SCREW TERMINAL TYPE ALUMINUM ELECTROLYTIC CAPACITORS
HCGF6A Series
• Conform RoHS
Useful of 4,000 hours at 85°C (Warranty of 2,000 hours at 85°C)
Features
• The size is reduced by about 14% of the HCGF5A series
and the rating 500 V DC is added in the series. A super
large case product of ø100 is also added.
Product Specifications
Items
Specifications
~ +85°C
Temperature range –25°C
Rated voltage 400 ~ 500V.DC
Capacitance tolerance ±20% (20°C,120Hz)
0.01CV (µA) or 5mA, whichever is smaller or less
Leakage current
[C = nominal capacitance (µF), V = rated voltage (V)]
Dissipation factor Less than the value specified in the standard products table. (20˚C,120Hz)
Permissible ripple current As specified in the standard products table. (40˚C,120Hz)
Insulation plate
S-Hexagon-head bolt
Screw terminal
Vent
Anode marking
Insulation sleeve
After the rated voltage with specified ripple current is applied at 85°C for 2000 hours:
Capacitance tolerance: ±15% or less of the initial value
High-temperature load
Dissipation factor: 175% or less of the specified initial value
Leakage current: Specified initial value or less
Others
JIS C 5101-4.
L
±2
Marking
Ｔ
±1
P
±1
φD
±1
Ripple current correction coefficient
Temperature (°C)
Correction coefficient
Frequency (Hz)
Correction coefficient
40
1.0
50/60
0.7
60
0.75
120
1.0
70
0.62
300
1.1
85
0.37
1k
1.3
(unit：mm)
φD
51
64
77
90
101
P
22.0
28.6
32.0
32.0
32.0
S
M5×10
M5×10
M5×10
M5×10
M6×12
T
4.5
4.5
4.5
4.0
3.0
Cap material
PPS
PPS
PPS
PPS
PPS
≧10K
1.4
Ripple current should be under 60Arms at M5 (100Arms at M6 for G case)
in accordance with from the permissible current.
Product code : (Example) HCGF6A Series A case 400V 10,000µF±20%
HCGF6 A 2G 103 Y
(
F
)
Case code (∗)
Type of bracket code
Capacitance code
Rated voltage code
Terminal code A (screw)
Type of series
Bracket
• See page 51 for shapes and dimensions.
• Product names in the Standard Products Table correspond to the
bracket for Type Y (Type
Ι
for ø36 only), but Type
Ι
bracket may be
used (Type of bracket Code =
Ι
).
• If bracket are not necessary, enter "N" for the type of bracket code.
• Bracket will be delivered separately.
∗(
) Case code in parentheses : If two types of shape exist for the same rating,
enter the case code.
Standard Products Table
Rated Voltage
Code
(Surge Voltage)
(V. DC)
Capacitance
(µF)
2200
2700
3300
3900
4700
5600
6800
8200
10000
12000
15000
18000
22000
Case size
øDXL(mm)
51×115
51×130
64×96
64×96
64×115
64×130
77×115
77×130
77×155
77×195
90×131
90×157
90×196
90×236
101×175
101×237
Ripple current
tanδ
20°C,120Hz
40°C,120Hz
(Arms)
ESR(typ.)
20°C,100Hz
(m
Ω
)
Z max
20°C,10kHz
(m
Ω
)
ESL(typ.)
(nH)
21
21
22
22
22
22
24
24
24
24
24
24
24
24
33
33
Product name
HCGF6A2G222Y
HCGF6A2G272YC
HCGF6A2G272YD
HCGF6A2G332Y
HCGF6A2G392Y
HCGF6A2G472Y
HCGF6A2G562Y
HCGF6A2G682Y
HCGF6A2G822Y
HCGF6A2G103YE
HCGF6A2G103YF
HCGF6A2G123Y
HCGF6A2G153Y
HCGF6A2G183YF
HCGF6A2G183YG
HCGF6A2G223Y
400
2G
(450)
0.20
0.20
0.20
0.20
0.20
0.20
0.20
0.20
0.20
0.20
0.20
0.20
0.20
0.20
0.20
0.20
16.5
19.2
18.7
20.7
24.1
27.8
30.6
35.4
41.6
50.5
45.8
53.8
65.7
77.7
69.8
86.8
61
50
50
41
35
29
25
22
18
17
17
12
10
9
9
8
63
52
52
42
37
32
28
25
21
20
19
15
13
12
12
11
