RS1A, RS1B, RS1D, RS1G, RS1J, RS1K

www.vishay.com

Vishay General Semiconductor

Surface Mount Fast Switching Rectifier

FEATURES

• Low profile package

• Ideal for automated placement

• Glass passivated chip junction

• Fast switching for high efficiency

• High forward surge capability

• Meets MSL level 1, per J-STD-020, LF maximum peak of

260 °C

DO-214AC (SMA)

• AEC-Q101 qualified

• Material categorization: For definitions of compliance

please see

www.vishay.com/doc?99912

TYPICAL APPLICATIONS

For use in fast switching rectification of power supply,

inverters, converters, and freewheeling diodes for

consumer, automotive and telecommunication.

1.0 A

50 V, 100 V, 200 V, 400 V, 600 V,

800 V

30 A

150 ns, 250 ns, 500 ns

1.3 V

150 °C

DO-214AC (SMA)

Single die

PRIMARY CHARACTERISTICS

F(AV)

RRM

FSM

max.

Package

Diode variation

MECHANICAL DATA

Case:

DO-214AC (SMA)

Molding compound meets UL 94 V-0 flammability rating

Base P/N-E3 - RoHS-compliant, commercial grade

Base P/NHE3 - RoHS-compliant, AEC-Q101 qualified

Base P/NHE3_X - RoHS-compliant and AEC-Q101 qualified

(“_X” denotes revision code e.g. A, B, .....)

Terminals:

Matte tin plated leads, solderable per

J-STD-002 and JESD 22-B102

E3 suffix meets JESD 201 class 2 whisker test, HE3 suffix

meets JESD 201 class 2 whisker test

Polarity:

Color band denotes cathode end

MAXIMUM RATINGS

= 25 °C unless otherwise noted)

PARAMETER

Device marking code

Maximum repetitive peak reverse voltage

Maximum RMS voltage

Maximum DC blocking voltage

Maximum average forward rectified current at T

= 90 °C

Peak forward surge current 8.3 ms single half sine-wave

superimposed on rated load

Operating junction and storage temperature range

RRM

RMS

F(AV)

FSM

, T

STG

SYMBOL

RS1A

RS1B

100

RS1D

200

140

200

1.0

- 55 to + 150

RS1G

400

280

400

RS1J

600

420

600

RS1K

800

500

800

°C

UNIT

Revision: 21-Aug-13

Document Number: 88707
