12,15
8,95
Ansaughaube
5,85
4,6
Verpackt in Gurtverpackung
Tape on Reel Packaging
Verpackungseinheit: 420 Stück
hood
1,5
Packaging unit: 420 pcs
2,75
7,95
5,8
7,3
11
0,65
0,5
0,6
0,8
3,675
330
Abspulrichtung -
Reel off Direction
12,15
ohne Angsaughaube
without hood
a1
16
a1
4x2=8
Leiterplatten-Layout Vorschlag /
PCB-Layout Proposal
11
±0,03
0,85
3
1)
0,9
±0,03
3x3=9
0,8
1)
0,65
0,7
±0,03
Anschlussbereich verzinnt 4-6 µm
Kontaktbereich vergoldet
Anforderungsstufe 1
Performance Level 1
Mating Area gold plating
Terminal Area 4-6 µm tin plating
0,75
Koplanarität der Anschlüsse
≤
0,1 mm
4,45
2,6
Coplanarity Area of Termination
≤
0,1 mm
Copyright by ERNI GmbH
Proprietary notice pursuant to ISO 16016 to be observed.
32
a5
2
Information:
Tolerances
All Dimensions
in mm
Scale
5:1
0,8
2
1,5
4x2=8
0,85
All rights reserved.
Only for Information.
To ensure that this is the latest
version of this drawing, please
contact one of the ERNI companies
before using.
k
Index
06.09.2012
Date
Designation
Subject to modification without
prior notice.
Drawing will not be updated.
Messerleiste SMD, Powerm. 2mm
Male Con. SMD, Powerm. 2mm
www.ERNI.com
Class
1.) Durchmessser des Bohrers /
Drill tool
100100630001
MSPEED
K
A3
Embedded System
