DR360 SERIES, HIGH CURRENT, HIGH TEMPERATURE INDUCTORS
Features
Low EMI
High Current Capacity
Operating Temp. -55°C to +200°C
Horizontal or Vertical mount
(Note 5)
Tinned Leads with Leaded Solder is Available
(note 7)
NOTES
Part
Number
DR360-X-122
DR360-X-182
DR360-X-272
DR360-X-392
DR360-X-472
DR360-X-562
DR360-X-682
DR360-X-822
DR360-X-103
DR360-X-123
DR360-X-153
DR360-X-183
DR360-X-223
DR360-X-273
DR360-X-333
DR360-X-393
DR360-X-473
DR360-X-563
DR360-X-683
DR360-X-823
DR360-X-104
DR360-X-124
DR360-X-154
DR360-X-184
DR360-X-224
DR360-X-274
DR360-X-334
DR360-X-394
DR360-X-474
DR360-X-564
DR360-X-684
DR360-X-824
DR360-X-105
L(µH)
±15% (1)
1.2
1.8
2.7
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
L(µH)±15%
@ I rated
(2)
1.0
1.5
2.2
3.1
3.7
4.3
5.1
6.0
7.2
8.5
10.3
12.2
14.5
19.2
23.0
26.7
34.7
40.8
48.5
57.4
68.3
80.5
97.9
114.5
136.6
163.2
218.3
252.8
297.9
389.1
461.4
545.2
648.2
Idc
(A)
38.7
34.6
31.6
29.2
27.3
25.8
24.5
24.3
23.3
22.4
20.8
20.2
19.0
14.3
13.6
13.0
10.0
9.7
9.2
8.8
8.3
8.0
7.5
7.2
6.8
6.5
4.9
4.7
4.5
3.4
3.2
3.1
2.9
DCR (Ω)
(MAX)
0.002
0.003
0.003
0.004
0.004
0.005
0.005
0.005
0.006
0.006
0.007
0.007
0.008
0.014
0.015
0.017
0.028
0.030
0.034
0.037
0.041
0.045
0.050
0.055
0.061
0.067
0.10
0.13
0.14
0.24
0.27
0.30
0.33
Dim.
A
Nom.
0.56
0.56
0.56
0.56
0.56
0.56
0.56
0.56
0.56
0.56
0.56
0.56
0.56
0.53
0.53
0.53
0.52
0.52
0.52
0.52
0.56
0.56
0.56
0.56
0.56
0.56
0.54
0.54
0.54
0.53
0.53
0.53
0.58
Dim.
B
Nom.
1.18
1.18
1.18
1.18
1.18
1.18
1.18
1.18
1.18
1.18
1.18
1.18
1.18
1.14
1.14
1.14
1.13
1.13
1.13
1.13
1.17
1.17
1.17
1.17
1.17
1.17
1.16
1.16
1.16
1.14
1.14
1.14
1.17
Dim.
C
Nom.
0.066
0.066
0.066
0.066
0.066
0.066
0.066
0.066
0.066
0.066
0.066
0.066
0.066
0.053
0.053
0.053
0.042
0.042
0.042
0.042
0.042
0.042
0.042
0.042
0.042
0.042
0.037
0.037
0.037
0.027
0.027
0.027
0.027
(1)
OCL measured at .25VRMS, 1kHz.
(2)
Rated Current tested at .25VRMS, 1kHz
(3)
All materials are rated at 200ºC
(4)
Electrical Specifications at 25°C
(5)
DR360-2-XXX denotes vertical design.
DR360-1-XXX denotes
horizontal design
(6)
All dimensions are shown in
inches “in”. General tolerance is ±0.010in,
unless otherwise specified.
(7)
For non-RoHS parts replace DR
prefix with 42- (e.g. DR360 becomes
42-360)
(8)
Terminal finish is compliant to
RoHS requirements
.
.50 .02
u
1.280
MAX
1
B
C
0.65
MAX
0.65
MAX
1.28
MAX
2
Schematic
.50 .02
u
C
Vertical
DR360-2-XXX
A
Horizontal
DR360-1-XXX
DATATRONIC
:
28151 Highway 74, Romoland, CA 92585 Tel: 951-928-7700 Toll Free Tel: 888-889-5391 Fax: 951-928-7701
Email: ddisales@datatronics.com
499 King’s Road, Hong KongTel: (852) 2562 3858, (852) 2564 8477 Fax: (852) 2565 7214, (852) 2563 1290
All specifications are subject to change without notice.
