Anti-Sulfurated Thick Film Chip Resistors
Document No. TRMS-XX0S001O
Revise Date
page number
2021/08/04
3/13
( RMS series standard )
Halogen-Free
AEC-Q200 qualified
5. Ratings & Characteristics :
Type
Power
Max.
Max.
Rating
T.C.R
Rating
Working Over- Load
Voltage
(PPM/℃)
at 70℃
Voltage
Voltage
±200
25V
50V
+600
-200
±100
±200
50V
100V
+500
-200
±400
±100
RMS06 1/10W
Refer
5.2
50V
100V
±200
±400
±100
RMS10
1/8W
Refer
5.2
150V
300V
±200
±400
±100
RMS12
1/4W
Refer
5.2
200V
400V
±200
±400
±100
RMS13 1/2W
Refer
5.2
200V
400V
±200
±400
±100
RMS20
1/2W
Refer
5.2
200V
400V
±200
±400
±100
RMS25
1W
Refer
5.2
200V
400V
±200
±400
10Ω-1MΩ
10Ω-1MΩ
10Ω-1MΩ
10Ω-1MΩ
10Ω-1MΩ
10Ω-1MΩ
Resistance Range(Ω)
D(±0.5%)
E-96&E-24
100Ω -10KΩ
F(±1%)
E-96&E-24
10Ω -3MΩ
1Ω≦R<10Ω
G(±2%)
E-24
10Ω -3MΩ
1Ω≦R<10Ω
J(±5%)
E-24
10Ω -10MΩ
1Ω≦R<10Ω
RMS02 1/20W
Refer
5.2
100Ω ~1MΩ
10Ω≦R<100Ω
100Ω ~1MΩ
10Ω≦R<100Ω
1MΩ<R≦10MΩ
1Ω≦R<10Ω
10Ω-10MΩ
1Ω≦R<10Ω
10Ω-10MΩ
1Ω≦R<10Ω
10MΩ≦R≦20MΩ
10Ω-1MΩ
1M<R≦10MΩ
1Ω≦R<10Ω
10Ω-1MΩ
1M<R≦10MΩ
1Ω≦R<10Ω
10Ω-1MΩ
1M<R≦10MΩ
1Ω≦R<10Ω
10Ω-1MΩ
1M<R≦10MΩ
1Ω≦R<10Ω
10Ω-1MΩ
1M<R≦10MΩ
1Ω≦R<10Ω
10Ω-1MΩ
1M<R≦10MΩ
1Ω≦R<10Ω
10Ω-10MΩ
1Ω≦R<10Ω
10Ω-10MΩ
1Ω≦R<10Ω
10M<R≦20MΩ
10Ω-10MΩ
1Ω≦R<10Ω
10Ω-10MΩ
1Ω≦R<10Ω
10M<R≦20MΩ
10Ω-10MΩ
1Ω≦R<10Ω
10Ω-10MΩ
1Ω≦R<10Ω
10MΩ<R≦20MΩ
10Ω-10MΩ
1Ω≦R<10Ω
10Ω-10MΩ
1Ω≦R<10Ω
10MΩ<R≦20MΩ
10Ω-10MΩ
1Ω≦R<10Ω
10Ω-10MΩ
1Ω≦R<10Ω
10MΩ<R≦20MΩ
10Ω-10MΩ
1Ω≦R<10Ω
10Ω-10MΩ
1Ω≦R<10Ω
10MΩ<R≦20MΩ
RMS04 1/16W
Refer
5.2
OΩ THICK FILM CHIP RESISTORS
Type
RMS02
RMS04
RMS06
RMS10
RMS12
RMS13
RMS20
RMS25
Operating Temp(℃):
Rated Current
0.5A
1A
1A
2A
2A
2A
2A
2A
-55℃
〜
+155℃ ( RMS02 :
Max Overload Current
1A
2.5A
2.5A
5A
5A
5A
5A
5A
-55℃
〜
+125℃ )
Resistance Range
50mΩ MAX
50mΩ MAX
50mΩ MAX
50mΩ MAX
50mΩ MAX
50mΩ MAX
50mΩ MAX
50mΩ MAX
Note
: Except for the above standardized products, we also provide the customized products.
TA-I TECHNOLOGY CO., LTD
Anti-Sulfurated Thick Film Chip Resistors
Document No. TRMS-XX0S001O
Revise Date
page number
2021/08/04
4/13
( RMS series standard )
Halogen-Free
AEC-Q200 qualified
5.1
Derating Curve :
For resistors operated at ambient temperature over 70℃ , power rating shall be derated in
accordance with figure 1.
P max.
