Solid Tantalum Chip Capacitors T
ANTAMOUNT
™,
Low Profile, Low ESR, Conformal Coated, Maximum CV
FEATURES
• New robust ratings for pulsed applications
• New case size offerings
• 1.2 mm to 2 mm height
• Terminations: 100 % matte tin (2) standard,
tin / lead available
• Very low ESR
Available
Available
Available
LINKS TO ADDITIONAL RESOURCES
• 8 mm, 12 mm tape and reel packaging available per
EIA-481 and reeling per IEC 60286-3
7" [178 mm] standard
13" [330 mm] available
• Footprint compatible with EIA 535BAAC and CECC 30801
D
D
3
3
3D Models
Parametric
Search
Calculators
PERFORMANCE CHARACTERISTICS
www.vishay.com/doc?40194
Operating Temperature:
-55 °C to +125 °C
(above 85 °C, voltage derating is required)
Capacitance Range:
1 μF to 1000 μF
Capacitance Tolerance:
± 10 %, ± 20 % standard
Voltage Rating:
4 V
DC
to 50 V
DC
Moisture Sensitivity Level 2a
• See also 592W for additional ratings designs for pulsed
applications
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
Note
*
This datasheet provides information about parts that are
RoHS-compliant and / or parts that are non RoHS-compliant. For
example, parts with lead (Pb) terminations are not RoHS-compliant.
Please see the information / tables in this datasheet for details
ORDERING INFORMATION
591D
TYPE
106
CAPACITANCE
X0
CAPACITANCE
TOLERANCE
X0 = ± 20 %
X9 = ± 10 %
010
DC VOLTAGE RATING
AT +85 °C
This is expressed in
volts. To complete the
three-digit block, zeros
precede the voltage
rating. A decimal point
is indicated by an “R”
(6R3 = 6.3 V).
B
CASE
CODE
See
Ratings
and Case
Codes
table
2
TERMINATION
T
REEL SIZE AND
PACKAGING
T = tape and reel
7" [178 mm] reel
W = 13" [330 mm] reel
15H
SUFFIX
This is expressed
in picofarads. The
first two digits are
the significant
figures. The third
is the number of
zeros to follow.
2 = 100 % tin
4 = gold plated
8 = solder
plated 60/40
Special order
Maximum
height (mm)
see
Standard
Ratings
table
Notes
• Preferred tolerance and reel sizes are in bold.
We reserve the right to supply higher voltage ratings and tighter capacitance tolerance capacitors in the same case size
• Low ESR solid tantalum chip capacitors allow delta ESR of 1.25 times the datasheet limits after mounting
Revision: 30-Aug-2021
Document Number: 40012
1
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
591D
www.vishay.com
Vishay Sprague
DIMENSIONS
in inches [millimeters]
Tantalum wire
nib identifies
anode (+)
terminal
W
L
MAX.
D
REF.
A
B
J
MAX.
H
(1)
J
MAX.
CASE CODE
A
B
C
D
M
R
L MAX.
0.146 [3.7]
0.157 [4.0]
0.28 [7.1]
0.295 [7.5]
0.295 [7.5]
0.283 [7.2]
W
0.071 ± 0.012
[1.8 ± 0.3]
0.110 + 0.012 / - 0.024
[2.8 + 0.3 / - 0.6]
0.126 ± 0.012
[3.2 ± 0.3]
0.169 ± 0.012
[4.3 ± 0.3]
0.248 ± 0.012
[6.3 ± 0.3]
0.236 + 0.012 / - 0.024
[6.0 + 0.3 / - 0.6]
A
0.031 ± 0.012
[0.8 ± 0.3]
0.031 ± 0.012
[0.8 ± 0.3]
0.051 ± 0.012
[1.3 ± 0.3]
0.051 ± 0.012
[1.3 ± 0.3]
0.051 ± 0.012
[1.3 ± 0.3]
0.051 ± 0.012
[1.3 ± 0.3]
B
0.087 ± 0.016
[2.2 ± 0.4]
0.098 ± 0.016
[2.5 ± 0.4]
0.173 ± 0.024
[4.4 ± 0.6]
0.181 ± 0.024
[4.6 ± 0.6]
0.200 ± 0.024
[5.1 ± 0.6]
0.181 ± 0.024
[4.6 ± 0.6]
D REF.
0.114 [2.9]
0.138 [3.5]
0.236 [6.0]
0.252 [6.4]
0.264 [6.7]
0.244 [6.2]
J MAX.
0.004 [0.1]
0.004 [0.1]
0.004 [0.1]
0.004 [0.1]
0.004 [0.1]
0.004 [0.1]
Notes
• The anode termination (D less B) will be a minimum of 0.012" [0.3 mm]
(1)
For package height, please refer to specific rating in the “Standard Ratings” table
RATINGS AND CASE CODES
μF
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
120
150
220
330
470
680
1000
1500
C/R
C/D
C/D
C/D/R
D/R
R
A/B
B
B/C
B/C/D
D/R
A
A/B
A/B
A/B/C
B/C/D
D/R
B/C/D/R
C
C/D/R
C/D/R
C/D/R
C/D/R
R
R
M/R
C/D
D/R
D/R
D/R
R
A
A
A/B
B
A/B/C
C/D
D/R
C/D/R
B/C/D
A
A/B
B/C
B/D
C/D
C/D/R
C/R
C/D
C/D
R
A/B
B/C
B/D
C
D/R
R
C
D
R
A
A/B
B/C
C
C/D
B/D/R
R
4V
6.3 V
10 V
16 V
20 V
25 V
35 V
A/B
B
B/C
B/C/D
B
D/R
R
C
50 V
B
