LBN140A80 Overview

140MHz SAW Filter

Preview

Download Datasheet

View All

China Electronics Technology Group Corporation

No.26 Research Institute

140MHz SAW Filter

13.1MHz Bandwidth

Part Number:LBN140A80

Number:LBN140A80

SIPAT Co., Ltd.

www.sipatsaw.com

Features

For IF SAW filter

High attenuation

Single-ended operation

Dual In-line Package

No matching required for operation at 50Ω

RoHS compliant (2002/95/EC), Pb-free

Specifications

Parameter

Center Frequency

Insertion Loss

3dB Bandwidth

35dB Bandwidth

45dB Bandwidth

50dB Bandwidth

53dB Bandwidth

Passband Variation

Absolute Delay

Ultimate Rejection(f0±21MHz)

Material Temperature coefficient

Substrate Material

Ambient Temperature

Operating Temperature Range

Storage Temperature Range

Input Power

ESD Class

Package Size

Notes:

All specifications are based on the test circuit shown;

In production, all specifications are measured by Agilent Network analyzer and full 2 port calibration at room

temperature;

Electrical margin has been built into the design to account for the variations due to temperature drift and

manufacturing tolerances;

This is the optimum impedance in order to achieve the performance show.

Unit

MHz

usec

KHz/°C

°C

dBm

Minimum

139.85

13.1

Typical

140

23.4

13.16

13.93

14.03

14.08

14.10

1.1

3.25

-13.16

YZ-LN

Maximum

140.15

14.0

14.2

15.2

23.2

1.5

4.0

-25

-45

+85

+105

DIP3512 (35.0*12.8*4.7mm3)

SIPAT Co., Ltd.

( CETC No.26 Research Institute )

#14 Nanping Huayuan Road,

Chongqing, China, 400060

Tel: +86-23-62808818

Phone: +86-23-62920684

Part Number

Rev. Date

Ver.

LBN140A80

2013-01-18

1.0

Page

1/3

Fax: +86-23-62808382

Fax: +86-23-62805284

www.sipatsaw.com / sales@sipat.com

www.sipatsaw.com / sawmkt@sipat.com
