SA5V0(C)A - SA170(C)A
Transient Voltage Suppressors
SA5V0(C)A - SA170(C)A
Features
•
•
•
•
•
Glass passivated junction.
500W Peak Pulse Power capability on
10/1000
µs
waveform.
Excellent clamping capability.
Low incremental surge resistance.
Fast response time; typically less
than 1.0 ps from 0 volts to BV for
unidirectional and 5.0 ns for
bidirectional.
Typical I
R
less than 1.0
µA
above 10V.
DO-15
COLOR BAND DENOTES CATHODE
ON UNIDIRECTIONAL DEVICES ONLY. NO
COLOR BAND ON BIDIRECTIONAL DEVICES.
•
DEVICES FOR BIPOLAR APPLICATIONS
- Bidirectional types use CA suffix.
- Electrical Characteristics apply in both directions.
500 Watt Transient Voltage Suppressors
Absolute Maximum Ratings*
Symbol
P
PPM
I
PPM
P
D
I
FSM
T
stg
T
J
T
A
= 25°C unless otherwise noted
Parameter
Peak Pulse Power Dissipation on 10/1000
µs
waveform
Peak Pulse Current on 10/1000
µs
waveform
Power Dissipation
.375 " lead length @ T
A
= 75°C
Non-repetitive Peak Forward Surge Current
superimposed on rated load (JEDEC method)
Storage Temperature Range
Operating Junction Temperature
Value
500
see table
1.0
(Note 1)
Units
W
A
W
A
°C
°C
70
-65 to +175
+ 175
*
These ratings are limiting values above which the serviceability of any semiconductor device may be impaired.
Note 1:
Measured on 8.3 ms single half-sine wave or equivalent square wave; Duty cycle = 4 pulses per minute maximum.
2002
Fairchild Semiconductor Corporation
SA5V0(C)A - SA170(C)A, Rev. D
SA5V0(C)A - SA170(C)A
Transient Voltage Suppressors
(continued)
Electrical Characteristics
Uni-directional
Bi-directional (C)
Device
SA5V0(C)A
SA6V0(C)A
SA6V5(C)A
SA7V0(C)A
SA7V5(C)A
SA8V0(C)A
SA8V5(C)A
SA9V0(C)A
SA10(C)A
SA11(C)A
SA12(C)A
SA13(C)A
SA14(C)A
SA15(C)A
SA16(C)A
SA17(C)A
SA18(C)A
SA20(C)A
SA22(C)A
SA24(C)A
SA26(C)A
SA28(C)A
SA30(C)A
SA33(C)A
SA36(C)A
SA40(C)A
SA43(C)A
SA45(C)A
SA48(C)A
SA51(C)A
SA54(C)A
SA58(C)A
SA60(C)A
SA64(C)A
SA70(C)A
SA75(C)A
SA78(C)A
SA85(C)A
SA90(C)A
SA100(C)A
SA110(C)A
SA120(C)A
SA130(C)A
SA150(C)A
SA160(C)A
SA170(C)A
Reverse
Stand-off Voltage
V
RWM
(V)
5.0
6.0
6.5
7.0
7.5
8.0
8.5
9.0
10
11
12
13
14
15
16
17
18
20
22
24
26
28
30
33
36
40
43
45
48
51
54
58
60
64
70
75
78
85
90
100
110
120
130
150
160
170
T
A
= 25°C unless otherwise noted
Breakdown Voltage
V
BR
(V)
min
6.40
6.67
7.22
7.78
8.33
8.89
9.44
10.0
11.1
12.2
13.3
14.4
15.6
16.7
17.8
18.9
20.0
22.2
24.4
26.7
28.9
31.1
33.3
36.7
40.0
44.4
47.8
50.0
53.3
56.7
60.0
64.4
66.7
71.1
77.8
83.3
86.7
94.4
100.0
111.0
122.0
133.0
144.0
167.0
178.0
189.0
max
7.00
7.37
