BSS123WQ

N-CHANNEL ENHANCEMENT MODE MOSFET

Product Summary

(BR)DSS

100V

DS(ON)

6.0Ω @ V

= 10V

= +25°C

170mA

Features and Benefits



Low Gate Threshold Voltage

Low Input Capacitance

Fast Switching Speed

Low Input/Output Leakage

High Drain-Source Voltage Rating

Totally Lead-Free & Fully RoHS compliant (Notes 1 & 2)

Halogen and Antimony Free. “Green” Device (Note 3)

Qualified to AEC-Q101 Standards for High Reliability

PPAP Capable (Note 4)

Description

This

MOSFET

designed

minimize

the

on-state

resistance (R

DS(ON)

)

and yet maintain superior switching performance,

making it ideal for high efficiency power management applications.

Applications



Small Servo Motor Control

Power MOSFET Gate Drivers

Switching Applications

Mechanical Data



Case: SOT323

Case Material: Molded Plastic, "Green" Molding Compound,

UL Flammability Classification Rating 94V-0

Moisture Sensitivity: Level 1 per J-STD-020

Terminal Connections: See Diagram

Terminals: Matte Tin Finish annealed over Alloy 42 Leadframe

(Lead Free Plating). Solderable per MIL-STD-202, Method 208

Weight: 0.006 grams (approximate)

SOT323

Top View

Equivalent Circuit

Top View

Ordering Information

(Notes 4 & 5)

Part Number

BSS123WQ-7-F

Notes:

Compliance

Automotive

Case

SOT323

Packaging

3000/Tape & Reel

1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.

2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"

and Lead-free.

3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and

<1000ppm antimony compounds.

4. Automotive products are AEC-Q101 qualified and are PPAP capable. Automotive, AEC-Q101 and standard products are electrically and thermally the

same, except where specified. For more information, please refer to http://www.diodes.com/quality/product_grade_definitions/.

5. For packaging details, go to our website at http://www.diodes.com/products/packages.html

Marking Information

K23 = Product Type Marking Code

YM = Date Code Marking

Y = Year (ex: B = 2014)

M = Month (ex: 9 = September)

K23

Date Code Key

Year

2002

Code

Month

Code

Jan

2003

Feb

2004

Mar

2005

2006

Apr

…

May

2014

Jun

2015

Jul

2016

Aug

2017

Sep

2018

2019

Oct

2020

Nov

2021

Dec

BSS123WQ

Document number: DS37469 Rev. 1 - 2

1 of 5

www.diodes.com

September 2014
