LTC2053IDD Overview

INSTRUMENTATION AMPLIFIER, 20 uV OFFSET-MAX, PDSO8

LTC2053IDD Parametric

Parameter Name	Attribute value
Brand Name	Linear Technology
Is it Rohs certified?	incompatible
Maker	Linear ( ADI )
Parts packaging code	DFN
package instruction	VSON, SOLCC8,.11,20
Contacts	8
Manufacturer packaging code	DD
Reach Compliance Code	_compli
ECCN code	EAR99
Amplifier type	INSTRUMENTATION AMPLIFIER
Maximum average bias current (IIB)	0.01 µA
Minimum Common Mode Rejection Ratio	95 dB
Maximum input offset current (IIO)	0.003 µA
Maximum input offset voltage	20 µV
JESD-30 code	S-PDSO-N8
JESD-609 code	e0
length	3 mm
Humidity sensitivity level	1
Negative supply voltage upper limit	-5.5 V
Nominal Negative Supply Voltage (Vsup)	-5 V
maximum nonlinearity	0.001%
Number of functions	1
Number of terminals	8
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	VSON
Encapsulate equivalent code	SOLCC8,.11,20
Package shape	SQUARE
Package form	SMALL OUTLINE, VERY THIN PROFILE
Peak Reflow Temperature (Celsius)	235
power supply	3/5/+-5 V
Certification status	Not Qualified
Maximum seat height	0.8 mm
Nominal slew rate	0.2 V/us
Maximum slew rate	1.3 mA
Supply voltage upper limit	5.5 V
Nominal supply voltage (Vsup)	5 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	NO LEAD
Terminal pitch	0.5 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	20
width	3 mm

Preview

Download Datasheet

View All

LTC2053

Precision, Rail-to-Rail

Input and Output, Zero-Drift Instrumentation

Amplifier with Resistor-Programmable Gain

FEATURES

DESCRIPTIO

116dB CMRR Independent of Gain

Maximum Offset Voltage: 10µV

Maximum Offset Voltage Drift: 50nV/°C

Rail-to-Rail Input

Rail-to-Rail Output

2-Resistor Programmable Gain

Supply Operation: 2.7V to

±5.5V

Typical Noise: 2.5µV

P-P

(0.01Hz to 10Hz)

Typical Supply Current: 750µA

Available in an MS8 and 3mm

3mm

0.8mm

DFN Packages

The LTC

2053 is a high precision instrumentation ampli-

fier. The CMRR is typically 116dB with a single or dual 5V

supply and is independent of gain. The input offset voltage

is guaranteed below 10µV with a temperature drift of less

than 50nV/°C. The LTC2053 is easy to use; the gain is

adjustable with two external resistors, like a traditional

op amp.

The LTC2053 uses charge balanced sampled data tech-

niques to convert a differential input voltage into a single

ended signal that is in turn amplified by a zero-drift

operational amplifier.

The differential inputs operate from rail-to-rail and the

single ended output swings from rail-to-rail. The LTC2053

can be used in single supply applications, as low as 2.7V.

It can also be used with dual

±5.5V

supplies. The LTC2053

is available in an MS8 surface mount package. For space

limited applications, the LTC2053 is available in a

3mm

0.8mm dual fine pitch leadless package

(DFN).

, LTC and LT are registered trademarks of Linear Technology Corporation.

APPLICATIO S

Thermocouple Amplifiers

Electronic Scales

Medical Instrumentation

Strain Gauge Amplifiers

High Resolution Data Acquisition

TYPICAL APPLICATIO

Differential Bridge Amplifier

0.1µF

R < 10k

INPUT OFFSET VOLTAGE (µV)

Typical Input Referred Offset vs Input

Common Mode Voltage (V

= 3V)

–5

G = 10

–10

G=1

–15

2053 TA01

= 3V

REF

= 0V

= 25°C

–

LTC2053

1, 4

GAIN = 1+

0.1µF

10Ω

R2 10k

OUT

1.0

1.5

2.0

2.5

0.5

INPUT COMMON MODE VOLTAGE (V)

G = 1000

G = 100

3.0

2053 G01

2053fa
