Ordering number : EN3614A
Schottky Barrier Diode
SB05-03C
30V, 500mA Rectifier
Applications
• Universal-use rectifier.
• High frequency rectification (switching regulators, converters, choppers).
Features
• Low forward voltage (VF max=0.55V).
• Fast reverse recovery time (trr max=10ns).
• Low switching noise
• Low leakage current and high reliability due to highly reliable planar structure.
• Small-sized package, permitting applied sets to be compact and slim.
Absolute Maximum Ratings
at Ta=25°C
Repetitive Peak Reverse Voltage
Nonrepetitive Peak Reverse
Surge Voltage
Average Output Current
Surge Forward Current
Junction Temperature
Storage Temperature
VRRM
VRSM
Io
IFSM
Tj
Tstg
30
35
500
5
–55 to +125
–55 to +125
min
30
typ
unit
V
V
mA
A
°C
°C
max
0.55
30
unit
V
V
µA
pF
ns
°C/W
50Hz sine wave, 1 cycle
Electrical Characteristics
at Ta=25°C
Reverse Voltage
Forward Voltage
Reverse Current
Interterminal Capacitance
Reverse Recovery Time
Thermal Resistance
Marking : Q
VR
VF
IR
C
trr
Rthj-a
IR=150µA
IF=500mA
VR=15V
VR=10V, f=1MHz
IF=IR=100mA,
See specified Test Circuit.
16
10
560
trr Test Circuit
Package Dimensions
1148A
(unit : mm)
SANYO Electric Co.,Ltd. Semiconductor Bussiness Headquarters
TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110 JAPAN
61197GI/N120MH (KOTO) No.3614-1/2
SB05-03C
No products described or contained herein are intended for use in surgical implants, life-support systems,
aerospace equipment, nuclear power control systems, vehicles, disaster/crime-prevention equipment and
the like, the failure of which may directly or indirectly cause injury, death or property lose.
Anyone purchasing any products described or contained herein for an above-mentioned use shall:
Accept full responsibility and indemnify and defend SANYO ELECTRIC CO., LTD., its affiliates,
subsidiaries and distributors and all their officers and employees, jointly and severally, against any
and all claims and litigation and all damages, cost and expenses associated with such use:
Not impose any responsibilty for any fault or negligence which may be cited in any such claim or
litigation on SANYO ELECTRIC CO., LTD., its affiliates, subsidiaries and distributors or any of
their officers and employees jointly or severally.
Information (including circuit diagrams and circuit parameters) herein is for example only; it is not guarant-
eed for volume production. SANYO believes information herein is accurate and reliable, but no guarantees
are made or implied regarding its use or any infringements of intellectual property rights or other rights of
third parties.
This catalog provides information as of June, 1997. Specifications and information herein are subject to
change without notice.
No.3614-2/2
