AC Film Capacitors
Lighting
B 32436
Construction
Dielectric: polypropylene film
Aluminium can
Soft polyurethan resin
Internal dischage resistor
Overpressure disconnector
Features
Self-healing properties
Low dissipation factor
High insulation resisitance
Typical applications
For general sine wave applications,
mainly as series and parallel connection
lighting capacitors.
Terminals
Single tag 2,8 mm ; Push-in terminals
Mounting parts
Metal stud (max. torque = 5 Nm)
Technical data and specifications
Standard
Rated capacitance
C
N
Tolerance
Rated voltage
U
N
Rated frequency
f
N
Life expectance
Maximum ratings
Maximum permissible voltage
U
max
Maximum permissible current
I
max
Test data
AC test voltage terminal to terminal
U
TT
Insulation voltage terminals to case
Insulation resistance
R
is
or time constant
τ
at 20 °C
Rel. Humidity
≤
65 °C (minimum value)
Dissipation factor tanδ at 20 °C
Maximum rate of voltage rise du/dt
max
IEC /EN 61048/61049
3 .. 60 µF
±
5%,
±10%
250 ... 450 Vac
50...60Hz
10 years
1,1 x U
N
(U
N
: rated voltage)
1,3 x I
N
(I
N
: rated current)
2,0 x U
N
, 60 s
2000 Vac, 60 s.
3000 s
≤
1,0 x10
-3
(120 Hz)
10 V/µs
Issue No. 2
07/01
Page 1 of 5
AC Film Capacitors
Lighting
B 32436
Technical data (cont`d)
Climatic data
Climatic category
Lower category
T
min
Upper category
T
max
Damp heat test
t
test
Permitted capacitance
∆C/C
25/085/21
in accordance with IEC 60068-1
-25 °C
+85 °C
21 days
≤
3%
Note
:
1) It should be noted that presence of harmonics produces over voltage & over current on capacitors. Resonance may
cause serious damage to installation if a siginificant level of total harmonic distortion level exists for voltage or current.
In such cases, series reactors must be considered.
2) Operating temperature class: In accordance with the reference standards, these temperatures are those measured on
the surface on the capacitor
Issue No. 2
07/01
Page 2 of 5
AC Film Capacitors
Lighting
B 32436
Dimensional drawings
Issue No. 2
07/01
Page 3 of 5
AC Film Capacitors
Lighting
B 32436
Ordering codes and packing units
U
N
Vac
250
2
3
4
5
7
8
10
12
15
16
20
25
30
35
40
45
50
60
450
2
3
4
5
6
8
10
C
N
µF
Max. dimensions
d
x
l
(mm)
30 x 68
30 x 68
30 x 68
30 x 68
30 x 68
30 x 68
35 x 68
35 x 68
35 x 78
35 x 78
35 x 78
40 x 78
40 x 78
40 x 103
40 x 103
40 x 103
45 x 103
45 x 103
30 X 68
30 x 68
30 X 68
30 x 78
30 x 78
35 x 78
35 x 78
Ordering code
B32436-
Packing unit (pcs.)
112
112
112
112
112
112
84
84
84
84
84
45
45
45
45
45
45
45
112
112
112
112
112
84
84
A1205-+0*0
A1305-+0*0
A1405-+0*0
A1505-+0*0
A1705-+0*0
A1805-+0*0
A1106-+0*0
A1126-+0*0
A1156-+0*0
A1166-+0*0
A1206-+0*0
A1256-+0*0
A1306-+0*0
A1356-+0*0
A1406-+0*0
A1456-+0*0
A1506-+0*0
A1606-+0*0
A6205-+0*0
A6305-+0*0
A6405-+0*0
A6505-+0*0
A6605-+0*0
A6805-+0*0
A6106-+0*0
Notes for ordering code:
1) Replace * for terminals
3- Aluminum can with push-in
4- Aluminum can with push-in terminals and bolt
5- Aluminum can with solder tag
6- Aluminum can solder tag without resistor
7- Aluminum can solder tag with bolt
8- Aluminium can solder tag, bolt, and without resistor
M 8 fixing threaded bolt for
≤ φ
53mm.
Note- Push-in terminal available only upto 30
µ
f in 250 V.
2)
Replace + for capacitance tolerance: - J- ± 5%, K- ± 10%
Issue No. 2
07/01
Page 4 of 5
AC Film Capacitors
Lighting
B 32436
EPCOS AG 2000. All Rights Reserved. Reproduction, publication and dissemination of this data sheet, enclosures hereto
and the information contained therein without EPCOS' prior express consent is prohibited.
The information contained in this data sheet describes the type of component and shall not be considered as guaranteed
characteristics. Purchase orders are subject to the General Conditions for the Supply of Products and Services of the
Electrical and Electronics Industry recommended by the ZVEI (German Electrical and Electronic Manufacturers'
Association), unless otherwise agreed.
Issue No. 2
07/01
Page 5 of 5
