NT
Features
n
Power ratings from 0.5 - 3 watts
n
Large terminals and optimized body shape
Applications
n
Telecommunications
n
Audio equipment
n
Medical equipment
n
Base stations
n
Industrial equipment
*R
oH
S
C
OM
PL
IA
LE
AD
F
RE
E
for power dissipation
n
Excellent surge capabilities
n
Low TCR
n
Non-inductive versions available
n
RoHS compliant*
PWR2010/3014/4318/5322
-
Surface Mount Wirewound Resistors
General Information
Ro VE LEA
HS RS D
C ION FRE
OM S E
PL AR
IA E
NT
*
The PWR2010/3014/4318/5322 Series surface mount wirewound resistors boast a high power density and excellent pulse power
characteristics. They can be used in a wide range of applications where surge voltages or inrush currents are present.
Electrical Characteristics
Parameter
Power
Resistance Range
1 % Based on E24+E96 Series
5 % Based on E24 Series
Resistance Range
(Non-inductive Versions)
Based on E24 Series
Tolerance
Temperature Coefficient
0.1 - 0.99
Ω
1.0 - 10
Ω
>10
Ω
Operating Temperature
Maximum Voltage
PWR2010
0.5 W
0.005
Ω
- 1.2K
Ω
0.1
Ω
- 200
Ω
PWR3014
1.0 W
0.005
Ω
- 5K
Ω
0.1
Ω
- 1K
Ω
PWR4318
2.0 W
0.005
Ω
- 12K
Ω
0.1
Ω
- 2.4K
Ω
PWR5322
3.0 W
0.01
Ω
- 20K
Ω
0.1
Ω
- 4K
Ω
0.5 % / 1 % / 5 %
±90 PPM/˚C
±50 PPM/˚C
±20 PPM/˚C
-55 ˚ to 155 ˚C
√P*R
Environmental Characteristics
Test
Thermal Shock
Short Time Overload
Solderability
Resistance to Solder Heat
Description
-55 +0 °C/-3 °C to 150 °C +3 °C/-0 °C, 5 cycles,
with minimum 15 minutes at each cycle
Specification
ΔR
±(2.0 % +0.05
Ω)
ΔR
±(0.5 % +0.05
Ω)
90 % of contact covered in solder
ΔR
±(0.5 % +0.05
Ω)
Pass
>1000 GΩ
ΔR
±(2.0 % +0.05
Ω)
ΔR
±(2.0 % +0.05
Ω)
ΔR
±(2.0 % +0.05
Ω)
Dielectric Strength
Insulation Resistance
High Temperature Exposure
Low Temperature Exposure
Load Life
Five times rated power for 5 seconds
Immersion in solder 260 °C ±5 ˚C for 5 ±0.5 seconds
Immersion in solder 260 °C ±5 ˚C for 5 ±0.5 seconds
Test voltage >500 Vrms for greater than 1 minute
Test voltage greater than 500 Vrms for one minute
Ambient temperature of 175 °C +5 ˚C/-0 ˚C for 250 ±8 hours
Ambient Temperature of -65C ±2C for 24 hours ±4 hours
Rated continuous voltage for 1000 hours (1 hour on and 0.5 hours
off) at a test temperature of 70°C ±2 °C
Environmental Characteristics
(Cont’d)
Asia-Pacific:
Tel: +886-2 2562-4117 • Email: asiacus@bourns.com
EMEA:
Tel: +36 88 520 390 • Email: eurocus@bourns.com
The Americas:
Tel: +1-951 781-5500 • Email: americus@bourns.com
www.bourns.com
Moisture Sensitivity Level .....................1
ESD Classification (HBM) .................N/A
Physical Characteristics
Body Material....................... Epoxy resin
Lead Frame .... 100 % Sn Plated Copper
Flammability ....... Conforms to UL 94V-0
WARNING Cancer and Reproductive Harm -
www.P65Warnings.ca.gov
*RoHS Directive 2002/95/EC Jan. 27, 2003 including annex and RoHS Recast 2011/65/EU June 8, 2011.
Specifications are subject to change without notice.
Users should verify actual device performance in their specific applications.
The products described herein and this document are subject to specific legal disclaimers as set forth on the last page
of this document, and at www.bourns.com/docs/legal/disclaimer.pdf.
