COAXIAL RESONATOR OSCILLATOR

Preview

Download Datasheet

View All

COAXIAL RESONATOR

OSCILLATOR

Features

Model 511076

1900 MHz

Low Phase Noise Bipolar Transistor

Rugged Construction for Extreme Environmental Conditions

High Frequency Stability

Maximum Ratings

Voltage Tuning Option

Specifications

CHARACTERISTIC

Frequency

Output Power (dBm)

Spurious (dBc)

Phase Noise (dB)

TYPICAL

Ta= 25

ºC

1900 MHz

+10

-60

-41 dBc/Hz @ 100 Hz

-81 dBc/Hz @ 1 KHz

-109 dBc/Hz @ 10 KHz

-131 dBc/Hz @ 100 KHz

-143 dBc/Hz @ 1 MHz

1.5

-20

+/- 0.1% / Volt

+/- 0.02%

+/- 0.01%

-55

ºC

150

2.0

-20

+/- .02% / Volt

+/- 0.03%

+/- 0.02%

+125

ºC

155

MIN/MAX

Ta = -10

ºC

to +60

ºC

1900 MHz

+13 Max.

-60

Ambient Operating Temperature ............. -55ºC to +100 ºC

Storage Temperature .............................. -62ºC to +125 ºC

Case Temperature ............................................... +125 ºC

DC Voltage ....................................................... +20 Volts

Maximum DC Tuning Voltage ............................ +20 Volts

Minimum DC Tuning Voltage .................................. 0 Volts

NOTE: Care should always be taken to

effectively ground the case of each unit.

VSWR

Harmonics (dBc)

Frequency Pushing

Frequency Pulling

Temperature Drift

Storage Temperature

Supply Power DC

Spectrum Microwave CROs produce impressive fre-

quency stability and phase noise when used in a prop-

erly designed oscillator circuit. The units can be voltage

tuned with a varactor over 5% bandwidth and still retain

excellent stability and phase noise performance.

Mechanical Outline

Spectrum Microwave · 2144 Franklin Drive N.E. · Palm Bay, Florida 32905 · PH (888) 553-7531 · Fax (888) 553-7532

Rev.

3/6/08

www.SpectrumMicrowave.com

Spectrum Microwave · 2707 Black Lake Place · Philadelphia, Pennsylvania 19154 · PH (215) 464-4000 · Fax (215) 464-4001
