3DC11LP
SMD 3D Coil 13x11.6x3.15 mm MAX (2.38 mH – 7.2 mH) Low pro le
3-Axes Transponder Inductor (3DCoils)
Characteristics
- Offers 3 coils, oriented in the 3 space axes, assembled in a single component with
full functionality.
- Suitable for automotive applications (Keyless Entry Systems, RTPMS), etc.
- Very good electrical performance in the smallest dimensions.
- High stability in temperature (-40ºC to +85ºC).
- High sensitivity values.
- The inductivity in each axis can be customized to achieve customer requirements.
- Designs at lower frequencies, 20 kHz or 40 kHz, show
a very good electrical performance as well.
Dimensions and recommended pad layout
Pins coplanarity 0.15mm
All dimensions in mm
Tolerances unless otherwise speci ed: ±0.20mm
Electrical speci cations
P/N
3DC11LP-0238J
3DC11LP-0247J
3DC11LP-0345J
3DC11LP-0405J
3DC11LP-0477J
3DC11LP-0491J
3DC11LP-0720J
L
SRFx,y SRFz DCRx,y DCRz Sensitivity x,y,z
Qx,y,z Freq Cres
Length Width Height
x,y,z
(kHz) (kHz) (Ohm) (Ohm) (mV/App/m)
Min (KHz) (pF)
(mm) (mm) (mm)
(mH)
Min Min
Max Max
Min
2.38
2.47
3.45
4.05
4.77
4.91
7.20
25
25
29
30
30
32
25
125
125
125
125
125
125
125
680
656
470
400
340
330
225
500
500
400
400
370
350
330
900
800
800
600
600
600
500
50
50
60
67
70
74
84
50
50
70
67
96
98
120
40
50
55
60
65
65
72
13
13
13
13
13
13
13
11,6
11,6
11,6
11,6
11,6
11,6
11,6
3,15
3,15
3,15
3,15
3,15
3,15
3,15
This chart is a reference guide for the most common required values at working frequency of 125 kHz. Any other inductance value
at LF or tighter tolerances can be provided. Also can be supplied different inductance values in the different winding axis. Please
contact our sales department for any inquiry.
L and Q factor measured at 125 kHz, 1 Vac.
Sensitivity measured with Helmholtz coils H=8.36 App/m @125 kHz. Contact us for measurement speci cation.
SRF: Self Resonant Frequency of the coil.
