Green
100GHz Compact Fiber
Optical Interleaver
CFOI100 Series
Product Description
Oplink’s compact, low-dispersion interleavers greatly expand wavelength
channel counts in DWDM systems. Oplink’s DWDM interleavers feature
excellent wide, flat passbands and high isolation. Both mux and demux func-
tions are supported. Interleavers are athermal and do not require tempera-
ture control.
Performance Specificationns
CFOI100 Series
Min
Typical
Max
Unit
Features
Center Wavelength Range
Center Frequency Range
Channel Center Wavelength
Input Channel Spacing
Output Channel Spacing
Clear Bandwidth
Insertion Loss
[1]
Ripple
Insertion Loss Uniformity
Adjacent Channel Isolation
C-Band
L-Band
C-Band
L-Band
1529.55
1569.59
192000
186900
ITU Grid
100
200
± 15
1.2
0.2
0.3
23
25
0.2
0.2
- 20
40
50
45
55
1561.42
1604.03
196000
191000
nm
nm
Ghz
GHz
GHz
GHz
GHz
Low Insertion Loss
High Isolation
Low Dispersion
Highly Stable & Reliable
Epoxy-Free Optical Path
Compact Size
Completely Passive
Athermal Design
1.8
0.4
0.5
0.3
0.3
+ 20
dB
dB
dB
dB
dB
ps
ps/nm
dB
dB
Applications
Polarization Dependent Loss (PDL)
Polarization Mode Dispersion (PMD)
Chromatic Dispersion
Return Loss
Directivity
Operating Power Handling
Operating Temperature
Storage Temperature
Fiber Type
Package Dimensions
[3]
DWDM Systems
Extend Network Capacity
24
0 to +65
-40 to +85
G.657.A1 or equivalent
100.5 (L) x 60.0 (W) x10.3 (H)
dBm
°C
°C
mm
Note:
[1] The maximum IL is under all states of polarization and within the full operating temperature and wave-
length ranges specified.
[2] All spec excluding connectors
[3] The mechanical tolerance should be +/-0.2mm on all package dimensions unless otherwise custom specified.
S0460 - R01. (web) 20140711
100GHz Compact Fiber Optical Interleaver
CFOI100 Series
Mechanical Drawing / Package Dimensions (dimension in mm)
46335 Landing Pkwy Fremont, CA 94538 Tel: (510) 933-7200 Fax: (510) 933-7300 Email: Sales@Oplink.com • www.oplink.com
Ordering Information
Oplink can provide a remarkable range of customized optical solutions. For detail, please contact Oplink’s OEM
design team or account manager for your requirements and ordering information (510) 933-7200.
CFOI
1
0
0
2
0
0
E
Input
100GHz = 100
Output
200GHz = 200
Band
C band = C
H band = H
L band = L
Fiber Length
0.5 Meter = H
1.0 Meter = 1*
1.5 Meters = 5
2.0 Meters = 2
Connector Type
None = 1
FC/PC = 2
FC/SPC = 3
FC/APC = 4
SC/PC = 5
SC/SPC = 6
SC/APC = 7
ST = 8
LC/PC = 9
MU = A
LC/APC = B
Fiber Jacket
250μm Bare Fiber = 1
900μm Loose Tube = 2
* The tolerance of fiber length is +/-0.1m. 1 meter is standard. The lead-time for special fiber length will be longer.
S0460 - R01. (web) 20140711
Product Lines:
Mux/Demux
Switching/Routing
Coupling/Splitting
Monitoring/Conditioning
Amplification
Interconnect
Transmission
HFC/RoF Subsystem
Analog electronics
