Marvell
®
88W8977
High Performance, Power Efficient, Highly Integrated SoC
MARVELL 88W8977 OVERVIEW
The Marvell® 88W8977 is a highly integrated WLAN (2.4/5 GHz) and Bluetooth single-chip solution,
specifically designed to support the speed, reliability, and quality requirements of next generation products.
The System-on-Chip (SoC) provides both simultaneous and independent operation of the following:
•
IEEE 802.11n compliant, 1x1 spatial stream with data rates up to MCS 7 (150 Mbps)
•
Bluetooth 4.2, as well as future Bluetooth 5.0 features (includes Bluetooth Low Energy (LE))
•
3-way coexistence for WLAN, Bluetooth, and ZigBee operation with Marvell ZigBee solutions
•
Indoor location and navigation (802.11 mc and BLE Angles)
Internal coexistence arbitration and a Mobile Wireless Systems (MWS) serial transport interface provide the
functionality for connecting an external Long Term Evolution (LTE) or ZigBee device.
For security, the device supports high performance 802.11i security standards through implementation of the
Advanced Encryption Standard (AES)/Counter Mode CBC-MAC Protocol (CCMP), Wired Equivalent Privacy
(WEP) with Temporal Key Integrity Protocol (TKIP), AES/Cipher-Based Message Authentication Code
(CMAC), and WLAN Authentication and Privacy Infrastructure (WAPI) security mechanisms.
For video, voice, and multimedia applications, 802.11e Quality of Service (QoS) is supported. The device also
supports 802.11h Dynamic Frequency Selection (DFS) for detecting radar pulses when operating in the
5 GHz range.
Generic interfaces include SDIO 3.0 and high-speed UART interfaces for connecting WLAN and Bluetooth
technologies to the host processor.
The device is available in QFN and eWLP package options.
APPLICATIONS
GENERAL FEATURES
•
Dual
simultaneous and
independent WLAN and
Bluetooth (includes LE)
operation
•
Dynamic Rapid Channel
Switching (DRCS) for
simultaneous and power
efficient operation in 2.4 GHz
and 5 GHz bands
•
Coexistence with cellular and
other on-chip radios
•
Low power dissipation
•
CMOS and low-swing sine wave
input clock
•
Digital audio interfaces
(PCM/Marvell proprietary TDM)
•
26 MHz reference clock select
•
Optional external 32.768 kHz
CMOS-level sleep clock
•
Power management with sleep
clock
•
Fully compatible with Marvell
Power Management (PM)
device(s) (external PM device
required for power supply)
•
On-chip LDO for 1.1V generation
from V18
•
Sleep and standby modes for
low-power operation
•
One Time Programmable (OTP)
memory to eliminate need for
external EEPROM
Packaging
•
68-pin QFN
•
74-bump eWLP
SoC Level
CPU
•
Dual-core CPUs
•
160 MHz max CPU clock speed
Direct Memory Access (DMA)
•
Independent 2-Channel DMA
Memory
•
Internal SRAM for Tx frame
queues/Rx data buffers
•
Boot ROM
Test
•
On-chip diagnostic information
IEEE
802.11
Standards
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
IOT, Mobiles, IP Cameras, Wearables and Smart Home Applications
802.11 data rates of 1 and 2 Mbps
802.11b data rates of 5.5 and 11 Mbps
802.11a/g data rates 6, 9, 12, 18, 24, 36, 48, and 54 Mbps for multimedia content transmission
802.11g/b performance enhancements
802.11n with maximum data rates up to 72 Mbps (20 MHz channel), 150 Mbps (40 MHz channel)
802.11d international roaming
802.11e quality of service
802.11h transmit power control
802.11h DFS radar pulse detection
802.11i enhanced security
802.11k radio resource measurement
802.11mc precise indoor location and navigation
802.11n block acknowledgement extension
802.11r fast hand-off for AP roaming
802.11u Hotspot 2.0 (STA mode only)
802.11v TIM frame transmission/reception
802.11w protected management frames
Fully supports clients (stations) implementing IEEE Power Save mode
Marvell 88W8977 Overview
Marvell
Technology
G roup
www.marvell.com
ABOUT MARVELL:
Marvell is a global leader in providing complete silicon solutions and Kinoma® software, enabling the
“Smart Life and Smart Lifestyle.” From storage to cloud infrastructure, Internet of Things (IoT), connectivity and multimedia,
Marvell’s diverse product portfolio aligns complete platform designs with industry-leading performance, security, reliability
and efficiency. For additional information, please visit our website at www.marvell.com for a Marvell sales office or
representative in your area.
THE MARVELL ADVANTAGE:
Marvell chipsets come with complete reference designs which include board layout designs,
software, manufacturing diagnostic tools, documentation, and other items to assist customers with product evaluation and
production. Marvell’s worldwide field application engineers collaborate closely with end customers to develop and deliver
new leading-edge products for quick time-to-market. Marvell utilizes world-leading semiconductor foundry and packaging
services to reliably deliver high-volume and low-cost total solutions.