7.98
8.60
9.21
9.83
10.4
11.1
12.3
13.5
14.7
15.9
17.2
18.5
19.7
20.9
22.1
24.5
26.9
29.5
31.9
34.4
36.8
40.6
44.2
49.1
52.8
55.3
58.9
62.7
66.3
71.2
73.7
78.6
86.0
92.1
95.8
104.0
111.0
123.0
135.0
147.0
159.0
185.0
197.0
209.0
Test
Current
I
T
(mA)
10
10
10
10
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
Clamping Voltage Peak Pulse
@I
PPM
Current
V
C
(V)
I
PPM
(A)
9.2
10.3
11.2
12.0
12.9
13.6
14.4
15.4
17.0
18.2
19.9
21.5
23.2
24.4
26.0
27.6
29.2
32.4
35.5
38.9
42.1
45.4
48.4
53.3
58.1
64.5
69.4
72.7
77.4
82.4
87.1
93.6
96.8
103.0
113.0
121.0
126.0
137.0
146.0
162.0
177.0
193.0
209.0
243.0
259.0
275.0
54.3
48.5
44.7
41.7
38.8
36.7
34.7
32.5
29.4
27.4
25.1
23.2
21.5
20.6
19.2
18.1
17.2
15.4
14.1
12.8
11.9
11.0
10.3
9.4
8.6
7.8
7.2
6.9
6.5
6.1
5.7
5.3
5.2
4.9
4.4
4.1
4.0
3.6
3.4
3.1
2.8
2.7
2.4
2.1
1.9
1.8
Reverse
Leakage V
RWM
I
R
(uA)*
600
600
400
150
50
25
10
5
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
* For bidirectional parts with V
RWM
<10V, the I
R
max limit is doubled.
SA5V0(C)A - SA170(C)A, Rev. D
SA5V0(C)A - SA170(C)A
Transient Voltage Suppressors
(continued)
Typical Characteristics
100
100
T
A
= 25
º
C
75
Pulse Power [%]
Pulse Power [kW]
10
50
1
25
0.1
0.0001
0
0.001
0.01
0.1
Pulse Width [ms]
1
10
0
25
50
75
100 125 150
Ambient Temperature [ºC]
175
200
Figure 1. Peak Pulse Power Rating Curve
Figure 2. Pulse Derating Curve
150
tf = 10µsec
µ
Total Capacitance, C
T
[pF]
Peak Pulse Current [%]
100
Peak Value
Ippm
T
A
= 25
º
C
Pulse Width (td) is Defined
as the Point Where the Peak
Current Decays to 50% of Ipp
6000
4000
2000
1000
500
200
100
50
20
4
10
1
Measured at
Stand-Off
Voltage (V mw)
T
A
= 25
º
C
f = 1.0 MHz
Visg = 50m Vp-p
Measured at
Zero Bias
Half Value-Ipp
2
50
10/1000µsec Waveform
µ
as Defined by R.E.A.
td
e-kt
0
0
1
2
Time [ms]
3
5
10
50
Reverse Voltage, V
R
[V]
100
200
Figure 3. Pulse Waveform
Figure 4. Total Capacitance - Unidirectional
Peak Forward Surge Current, I
FSM
[A]
1.6
1.4
Power Dissipation [W]
1.2
1
0.8
0.6
0.4
0.2
0
0
25
50
75
100 125 150
Lead Temperature [ºC]
175
200
100
T
A
= T
A
max
8.3ms Single Half Sine-Wave
JEDEC Method
50
20
10
1
2
Figure 5. Steady State Power Derating Curve
5
10
20
Number of Cycles at 60Hz
50
100
Figure 6. Non-Repetitive Surge Current
SA5V0(C)A - SA170(C)A, Rev. D
TRADEMARKS
The following includes registered and unregistered trademarks and service marks, owned by Fairchild Semiconductor and/or its global subsidiaries, and is not
intended to be an exhaustive list of all such trademarks.
