MS52XX-C&T
SMD Pressure Sensor
SPECIFICATIONS
1, 4, and 7 bar absolute pressure range
Piezoresistive silicon micromachined sensor
Surface mount 6.2 x 6.4 mm
LCP plastic cap for easy connection
Uncompensated
Optional trimmed offset
Low noise, high sensitivity, high linearity
The MS52xxC&T SMD pressure sensor series is designed for
industrial pressure sensor systems with highest demands on
resolution, accuracy and reliability. The device consists of a silicon
micromachined pressure sensor die mounted on a 6.2 x 6.4 mm
ceramic carrier protected by a plastic cap. The MS52xxC&T SMD
can be delivered with many different sensitivities and linearities.
When you have a need, please feel free to ask us.
Full scale
pressure
1 bar
4 bar
7 bar
Untrimmed offset
Full
Product code scale
span
MS5201-CP
240 mV
MS5204-CP
225 mV
MS5207-CP
392 mV
Trimmed offset
Linearity
±0.15 % FS
±0.15 % FS
±0.15 % FS
Product code
MS5201-TP
MS5204-TP
Full scale
span
On request
225 mV
Offset at
1013 mbar
On request
17 mV
SENSOR SOLUTIONS
///MS52XX-C&T
06/2017
Page 1
MS52XX-C&T
SMD Pressure Sensor
FEATURES
Low cost SMD ceramic package
Small size
High reliability, low drift
-40 °C to +125 °C operation range
Trimmed offset available
Simple to interface with nozzle port
APPLICATIONS
Absolute pressure sensor systems
High resolution altimeters, variometers
Barometers
Engine controls
Industrial applications
Pressure monitoring systems
SENSOR SOLUTIONS
///MS52XX-C&T
06/2017
Page 2
MS52XX-C&T
SMD Pressure Sensor
PIN CONFIGURATION
3: VS+
4: OUT+
1: OUT-
2: GND
PIN DESCRIPTION
Pin Name
OUT-
GND
VS+
OUT+
Pin No
1
2
3
4
Function
Negative output voltage of Wheatstone bridge
Ground
Supply voltage of Wheatstone bridge
Positive output voltage of Wheatstone bridge
ABSOLUTE MAXIMUM RATINGS
Parameter
Supply voltage
Storage temperature
Overpressure MS5201-CP
MS5204-TP
MS5207-CP
Symbol
VS+
T
S
P
Conditions
Ta = 25 °C
Min
-
-40
Max
20
+125
5
21
21
Unit
V
°C
bar
Notes
Ta = 25 °C
1
NOTES
1) The MS52xx-C&T is aimed for air pressure applications. There is no gel protection on the silicon sensing
element.
SENSOR SOLUTIONS
///MS52XX-C&T
06/2017
Page 3
MS52XX-C&T
SMD Pressure Sensor
ELECTRICAL CHARACTERISTICS
UNTRIMMED VERSIONS
Parameter
Operating pressure range
Full-scale span (FS)
Sensitivity
Linearity
Operating pressure range
Full-scale span (FS)
Sensitivity
Linearity
Operating temperature range
Zero pressure offset
Pressure hysteresis
Temperature hysteresis
Repeatability
Bridge resistance
Temperature coefficient of resistance
Temperature coefficient of span
Temperature coefficient of offset
Min
0
190
190
-
0
322
46
-
-40
-40
-
-
-
3.0
+2'400
-1'500
-80
Typ
-
240
240
±0.15
-
392
56
±0.15
-
0
-
0.3
-
3.4
2'900
-1'900
-
Max
1
290
290
±0.4
7
462
66
±0.4
125
40
±0.20
0.8
±0.20
3.8
+3'300
-2'300
+80
(Vs+ = 5 V; Ta = 25 °C)
Unit
Notes
Bar
mV
mV/bar
% FS
1, 6
Bar
mV
mV/bar
% FS
1, 6
°C
mV
% FS
2, 6
% FS
3, 6
% FS
4, 6
kΩ
ppm/°C
5, 6
ppm/°C
5, 6
µV/°C
5, 6
MS5201-CP
MS5207-CP
All ranges
NOTES
1) Deviation at one half full-scale pressure from the least squares best line fit over pressure range.
2) Maximum difference of output voltage after 1 pressure cycle at any pressure within the operating pressure
range.
3) Maximum difference in offset after one thermal cycle from -40°C to +125°C.
4) Same as 2) after 10 pressure cycles.
5) Slope of the end-point straight line from 25°C to 60°C.
6) Not 100% tested.
SENSOR SOLUTIONS
///MS52XX-C&T
06/2017
Page 4
MS52XX-C&T
SMD Pressure Sensor
ELECTRICAL CHARACTERISTICS (CONT.)
TRIMMED VERSION
Parameter
Operating pressure range
Full-scale span (FS)
Sensitivity
Linearity
Operating temperature range
Pressure offset at 1013 mbar
Pressure hysteresis
Temperature hysteresis
Repeatability
Bridge resistance
Temperature coefficient of resistance
Temperature coefficient of span
Temperature coefficient of offset
Min
0
200
Typ
-
225
56
±0.15
-
17
-
0.3
-
3.4
2'900
-1'900
-
Max
4
250
±0.4
125
19
±0.20
0.8
±0.20
3.8
+3'300
-2'300
+80
(Vs+ = 5 V; Ta = 25 °C)
Unit
Notes
Bar
mV
mV/bar
% FS
1, 6
°C
mV
% FS
2, 6
% FS
3, 6
% FS
4, 6
kΩ
ppm/°C
5, 6
ppm/°C
5, 6
µV/°C
5, 6
MS5204-TP
-40
15
-
-
-
3.0
+2'400
-1'500
-80
NOTES
1) Deviation at one half full-scale pressure from the least squares best line fit over pressure range.
2) Maximum difference of output voltage after 1 pressure cycle at any pressure within the operating pressure
range.
3) Maximum difference in offset after one thermal cycle from -40°C to +125°C.
4) Same as 2) after 10 pressure cycles.
5) Slope of the end-point straight line from 25°C to 60°C.
6) Not 100% tested.
SENSOR SOLUTIONS
///MS52XX-C&T
06/2017
Page 5
