CMS17
TOSHIBA Schottky Barrier Diode
CMS17
Switching Mode Power Supply Applications
Portable Equipment Battery Applications
•
•
•
•
Forward voltage: V
FM
= 0.48 V (max)
Average forward current: I
F (AV)
= 2.0 A
Repetitive peak reverse voltage: V
RRM
= 30 V
Suitable for compact assembly due to a small surface-mount package:
“M−FLAT
TM
” (Toshiba package name)”
Unit: mm
Absolute Maximum Ratings
(Ta = 25°C)
Characteristic
Repetitive peak reverse voltage
Average forward current
Nonrepetitive peak surge current
Junction temperature
Storage temperature range
Symbol
V
RRM
I
F (AV)
I
FSM
T
j
T
stg
Rating
30
2.0 (Note 1)
30 (50 Hz)
−40~150
−40~150
Unit
V
A
A
°C
°C
Note 1: Ta
=
77°C
Device mounted on a ceramic board
Board size: 50 mm
×
50 mm
Soldering size: 2 mm
×
2 mm
Board thickness: 0.64 t
Rectangular waveform (α
=
180°), V
R
=
15 V
JEDEC
JEITA
TOSHIBA
⎯
⎯
3-4E1A
Weight: 0.023 g (typ.)
Note 2: Using continuously under heavy loads (e.g. the application of
high temperature/current/voltage and the significant change in
temperature, etc.) may cause this product to decrease in the reliability significantly even if the operating
conditions (i.e. operating temperature/current/voltage, etc.) are within the absolute maximum ratings.
Please design the appropriate reliability upon reviewing the Toshiba Semiconductor Reliability Handbook
(“Handling Precautions”/Derating Concept and Methods) and individual reliability data (i.e. reliability test
report and estimated failure rate, etc).
Electrical Characteristics
(Ta
=
25°C)
Characteristic
Peak forward voltage
Symbol
V
FM (1)
V
FM (2)
I
RRM (1)
I
RRM (2)
C
j
Test Condition
I
FM
=
1.0 A (pulse test)
I
FM
=
2.0 A (pulse test)
V
RRM
=
5 V (pulse test)
V
RRM
=
30 V (pulse test)
V
R
=
10 V, f
=
1.0 MHz
Device mounted on a ceramic board
(board size: 50 mm
×
50 mm)
(soldering land: 2 mm
×
2 mm)
(board thickness: 0.64 t)
Thermal resistance
(junction to ambient)
R
th (j-a)
Device mounted on a glass-epoxy board
(board size: 50 mm
×
50 mm)
(soldering land: 6 mm
×
6 mm)
(board thickness: 1.6 t)
Device mounted on a glass-epoxy board
(board size: 50 mm
×
50 mm)
(soldering land: 2.1 mm
×
1.4 mm)
(board thickness: 1.6 t)
Thermal resistance
(junction to lead)
R
th (j-ℓ)
⎯
Min
⎯
⎯
⎯
⎯
⎯
⎯
Typ.
0.42
0.45
0.8
10
90
⎯
Max
⎯
0.48
⎯
100
⎯
60
Unit
V
Peak repetitive reverse current
Junction capacitance
μA
pF
⎯
⎯
135
°C/W
⎯
⎯
210
⎯
⎯
16
°C/W
Start of commercial production
1
2004-09
2013-11-01
CMS17
Marking
Abbreviation Code
SG
Part No.
CMS17
Standard Soldering Pad
Unit: mm
1.4
3.0
1.4
Handling Precaution
1)
Schottky barrier diodes have reverse current characteristics compared to other diodes. SBDs can cause thermal
runaway when used under high temperature or high voltage conditions. Be sure to take forward and reverse
loss into consideration during design.
The absolute maximum ratings denote the absolute maximum ratings, which are rated values that must not be
exceeded during operation, even for an instant. The following are the general derating methods that we
recommend for designing a circuit incorporating this device.
V
RRM
: Use this rating with reference to (1) above. V
RRM
has a temperature coefficient of 0.1%/°C. Take
this temperature coefficient into account when designing a device for operation at low
temperature.
I
F (AV)
: We recommend that the worst case current be no greater than 80% of the absolute maximum
rating of
I
F (AV)
and that T
j
be below 120°C. When using this device, take the margin into consideration by
using an allowable Tamax-I
F (AV)
curve.
I
FSM
: This rating specifies the nonrepetitive peak current. This is applied only for abnormal operation,
which seldom occurs during the lifespan of the device.
T
j
:
Derate this rating when using the device to ensure high reliability.
We recommend that the device be used at a T
j
of below 120°C.
2)
3)
Thermal resistance between junction and ambient fluctuates depending on the mounting condition of the
device. When using the device, design the circuit board and soldering land size to match the appropriate
thermal resistance value.
Refer to the Rectifiers databook for further information.
4)
2.1
2
2013-11-01
