LEADED CAPACITORS, NETWORKS & HV CAPACITORS
MEDIUM VOLTAGE CAPACITORS
1kV to 6kVDC E.I.A.CLASS II & III–SPECIFICATIONS & TEST METHODS DE Series
Item
1 Operating Temperature Range
2 Capacitance
3 Q
Dissipation Factor (D.F.)
4 Insulation
Resistance (I.R.)
5 Dielectric
Strength
Between
lead wires
Between
lead wires
Body
Insulation
Specification
Temperature Compensating
High Dielectric Constant
–25 to +85°C
–25 to +85°C
Within the specified tolerance.
Within the specified
tolerance.
SL
C
≥
30pF: Q
≥
1000
C < 30pF: Q
≥
400 + 20C
1
B, E
F
D.F.
≤
2.5%
D.F.
≤
5.0%
Test Method
—
The capacitance shall be measured at 20°C with 1 ± 0.2kHz
(SL: 1 ± 0.2MHz) and 5V(r.m.s.) max.
Same condition as capacitance.
The insulation resistance shall be measured with 500 ± 50VDC within
60 ± 5 sec. of charging.
The capacitors shall not be damaged when DC voltage of 200% of the
rated voltage is applied between the lead wires for 1 to 5 sec.
(Charge/discharge current
≤50mA)
The capacitor is placed in the container with metal
balls of diameter 1mm so that each lead wire, short-
Approx. 2mm
circuited, is kept approximately 2mm off the balls as
shown in the figure, and DC voltage of 1.3kV is
applied for 1 to 5 sec. between capacitor lead wires
Metal balls
and small metals. (Charge/discharge current
≤50mA).
The capacitance measurement shall be made at each step specified in
table. Capacitance change from the value of step 3 shall not exceed the
limit specified.
Char. Step
1
2
3
4
5
SL
—
—
20 ± 2°C 85 ± 2°C 20 ± 2°C
B, E, F
20 ± 2°C –25 ± 3°C 20 ± 2°C 85 ± 2°C 20 ± 2°C
Pre-treatment
Capacitor shall be stored at 85 ± 2°C for 1 hour, then placed at room
condition
2
for 24 ± 2 hours before initial measurements (B, E, F).
The capacitor shall firmly be soldered to the supporting lead wire and
vibration which is 10 to 55Hz in the vibration frequency range, 1.5mm
in total amplitude, and about 1 minute in the rate of vibration change
from 10Hz to 55Hz and back to 10Hz is applied for a total of 6 hours;
2 hours each in 3 mutually perpendicular directions.
The lead wire shall be immersed into the melted solder of 350 ± 10°C
(body of 5 and under: 270 ± 5°C) up to about 1.5 to 2mm from the
main body for 3.5 ± 0.5 sec. (body of 5 and under: 5 ± 0.5 sec.).
Pre-treatment
Capacitor shall be stored at 85 ± 2°C for 1 hour, then placed at room
condition
2
for 24 ± 2 hours before initial measurements (B, E, F).
Post-treatment
Capacitor shall be stored for 1 to 2 hours at room condition
2
(SL).
Capacitor shall be stored for 24 ± 2 hours at room condition
2
(B, E, F).
Set the capacitor for 500
+24
hours at 40 ± 2°C in 90 to 95% humidity.
–0
Pre-treatment
Capacitor shall be stored at 85 ± 2°C for 1 hour, then placed at room
condition
2
for 24 ± 2 hours before initial measurements (B, E, F).
Post-treatment
Capacitor shall be stored for 1 to 2 hours at room condition
2
.
10000M ohms min.
No failure.
10000M ohms min.
No failure.
No failure.
No failure.
6 Temperature Characteristic
T.C.
SL
Temp. Coefficient
+350 to –1000ppm/°C
T.C.
B
E
F
Cap. Change
within ±10%
within
+20
%
–55
within
+30
%
–80
7 Vibration
Resistance
Appearance
Capacitance
Change
Q.
D.F.
Appearance
Capacitance
Change
Dielectric
Strength
(between
lead wires)
Appearance
Capacitance
Change
Q.
D.F.
No marked defect.
Within the specified tolerance.
