MKP1846-268-065 datasheet, PDF

Datasheet> All Categories > Passive components> capacitor> MKP1846-268-065

MKP1846-268-065: DescriptionCAPACITOR, METALLIZED FILM; CategoryPassive components capacitor; File Size152KB，4 Pages; ManufacturerVishay; Websitehttp://www.vishay.com

Download Datasheet Parametric View All

MKP1846-268-065 Overview

CAPACITOR, METALLIZED FILM

MKP1846-268-065 Parametric

Parameter Name	Attribute value
Objectid	1226146216
package instruction	,
Reach Compliance Code	unknown
ECCN code	EAR99
Capacitor type	FILM CAPACITOR
Number of terminals	2

Preview

Download Datasheet

View All

MKP 1846

Not for new designs

Vishay Roederstein

Metallized Polypropylene Film Capacitor

Related Document: IEC 60384-16

Dimensions in millimeters

L Max.

W Max.

Marking

FEATURES

Product is completely lead (Pb)-free

Product is RoHS-compliant

OPERATING TEMPERATURE RANGE

Max.

0.6

- 55°C to + 100°C

RoHS

COMPLIANT

CAPACITANCE RANGE

1000pF to 0.68µF

0.4

6.0

- 1

CAPACITANCE TOLERANCES

± 20% (M), ± 10% (K), ± 5% (J)

pcm

0.4

Ød

RATED VOLTAGES (U

630 VDC, 1000 VDC, 1600 VDC, 2000 VDC

PERMISSIBLE AC VOLTAGES (RMS) UP TO 60Hz

< 16.0

≥

16.0

Ød

0.8

1.0

400 VAC, 600 VAC, 650 VAC, 700 VAC

TEST VOLTAGE (ELECTRODE/ELECTRODE)

1.6 x U

for 2 s

MAIN APPLICATIONS

High voltage, high current and high pulse operations,

deflection circuits in TV sets (S-correction and fly-back

tuning). Protection circuits in SMPS’s. Snubber and

electronic ballast circuits. Input and output filtering in SPS

designs, storage, timing and integrating circuits.

INSULATION RESISTANCE

Measured at 100 VDC after one minute

For C

≤

0.33µF:

100,000 MΩ minimum value

TIME CONSTANT

MARKING

Manufacturer's logo/type/C-value/rated voltage/tolerance/

date of manufacture

Measured at 100 VDC after one minute

For C > 0.33µF:

30,000 s minimum value

TEMPERATURE COEFFICIENT

- 250 x 10

-6

/°C (typical value)

DIELECTRIC

Polypropylene film

CAPACITANCE DRIFT

Up to + 40°C, ± 0.5% for a period of two years

ELECTRODES

Vacuum deposited aluminum

DERATING FOR DC AND AC.CATEGORY VOLTAGE U

At + 85°C: U

= 1.0 U

At + 100°C: U

= 0.7 UR

COATING

Flame retardant plastic case (UL-class 94 V-0), blue, epoxy

resin sealed

SELF INDUCTANCE

~ 6 nH measured with 2mm long leads

CONSTRUCTION

Extended double-sided metallized polyester film, internal

series connection, single-sided metallized polypropylene film

(refer to general information)

PULL TEST ON LEADS

RELIABILITY

≥

30 N in direction of leads according to IEC 60068-2-21

Operational life > 300,000 h

Failure rate < 5 FIT (40°C and 0.5 x U

)

For further details, please refer to the general information

available at www.vishay.com/doc?26033.

LEADS

Tinned wire

IEC TEST CLASSIFICATION

55/100/56, according to IEC 60068

MAXIMUM PULSE RISE TIME

630 VDC

1000 VDC

1600 VDC

3430

6600

11100

22.5

2120

2800

3800

27.5

1524

2000

2680

37.5

980

1280

1690

If the maximum pulse voltage is less than the rated voltage higher d

values can be permitted.

Document Number: 26020

Revision: 23-Jun-05

For technical questions contact; dc-film@vishay.com

PCM

(mm)

Maximum Pulse Rise Time d

[V/µs]

2000 VDC

—

6200

4200

2600

www.vishay.com