Power ratio (%)
125
RMS02
RMS04/06/10
RMS12/13/20/25
Ambient Temp. (
C
)
Figure 1
5.2
Rated Voltage:
The rated voltage is calculated by the following formula:
E=
P*R
E=
Rated Voltage(V)
P=
Rated Power(W)
R=
Resistance Value
(Ω)
E.G. : What is RMS06JT102 the rated voltage ?
RMS06JT102 P:1/10W
E=
0.1(W) * 1000(Ω)
;
R:102 = 1KΩ = 1000Ω
= 10 (V)
TA-I TECHNOLOGY CO., LTD
Anti-Sulfurated Thick Film Chip Resistors
Document No. TRMS-XX0S001O
Revise Date
page number
2021/08/04
5/13
( RMS series standard )
Halogen-Free
AEC-Q200 qualified
6. Reliability Tests:
Test Items
Reference standard
-At
Condition of Test
+25/–55 °C and +25/+125 °C
Test Limits
△R
Refer 5.0
±(1%
+ 0.05Ω )
Remarks :
0201:
±(3%
+ 0.1Ω )
0402 :
±(2%
+ 0.1Ω )
0Ω : 50mΩ or less
0.5%,1%:±(1.0%+0.05Ω)
2%,5%:±(2.0%+0.1Ω)
0201 :
±(3%
+ 0.1Ω )
0Ω : 50mΩ or less
Temperature Coefficient
IEC 60115-1 4.8
of Resistance
Short Time Overload
IEC60115-1 4.13
2.5 X rated voltage
for 5 sec
High Temperature
Exposure (Storage)
AEC-Q200-REV D-Test 3
MIL-STD-202 Method 108
1000 hrs. @ T=125°C. Unpowered.
Measurement at 24±2 hours after test
conclusion.
Temperature Cycling
AEC-Q200-REV D-Test 4
JESD22 Method JA-104
1000 Cycles (-55°Cto+125°C)
Measurement at 24±4 hours after test
±(1%
+ 0.1Ω )
0201 :
±(2%
+ 0.1Ω )
conclusion. 30min maximum dwell time
at each temperature extreme. 1 min. 0Ω : 50mΩ or less
maximum transition time.
0.5%,1%:±(1.0%+0.05Ω)
T=24 hours / Cycle ,10Cycles . Notes : 2%,5%:±(2.0%+0.1Ω)
Steps 7a& 7b not required. Unpowered . 0201 :
±(3%
+ 0.1Ω )
0Ω : 50mΩ or less
1000 hours 85°C/85%RH. Note: Specified
±(3%
+ 0.1Ω )
conditions: 10% of operating power(not
0201 :
±(5%
+ 0.1Ω )
exceeding max working voltage).
Measurement at 24±2 hours after test
0Ω : 100mΩ or less
conclusion.
1000 hours TA=125°C at 35% rated
power.
Measurement at 24±4 hours after test
conclusion.
Electrical test not required.
Inspect device construction, marking and
workmanship.
Verify physical dimensions to the
applicable device detail specification. Note:
User(s) and Suppliers spec. Electrical test
not required.
a:Isopropyl Alcohol：Mineral Spirits= 1：3
b:Terpene Defluxer (Bioact EC-7R)
Marking and protective layer
c:Deionized water
：Propylene
Glycol
can not be detached
Monomethyl Ether：monoethanolamine =
42：1：1
Wave Form : Tolerance for half sine shock
±(1%
+ 0.1Ω )
pluse. Peak value is 100g’s. Normal
0Ω : 50mΩ or less
duration(D) is 6(ms)
5 g's for 20 min., 12 cycles each of 3
orientations. Note: Test from 10-2000 Hz.
±(1%
+ 0.1Ω )
0Ω : 50mΩ or less
0.5%,1%:
±(1%
+ 0.1Ω )
2%.5% :
±(3%
+ 0.1Ω )
0201 :
±(5%
+ 0.1Ω )
0Ω : 100mΩ or less
Moisture Resistance
AEC-Q200-REV D-Test 6
MIL-STD-202 Method 106
Biased Humidity
AEC-Q200-REV D-Test 7
MIL-STD-202 Method 103
Operational Life
AEC-Q200-REV D-Test 8
MIL-STD-202 Method 108
External Visual
AEC-Q200-REV D-Test 9
MIL-STD-883 Method 2009
Physical
Dimension
AEC-Q200-REV D-Test 10
JESD22 Method JB-100
Resistance to
Solvents
AEC-Q200-REV D-Test 12
MIL-STD-202 Method 215
Mechanical Shock
AEC-Q200-REV D-Test 13
MIL-STD-202 Method 213
AEC-Q200-REV D-Test 14
MIL-STD-202 Method 204
Vibration
