CMOS Oscillator -55+210°C
Specifications
2011/65/EU
MCSO1E
MCSO1E: 32.0kHz ~ 20.0MHz
MCSO1EH:
20.0
~ 100MHz
Parameters
Frequency range:
32.0kHz ~ 100MHz
7.86
±0.20
Product
MCSO1E
See table
CMOS
Option
Codes
Supply voltage (V
DD
):
+5.0V (±5%)
+3.3V (±5%)
+2.5V (±5%)
V
W
D
G
3.60
±0.20
Frequency stability (max)*:
±300ppm over -55 to +175°C
±400ppm over -55 to +210°C
Storage temperature range:
-55 to +125°C
Supply current:
2.00
±0.20
Driving ability:
Load:
3pF min, 47pF max
‘0’ level = +0.4V max
‘1’ level = V
DD
-0.5V min
5ms max
1
2
4
1.00
1
3
2
1.60
1.16
Logic levels:
4
2.10
3
1.60
Start up time:
2.54
3.18
TOP VIEW
2.54
Waveform symmetry:
40:60 max @ 50%V
DD
Rise / fall times:
7ns max
≤20MHz
3ns max >20MHz
150ns max@ 32.768kHz
Features
Suitable for Avionics, Down-hole, Geothermal etc
Extreme temperature ranges up to 210°C
High stability & low ageing under extremes
High shock & vibration resistance
Low current consumption
Enable / disable function:
None (pad 1 NC)
Tristate* (control via pad 1)
* not available under 500kHz
Shock resistance:
10,000G, 0.3ms, ½ sine
Vibration resistance:
40G rms 10.0 ~ 2,000Hz
Soldering condition:
260°C, 10 sec max
E
Standard.
Optional - Please specify required code(s) when ordering
Enable / Disable Function
Input (pad 1)
Open
‘1’ level
‘0’ level
Output (pad 3)
Enabled
Enabled
High Impedance
* Frequency stability is inclusive of calibration @ 25°C, operating temperature range, sup-
ply voltage change, load change and ageing (1 year).
Ordering Information
Product name + option codes + frequency
eg:
MCSO1E/DE 10.0MHz
5V ±300ppm -55 to +175°C Enable / disable
For frequencies
20.0MHz
add an 'H' to the product name
eg:
MCSO1EHW/G 32.0MHz
2.5V ±400ppm -55 to +210°C no E/D
Option code X (eg MCSO1E/X) denotes a custom specification.
Packed in trays (91pcs/tray), or T&R 250 ~ 1,000pcs / reel
Supply current
Freq / Supply
32kHz
<10MHz
10 ~ 20MHz
>20 ~ 100MHz
2.5V
300μA
2mA
3mA
15mA
3.3V
1mA
4mA
5mA
20mA
5.0V
2mA
6mA
7mA
30mA
Maximum values, no load.
Tel:
+44 1460 256 100
15 Nov 2013
Fax:
+44 1460 256 101
E-mail:
sales@golledge.com
Web:
www.golledge.com
