Ceramic
High Pass Filter
2410 to 6250 MHz
Maximum Ratings
Operating Temperature
Storage Temperature
RF Power Input*
-55°C to 100°C
-55°C to 100°C
7W max. at 25°C
EW!
N
HFCN-2000
Features
•
•
•
•
•
•
low cost
small size
7 sections
temperature stable
dc block in/out, breakdown voltage, 1kV typ.
excellent power handling, 7W
CASE STYLE: FV1206
Model
HFCN-2000
HFCN-2000D
Price
$1.99
$2.49
Qty.
(10-49)
(10-49)
*Passband rating, derate linearly to 3W at 100°C ambient.
Applications
Pin Connections
RF IN
RF OUT
GROUND
**RF IN & RF OUT can be interchanged
1**
3**
2,4
• sub-harmonic rejection and dc blocking
• transmitters/receivers
• lab use
High Pass Filter Electrical Specifications
1
(T
AMB
=25°C)
MODEL
NO.
STOP BAND
(MHz)
Min.
(loss>40 dB)
HFCN-2000
1300
(loss>20 dB)
1530
Outline Drawing
fco, MHz
Nom.
(loss 3 dB)
Typ.
2000
PASSBAND
(MHz)
(loss<1.3 dB)
Max.
2410-6000
(loss<2 dB)
Typ.
2260-6250
VSWR
Typ.
Stopband
20:1
POWER
INPUT
Frequency
(W)
(MHz)
1.5:1
2400-5600
7
1. For Applications requiring DC voltage to be applied to the Input or output, use HFCN-2000D (DC Resistance to
ground is 100 Mohms min.)
typical frequency response
ATTENUATION (dB)
schematic
RF IN
RF OUT
40dB
20dB
3dB
B
f co
FREQUENCY
f
1.3 dB
Typical Performance Data at 25°C
Frequency
(MHz)
1.00
504.00
1350.00
1560.00
1788.00
2000.00
2260.00
2410.00
3000.00
4060.00
4880.00
5830.00
6250.00
7350.00
9000.00
HFCN-2000
INSERTION LOSS
100
80
100
60
40
20
0
0
1000
2000
3000
4000
5000
6000
7000
8000
9000
FREQUENCY (MHz)
1000
Insertion Loss
(dB)
99.34
52.51
45.56
25.41
10.80
3.14
1.33
1.10
0.57
0.48
0.45
0.85
1.19
2.99
6.01
VSWR
(:1)
434.30
59.91
33.42
22.87
9.74
2.94
1.67
1.54
1.20
1.10
1.14
1.78
2.30
4.64
9.38
HFCN-2000
VSWR
Outline Dimensions (
inch
)
mm
A
.126
3.20
H
.087
2.21
B
.063
1.60
J
.024
0.61
C
.037
0.94
K
.122
3.10
D
.020
0.51
L
.024
0.61
E
.032
0.81
M
.087
2.21
F
.009
0.23
N
.012
0.30
G
.169
4.29
P
wt
.071 grams
1.80
.020
Demo Board MCL P/N: TB-270
Suggested PCB Layout (PL-137)
INSERTION LOSS (dB)
VSWR
10
1
0
1000
2000
3000
4000
5000
6000
7000
8000
9000
FREQUENCY (MHz)
designers kit available
Kit
No.
K1-HFCN
No. of
Units in Kit
40
Description
5 of each: HFCN-650,-740,-1200,-1500,-1760,
-2000,-2275,-2700
Price $
per Kit
79.95
Mini-Circuits
®
INTERNET
http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
Distribution Centers
NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010
Mini-Circuits
ISO 9001 & ISO 14001
Certified
NO. OF
SECTIONS
7
REV. C
M96263
EDR-6465/6
HFCN-2000
AD/RS/CP
050113