AccuPower
Auto-SPM
AX-CAP*
Build it Now
CorePLUS
CorePOWER
CROSSVOLT
CTL
Current Transfer Logic
DEUXPEED
®
Dual Cool™
EcoSPARK
®
EfficientMax
ESBC
®
Fairchild
®
Fairchild Semiconductor
®
FACT Quiet Series
FACT
®
FAST
®
FastvCore
FETBench
FlashWriter
®
*
FPS
F-PFS
FRFET
®
SM
Global Power Resource
Green FPS
Green FPS e-Series
Gmax
GTO
IntelliMAX
ISOPLANAR
MegaBuck
MICROCOUPLER
MicroFET
MicroPak
MicroPak2
MillerDrive
MotionMax
Motion-SPM
mWSaver
OptoHiT
OPTOLOGIC
®
OPTOPLANAR
®
®
Power-SPM
PowerTrench
®
PowerXS™
Programmable Active Droop
QFET
®
QS
Quiet Series
RapidConfigure
Saving our world, 1mW/W/kW at a time™
SignalWise
SmartMax
SMART START
SPM
®
STEALTH
SuperFET
®
SuperSOT-3
SuperSOT-6
SuperSOT-8
SupreMOS
®
SyncFET
Sync-Lock™
®
The Power Franchise
®
The Right Technology for Your Success™
TinyBoost
TinyBuck
TinyCalc
TinyLogic
®
TINYOPTO
TinyPower
TinyPWM
TinyWire
TriFault Detect
TRUECURRENT
®
*
SerDes
PDP SPM
™
*
UHC
®
Ultra FRFET
UniFET
VCX
VisualMax
XS™
* Trademarks of System General Corporation, used under license by Fairchild Semiconductor.
DISCLAIMER
FAIRCHILD SEMICONDUCTOR RESERVES THE RIGHT TO MAKE CHANGES WITHOUT FURTHER NOTICE TO ANY PRODUCTS HEREIN TO IMPROVE
RELIABILITY, FUNCTION, OR DESIGN. FAIRCHILD DOES NOT ASSUME ANY LIABILITY ARISING OUT OF THE APPLICATION OR USE OF ANY PRODUCT
OR CIRCUIT DESCRIBED HEREIN; NEITHER DOES IT CONVEY ANY LICENSE UNDER ITS PATENT RIGHTS, NOR THE RIGHTS OF OTHERS. THESE
SPECIFICATIONS DO NOT EXPAND THE TERMS OF FAIRCHILD’S WORLDWIDE TERMS AND CONDITIONS, SPECIFICALLY THE WARRANTY THEREIN,
WHICH COVERS THESE PRODUCTS.
LIFE SUPPORT POLICY
FAIRCHILD’S PRODUCTS ARE NOT AUTHORIZED FOR USE AS CRITICAL COMPONENTS IN LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE
EXPRESS WRITTEN APPROVAL OF FAIRCHILD SEMICONDUCTOR CORPORATION.
As used herein:
2. A critical component in any component of a life support, device, or
1. Life support devices or systems are devices or systems which, (a)
system whose failure to perform can be reasonably expected to
are intended for surgical implant into the body or (b) support or
cause the failure of the life support device or system, or to affect its
sustain life, and (c) whose failure to perform when properly used in
safety or effectiveness.
accordance with instructions for use provided in the labeling, can be
reasonably expected to result in a significant injury of the user.
ANTI-COUNTERFEITING POLICY
Fairchild Semiconductor Corporation's Anti-Counterfeiting Policy. Fairchild's Anti-Counterfeiting Policy is also stated on our external website,
www.fairchildsemi.com, under Sales Support.
Counterfeiting of semiconductor parts is a growing problem in the industry. All manufacturers of semiconductor products are experiencing counterfeiting of their
parts. Customers who inadvertently purchase counterfeit parts experience many problems such as loss of brand reputation, substandard performance, failed
applications, and increased cost of production and manufacturing delays. Fairchild is taking strong measures to protect ourselves and our customers from the
proliferation of counterfeit parts. Fairchild strongly encourages customers to purchase Fairchild parts either directly from Fairchild or from Authorized Fairchild
Distributors who are listed by country on our web page cited above. Products customers buy either from Fairchild directly or from Authorized Fairchild Distributors
are genuine parts, have full traceability, meet Fairchild's quality standards for handling and storage and provide access to Fairchild's full range of up-to-date
technical and product information. Fairchild and our Authorized Distributors will stand behind all warranties and will appropriately address any warranty issues that
may arise. Fairchild will not provide any warranty coverage or other assistance for parts bought from Unauthorized Sources. Fairchild is committed to combat this
global problem and encourage our customers to do their part in stopping this practice by buying direct or from authorized distributors.
