The SGA2286Z is a high performance SiGe HBT MMIC Amplifier. A Darlington con-
figuration featuring one-micron emitters provides high F
T
and excellent thermal per-
formance. The heterojunction increases breakdown voltage and minimizes leakage
current between junctions. Cancellation of emitter junction non-linearities results in
higher suppression of intermodulation products. Only two DC-blocking capacitors, a
bias resistor, and an optional RF choke are required for operation.
Features
High Gain: 14dB at 1950MHz
Cascadable 50Ω
Operates from Single Supply
Low Thermal Resistance
Package
PA Driver Amplifier
Cellular, PCS, GSM, UMTS
IF Amplifier
Wireless Data, Satellite
Applications
Optimum Technology
Matching® Applied
GaAs HBT
GaAs MESFET
Gain (dB)
24
Gain & Return Loss vs. Freq. @T
L
=+25°C
0
InGaP HBT
SiGe BiCMOS
Si BiCMOS
GAIN
IRL
ORL
Return Loss (dB)
18
-10
12
-20
SiGe HBT
GaAs pHEMT
Si CMOS
Si BJT
GaN HEMT
RF MEMS
6
-30
0
0
1
2
3
Frequency (GHz)
4
5
-40
Parameter
Small Signal Gain
Min.
13.5
Specification
Typ.
15.0
14.0
12.6
8.3
7.0
20.0
19.4
5000
Max.
16.5
Unit
dB
dB
dB
dBm
dBm
dBm
dBm
MHz
850MHz
1950MHz
2400MHz
850MHz
1950MHz
850MHz
1950MHz
Condition
Output Power at 1dB Compression
Output Third Intercept Point
Bandwidth Determined by Return
Loss (>10dB)
Input Return Loss
16.8
dB
1950MHz
Output Return Loss
19.5
dB
1950MHz
Noise Figure
3.5
dB
1950MHz
Device Operating Voltage
1.9
2.2
2.5
V
Device Operating Current
17
20
23
mA
Thermal Resistance
97
°C/W
(Junction - Lead)
Test Conditions: V
S
=5V, I
D
=20mA Typ., OIP
3
Tone Spacing=1MHz, P
OUT
per tone=-10dBm, R
BIAS
=140Ω, T
L
=25°C, Z
S
=Z
L
=50Ω
