and is fully compliant with
the RoHS directive 2011/65/EU
2011/65/EU
Pb
LeadFree
Packaging & Handling
Production quantities supplied on T&R, 1k pcs per reel.
Small quantities may be supplied on tape (no reel), or in bulk.
Static sensitive product. Observe proper handling precautions.
Soldering Profile
°C
260
260°C ±5°C
10s max
Marking
S FREQUENCY
CTO
DC
Marking type: Laser
DC = Date code in YM, eg “AB” = Feb 2011
200
5°C/s max
A
B
C
D
E
F
G H
J
K
L M
Y
1
2
3
4
5
6
7
8
9
0
M Jan Feb Mar Apr May Jun Jul Aug Sep Oct Nov Dec
100
5°C/s max
Tape & Reel Specification
5.8
±0.05
Preheat
140~160°C
1.50Ø
1.75
Heat
> 200°C
40s max
Slow
cooldown
Time
4.0 2.0
0.3
0
90s max
200s max
5°
6.75
±0.05
7.7
16.0
±0.3
Solder resistance: 260°C x 10 secs x 2.
MARK
2.5
8.0
2.0
120°
1.50
21Ø
200Ø
FEED
17.5
-1.5
+2.0
13Ø
80Ø
Not to scale. Dimensions in mm. Tolerances ±0.1mm unless otherwise stated.
Tel:
+44 1460 256 100
19 Dec 2013
Fax:
+44 1460 256 101
E-mail:
sales@golledge.com
Web:
www.golledge.com
