Marvell 88i9441 Soleil-H SATA SSHD Controller
6Gb/s SATA, Dual ARM On-Chip Processors, Encryption
PRODUCT OVERVIEW
The Marvell® 88i9441 is a high performance, low power Solid State Hybrid Drive (SSHD) controller that is highly flexible, enabling
optimization for a wide variety of storage environments. Advanced read/write channel technology with low density parity check
(LDPC) makes Soleil the best choice for high density drives.
Two integrated ARM Cortex-R4 processors allow independent management of host and servo functions, enhancing overall HDD
performance. A third dedicated secure processor supports AES encryption, protecting user data from unauthorized access.
The 6Gb/s SATA host interface supports Native Command Queuing, T10 CRC checking, and the ATA-8 command set, ensuring
high performance, data integrity, and full compatibility with SATA hosts.
BLOCK DIAGRAM
Preamp
Spindle
6Gb/s x2
Trace
Servo /
Read Channel
Real-Time Trace
AES Encryption
96 KB
ATCM
32 KB
B0TCM
Oscillator
ARM Cortex
R4
Host
ARM Cortex
R4
Servo
64 KB
ATCM
32 KB
B0TCM
eMMC
Controller
eMMC
Flash
PLL
4 KB
Shared B1TCM
PCIe Host
Controller
DRAM
Buffer
Flash
SATA Controller
6Gb/s SATA
Fig 1. Marvell 88i9441 SATA SSHD Controller
Marvell 88i9441 6Gb/s SATA, Dual ARM On-Chip Processors, Encryption
BENEFITS AND FEATURES
KEY BENEFITS
•
CPU
•
Host Interface
KEY FEATURES
•
Dual ARM Cortex R4 at 600MHZ
•
Separate DTCM and ITCM caches
•
•
•
•
6Gb/s SATA interface
Native Command Queuing enhances performance
ATA-8 command support ensures compatibility
T10 CRC check provides data integrity
•
Read/Write Channel
•
Low-density parity check (LDPC) for high-density HDDs
•
RS-ECC-less iterative decoder with programmable noise predictive non-linear Viterbi
detector for wide range of densities
•
PCIe controller handles data transfers to/from buffer using hardware automation,
minimizing latency and improving performance
•
256 bit AES encryption of user data
•
Trusted Computing Group (TCG) compliant
•
231-ball 8x10mm BGA
•
Flash Cache
•
Data Protection
•
Package
TARGET APPLICATIONS
•
Solid state hybrid drives
THE MARVELL ADVANTAGE:
Marvell chipsets come with complete reference designs which include board layout designs,
software, manufacturing diagnostic tools, documentation, and other items to assist customers with product evaluation and
production. Marvell’s worldwide field application engineers collaborate closely with end customers to develop and deliver
new leading-edge products for quick time-to-market. Marvell utilizes world-leading semiconductor foundry and packaging
services to reliably deliver high-volume and low-cost total solutions.
ABOUT MARVELL:
Marvell Marvell (NASDAQ: MRVL) is a global leader in providing complete silicon solutions enabling the
digital connected lifestyle. From mobile communications to storage, Internet of Things (IoT), cloud infrastructure, digital
entertainment and in-home content delivery, Marvell’s diverse product portfolio aligns complete platform designs with
industry-leading performance, security, reliability and efficiency. At the core of the world’s most powerful consumer,
network and enterprise systems, Marvell empowers partners and their customers to always stand at the forefront of
innovation, performance and mass appeal. By providing people around the world with mobility and ease of access to
services adding value to their social, private and work lives, Marvell is committed to enhancing the human experience. As
used in this release, the term “Marvell” refers to Marvell Technology Group Ltd. and its subsidiaries. For more information,
please visit
www.Marvell.com.
Marvell Semiconductor, Inc.
5488 Marvell Lane
Santa Clara, CA 95054
Phone 408.222.2500
www.marvell.com
