SHEET 1 OF 1
n
22.00
[.866 in]
n
13.40
n
15.50 ILLUMINATED RING
[.610 in]
[.528 in]
n
19.00
[.748 in]
PANEL CUTOUT
MAX. PANEL THICKNESS
11.0mm [.433]
ACTUATOR FINISH
MACHINED STAINLESS
FLAT ACTUATOR
BODY FINISH
MACHINED STAINLESS
2.00
[.079 in]
NOTE 15
HARDWARE
SUPPLIED
M19x1.0
SWITCH FUNCTION
POS. 1
POS. 2
ON
1-3, 4-6
ON
1-2, 4-5
28.50
`
.50
[1.122
`
.020
in]
37.00
`
.50
[1.457
`
.020
in]
36.00
`
.50
[1.417
`
.020
in]
(-)
4
1
(+)
1
3
1
3
2
6
5
RED
+
NOTE:
1. ALL DIMENSIONS IN mm [INCH]
2. GENERAL TOLERANCE: X.X=±0.4
X.XX=±0.25
3. TERMINAL NUMBERS FOR REF ONLY
4. CONTACT MATERIAL: SILVER
5. RATING: 2A 48VDC
6. ELECTRIC LIFE: 50,000 MAKE-AND-BREAK CYCLES
AT FULL LOAD.
7. INSULATION RESISTANCE: 1,000 M MIN.
8. DIELECTRIC STRENGTH: 2,000 VAC MIN. FOR 1 MINUTE
9. CONTACT RESISTANCE: 50m MAX. @ 1A 12VDC
10. OPERATING TEMP.: -20° to 55°C
C
11. TRAVEL: 2.8mm
12. DENOTES CRITICAL PARAMETER.
13. LAMP VOLTAGE: 12V
14. INGRESS PROTECTION: IP65
15. HARDWARE SUPPLIED: O-RING AND HEXNUT
16. ILLUMINATION COLOR: RED
.50
[.020 in]
4
5
C
(-)
2.60
[.102 in]
1
2
(+)
_
1
4
4
NO
NC
6
3
DPDT
CONTACT CONFIGURATION
A
REV
21230
PCR NO
INITIAL RELEASE
DESCRIPTION
9/11/13
DATE
EBP
BY
TITLE
SCALE
PV4F2G0SS-314
NONE
DATE
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
9/11/2013
DR
EBP
DWG
52-PV4F2G0SS314
REV
A
