DB201 THRU DB207
SINGLE-PHASE GLASS PASSIVATED SILICON BRIDGE RECTIFIER
REVERSE VOLTAGE:
FORWARD CURRENT:
FEATURES
· Glass passivated chip junction
· Low forward voltage drop
· High surge overload rating of 50 Amperes peak
· Ideal for printed circuit board
· High temperature soldering guaranteed:
260°C for 10 seconds
50 to 1000 VOLTS
2.0 AMPERE
DB
MECHANICAL DATA
Case: Molded plastic, DB
Epoxy: UL 94V-O rate flame retardant
Terminals: Leads solderable per MIL-STD-202,
method 208 guaranteed
Mounting position: Any
Weight: 0.02ounce, 0.4gram
Dimensions in inches and (millimeters)
Maximum Ratings and Electrical Characteristics
Ratings at 25
ambient temperature unless otherwise specified.
Single phase, half wave, 60H
Z
, resistive or inductive load.
For capacitive load, derate current by 20%.
Symbols
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward
Rectified Current at T
A
=40
Peak Forward Surge Current,
8.3ms single half-sine-wave
superimposed on rated load (JEDEC method)
Maximum Forward Voltage
at 1.0A DC and 25
Maximum Reverse Current
at Rated DC Blocking Voltage
at T
A
=25
T
A
=125
I
R
C
J
R
R
T
J
JA
JL
DB201
DB202
DB203
DB204
DB205
DB206
DB207
Units
Volts
Volts
Volts
Amp
V
RRM
V
RMS
V
DC
I
(AV)
50
35
50
100
70
100
200
140
200
400
280
400
2.0
600
420
600
800
560
800
1000
700
1000
I
FSM
60
Amp
V
F
1.1
5.0
500
25
40
15
-55 to +150
Volts
uAmp
pF
/W
/W
Typical Junction Capacitance (Note 1)
Typical Thermal Resistance (Note 2)
Typical Thermal Resistance (Note 2)
Operating and Storage Temperature Range
Tstg
NOTES:
1- Measured at 1 MH
Z
and applied reverse voltage of 4.0 VDC.
2- Thermal resistance from junction to ambient and from junction to lead mounted on P.C.B. with 0.5 x 0.5" (13 x 13mm) copper pads