SL
C
≥
30pF: Q
≥
1000
C < 30pF: Q
≥
400 + 20C
1
within ±2.5%
No marked defect.
Within the specified
tolerance.
B, E
F
B
E
F
D.F.
≤
2.5%
D.F.
≤
5.0%
within ±5%
within ±15%
within ±20%
8 Soldering
Effect
No marked defect.
SL
No marked defect.
Pass the item No. 5.
Pass the item No. 5.
9 Humidity
(Under
Steady State)
No marked defect.
SL
within ±5%
No marked defect.
B
E
F
B, E
F
within ±10%
within ±20%
within ±30%
D.F.
≤
5.0%
D.F.
≤
7.5%
SL
C
≥
30pF: Q
≥
350
C < 30pF: Q
≥
275 +
5
/
2
C
1
10 Humidity
Loading
I.R.
Appearance
Capacitance
Change
Q.
D.F.
1000M ohms min.
No marked defect.
SL
within ±7.5%
1000M ohms min.
No marked defect.
B
E
F
B, E
F
within ±10%
within ±20%
within ±30%
D.F.
≤
5.0%
D.F.
≤
7.5%
SL
C
≥
30pF: Q
≥
200
C < 30pF: Q
≥
100 +
10
/
3
C
1
11 Life
I.R.
Appearance
Capacitance
Change
Q.
D.F.
500M ohms min.
No marked defect.
SL
within ±3%
500M ohms min.
No marked defect.
B
E
F
B, E
F
within ±10%
within ±20%
within ±30%
D.F.
≤
4.0%
D.F.
≤
7.5%
SL
C
≥
30pF: Q
≥
350
C < 30pF: Q
≥
275 +
5
/
2
C
1
12 Strength of
Lead
I.R.
Pull
2000M ohms min.
Lead wire shall not cut off.
Capacitor shall not be broken.
2000M ohms min.
Bending
13 Solderability of Leads
Lead wire shall be soldered with uniform coating on the axial
direction over
3
/
4
of the circumferential direction.
2
“room
Apply the rated voltage for 500
+24
hours at 40 ± 2°C in 90 to 95%
–0
humidity. (Charge/discharge current
≤50mA).
Pre-treatment
Capacitor shall be stored at 85 ± 2°C for 1 hour, then placed at room
condition
2
for 24 ± 2 hours before initial measurements (B, E, F).
Post-treatment
Capacitor shall be stored for 1 to 2 hours at room condition
2
(SL).
Capacitor shall be stored at 85 ± 2°C for 1 hour, then placed at room
condition
2
for 24 ± 2 hours (B, E, F).
Apply a DC voltage of 150% of the rated voltage for 1000
+48
hours at
–0
85 ± 2°C. (Charge/discharge current
≤50mA).
Pre-treatment
Capacitor shall be stored at 85 ± 2°C for 1 hour, then placed at room
condition
2
for 24 ± 2 hours before initial measurements (B, E, F).
Post-treatment
Capacitor shall be stored for 1 to 2 hours at room condition
2
(SL).
Capacitor shall be stored at 85 ± 2°C for 1 hour, then placed at room
condition
2
for 24 ± 2 hours (B, E, F).
As in figure, fix the body of capacitor, apply a tensile weight
gradually to each lead wire in the radial direction of capacitor
up to 10N (1.0kgf) 5N (0.51kgf) for lead diameter 0.5, and
W
keep it for 10 ± 1 sec.
Each lead wire shall be subjected to 5N (0.51kgf) 2.5N (0.25kgf) for lead
diameter 0.5 weight and then a 90° bend, at the point of egress, in one
direction, return to original position, and then a 90° bend in the opposite
direction at the rate of one bend in 2 to 3 seconds.
The lead wire of a capacitor shall be dipped into a methanol solution of
25wt% rosin and then into molten solder of 235 ± 5°C for 2 ± 0.5
seconds. In both cases the depth of dipping is up to about 1.5 to 2mm
from the root of lead wires.
82
1
“C”
expresses nominal capacitance value (pF).
condition” temperature: 15 to 35°C; humidity: 45 to 75%; atmospheric pressure: 860 to 1060hPa.
CG01-J