PRODUCT STATUS DEFINITIONS
Definition of Terms
Datasheet Identification
Advance Information
Preliminary
No Identification Needed
Obsolete
Product Status
Formative /
In Design
First Production
Full Production
Not In Production
Definition
Datasheet contains the design specifications for product development. Specifications may change
in any manner without notice.
Datasheet contains preliminary data; supplementary data will be published at a later date. Fairchild
Semiconductor reserves the right to make changes at any time without notice to improve design.
Datasheet contains final specifications. Fairchild Semiconductor reserves the right to make
changes at any time without notice to improve the design.
Datasheet contains specifications on a product that is discontinued by Fairchild Semiconductor.
Step 1: Initiate a connection
The software initiates the connection using the remote ID and password.
One of the two communicating parties first uses other communication tools to send his ID and passw...
The 494 chip changes the level and sends it to pin 15 (input pin), and then feeds back to pin 3. I found that some circuits add a 1UF capacitor between the two. Doesn't this mean that it cannot be adj...
All electronic design engineers and scientists have performed electrical signal analysis, or signal analysis for short. Through this basic measurement, they can gain insight into signal details and...[Details]
With the rapid development of urban economy, elevators are increasingly used as a vertical transportation tool. However, elevator fault detection and maintenance, especially the role of elevator remot...[Details]
1. Introduction
At present, most lighting equipment still uses traditional energy for lighting. Making full use of solar energy as the energy supply for lighting equipment is of great si...[Details]
Overview:
This paper introduces a method of connecting a CAN-bus network with Ethernet to form a medium-sized remote monitoring/data transmission network.
CAN (Controller Area Network) is ...[Details]
LED is the abbreviation of light emitting diode, which is an electric light source made of semiconductor technology. The core part of LED is a chip composed of P-type semiconductor and N-type semi...[Details]
Many battery-powered systems require a visual indicator to show when the battery needs to be replaced. LEDs are commonly used for this purpose, but they consume at least 10mA of current. This con...[Details]
It is well known to automotive suppliers that automakers are demanding more from their supply base. For connector suppliers, this means stricter requirements for product performance, stability and ...[Details]
The era of mobile access to the Internet has arrived, and it will rapidly change the business and infrastructure needs of mobile operators under a whole new trend of requirements. We need 4G LTE to...[Details]
Since AC mains power may experience power outages, voltage sags and surges, continuous undervoltage and overvoltage, and frequency fluctuations during supply, these factors will affect the continuous ...[Details]
summary
This article will briefly analyze the success and shortcomings of high-frequency DC-DC switching power supplies in the process of miniaturization (the second basic goal), and propose m...[Details]
There are many types and styles of digital voltmeters in design and development. Traditional digital voltmeters have their own characteristics. They are suitable for manual measurement on site. Tra...[Details]
LonWorks fieldbus technology is widely used, for example, in intelligent buildings, industrial control, environmental protection, etc. Echelon's LonWorks system has been used in the products of tho...[Details]
With the development and application of liquid crystal display technology, more and more developers want to use liquid crystal screens to display Chinese characters in the instruments and equipment th...[Details]
For the past
15
years, many have predicted that
the
8
-bit microcontroller would soon be gone. However, this was one of the most miscalculated predictions in the el...[Details]
The Challenge:
Improving Siemens Wind
Turbine Controls
System software automated testing for regular releases, validating wind turbine control system components during the developme...[Details]
Embedded System
京公网安备 11010802033920号
EEWORLD
