INCHANGE Semiconductor
isc
Product Specification
isc N-Channel Mosfet Transistor
·
FEATURES
·Drain
Current –I
D
= 8A@ T
C
=25℃
·Drain
Source Voltage-
: V
DSS
= 650V(Min)
·Static
Drain-Source On-Resistance
: R
DS(on)
= 1.4Ω(Max)
·Avalanche
Energy Specified
·Fast
Switching
·Simple
Drive Requirements
·
DESCRITION
·Designed
for high efficiency switch mode power supply
·PWM
motor controls
·High
efficient DC to DC converters
8N65
·
ABSOLUTE MAXIMUM RATINGS(T
a
=25℃)
℃
SYMBOL
V
DSS
V
GS
I
D
I
DM
P
D
T
j
T
stg
PARAMETER
Drain-Source Voltage
Gate-Source Voltage-Continuous
Drain Current-Continuous
Drain Current-Single Plused
Total Dissipation @T
C
=25℃
Max. Operating Junction Temperature
Storage Temperature
VALUE
650
±30
8
30
147
150
-55~150
UNIT
V
V
A
A
W
℃
℃
·
THERMAL CHARACTERISTICS
SYMBOL
R
th j-c
R
th j-a
PARAMETER
Thermal Resistance, Junction to Case
Thermal Resistance, Junction to Ambient
MAX
0.85
62.5
UNIT
℃/W
℃/W
isc website：
www.iscsemi.com
：
1
isc
&
iscsemi
is registered trademark
INCHANGE Semiconductor
isc
Product Specification
isc N-Channel Mosfet Transistor
ELECTRICAL CHARACTERISTICS
T
C
=25℃ unless otherwise specified
℃
SYMBOL
PARAMETER
CONDITIONS
MIN
8N65
MAX
UNIT
V
(BR)DSS
Drain-Source Breakdown Voltage
V
GS
= 0; I
D
= 0.25mA
650
V
V
GS
(th
)
R
DS(
on
)
I
GSS
Gate Threshold Voltage
V
DS
= V
GS
; I
D
= 0.25mA
2
4
V
Ω
Drain-Source On-Resistance
V
GS
= 10V; I
D
= 4A
V
GS
=
±30V;
V
DS
= 0
1.4
±100
Gate-Body Leakage Current
nA
μA
I
DSS
Zero Gate Voltage Drain Current
V
DS
= 650V; V
GS
= 0
10
V
SD
Forward On-Voltage
I
S
= 8A; V
GS
= 0
1.4
V
·
isc website：
www.iscsemi.com
：
2
isc
&
iscsemi
is registered trademark
