4
PART APPLICABLE
NO.
NOTE(S)
-1CC
-2CC
-3CC
-4CC
1,2,3
1,2,3
1,2,3
1,2,3
INTERFACE(S)
FULL DETENT
LIMITED DETENT
SMOOTH DETENT
CATCHER MITT'S
(Ø A)
.116
.120
.125
.125
FIGURE(S)
FIG. 1
FIG. 1
FIG. 1
FIG. 2
3
2
REVISIONS
REV
DESCRIPTION
1
DATE
BY
C
D
E
ECO 12288
ECO 12856
ECO 20006 (REDRAW IN SW)
10.02.00
03.02.01
03.01.07
HDB
YP
D
D
4X
.037
.035
.076
.074
.021
.019
2X
.150
.148
C
C
RECOMMENDED MOUNTING
HOLE PATTERN
MATERIAL:
Insert:
303 sst per ASTM A-582
Body & Center Conductor:
BeCu alloy per ASTM B-196
Insulator:
PTFE per ASTM D-1710
ELECTRICAL:
Impedance: 50 Ohms Nom.
Freq. Range: DC TO 12 GHz
VSWR:
1.25:1 max to 12GHz
Insertion Loss: .10 dB max to 12GHz
Working Voltage: 335 Vrms @ Sea Level
Dielectric Withstand Voltage: 500 Vrms min
RF HiPot Voltage: 325 Vrms Min @ 5MHz
Corona Level: 125 Vrms @ 70,000 ft
Insulation Resistance:
5000 Mohms
Contact Resistance:
Center Conductor: 6.0 Milliohms max
Outer Conductor: 2.0 Milliohms max
RF Leakage:
-80 dB max to 3GHz
-65 dB max to 18GHz
MECHANICAL:
Interface Dimensions:
Consult Factory
Connector Durability:
100 Cycles min - Full Detent
500 Cycles min - Limited Detent
1000 Cycles min - Catchers Mitt
Center Contact Retention:
2 lbs Min Axial
N/A Radial
Force to Engage:
15 pounds max - Full Detent
10 pounds max - Limited Detent
2 pounds max - Catchers Mitt
Force to Engage:
5 pounds min - Full Detent
2 pounds min - Limited Detent
.5 pounds min - Catchers Mitt
Permeability: Less than 2.0 mu.
ENVIRONMENTAL:
Temp. Range: -65°C to +165°C
Thermal Shock:
MIL-STD-202, Method 107, Test Cond. B
Moisture Resistance:
MIL-STD-202, Method 106, except step 7b
shall be omitted. Insulation resistance at least
100 MegaOhms within 5 minutes after removal
from humidity.
Corrosion:
MIL-STD-202, Method 101, Test Cond. B
Vibration:
MIL-STD-202, Method 204, Test Cond. D
Shock:
MIL-STD-202, Method 213, Test Cond. I
B
B
FINISH:
APPLICABLE TENSOLITE DOCUMENTS
WORK STANDARD PROD INSTRUC
ASSY INSTRUC
NA
NA
NA
TOLERANCES AND NOTES
EXCEPT AS NOTED
DIMENSIONS ARE IN INCHES.
LINEAR .XX ±.015 ANGULAR ± 1/2°
.XXX ±.005
FRACTION ± 1/32
1. MACHINE FINISH: 63 RMS
2. BREAK ALL SHARP EDGES .003 MAX.
MAX.
3. MACHINED FILLETS
4. MACHINED SURFACES SQUARE TO RESPECTIVE
AXIS WITHIN .005 INCHES PER INCH.
5. MACHINED DIAMETERS CONCENTRIC WITHIN
.002 T.I.R.
6. DIMENSIONS TO BE MET BEFORE PLATING.
7. CHAMFER ALL THREADS 45°.
8. THREADS PER H-28
9. REMOVE FRAYED EDGES ON TEFLON.
10. REMOVE ALL BURRS.
SEE NOTE(S)
MATERIAL
APPROVAL INITIALS
DRAWN BY
CHECKED BY
TEST ENGR
QUALITY
DESIGN ENGR
DNG
MFG. ENGR
SCALE
SIZE
DATE
-
SEE NOTE(S)
SPECIFICATION
-
PROCUREMENT
A
Insert:
Passivate per ASTM A-967.
Body & Center Conductor:
Gold plate per ASTM B-488, over Nickle plate per AMS-QQ-N-290.
YPHAN
03.01.07
Tensolite
TITLE
SIZE
2400 Grand Avenue
HIGH PERFORMANCE CABLES
& INTERCONNECT SYSTEMS
Long Beach, California 90815-1762
A
NOTICE
THIS DRAWING EMBODIES A CONFIDENTIAL PROPRIETARY DESIGN
ORIGINATED BY TENSOLITE COMPANY AND ALL DESIGN, MANUFACTURING
REPRODUCTION, USE AND SALE RIGHTS REGARDING THE SAME ARE
EXPRESSLY RESERVED. IT IS SUBMITTED UNDER A CONFIDENTIAL
RELATIONSHIP FOR A SPECIFIED PURPOSE AND THE RECIPIENT AGREES
BY ACCEPTING THIS DRAWING NOT TO SUPPLY OR DISCLOSE ANY
INFORMATION REGARDING IT TO ANY UNAUTHORIZED PERSON TO
INCORPORATE IN OTHER PROJECTS ANY SPECIAL FEATURES PECULIAR
TO THIS DESIGN. ALL PATENT RIGHTS HERETO ARE EXPRESSLY
RESERVED BY TENSOLITE COMPANY, LONG BEACH, CALIFORNIA 90815.
.005
SMP MALE STRAIGHT
PCB MOUNT
SUB-DIRECTORY\FILE NAME
07.23.07
14:1
OLP
DRAWING NO.
SHEET
CAGE CODE
1
OF
2
REV.
C 30990
P603
E
ENG-DWG REV. A
4
3
2
1
