MODEL:
SJ-43504-SMT
│
DESCRIPTION:
MID MOUNT AUDIO JACK
FEATURES
• mid mount for low profile applications
• shielded
• two internal switches, tip and ring
SPECIFICATIONS
parameter
rated input voltage
rated input current
contact resistance
insulation resistance
voltage withstand
insertion/withdrawal force
terminal strength
operating temperature
life
RoHS
Notes:
conditions/description
min
typ
12
max
1
units
Vdc
A
mΩ
mΩ
MΩ
Vac
kg
g
°C
cycles
between terminal and mating plug
between terminal in a closed circuit
1
at 500 Vdc
at 50/60Hz for 1 minute
0.3
any direction for 10 seconds
-25
5,000
yes
100
50
30
500
3
500
85
1. When measured at a current of less than 100 mA / 1 kHz
2. Add suffix “-TR” to the model number for tape and reel packaging.
SOLDERABILITY
parameter
reflow soldering
conditions/description
see reflow profile
min
255
typ
260
max
265
units
°C
270
260
250
240
217
180
150
120
60
50
°C
60
Time (second)
70
120
140
180
240
250
300
340
360
380
420
430
480
cui.com
For more information, please visit the
product page.
CUI Inc
│
MODEL:
SJ-43504-SMT
│
DESCRIPTION:
MID MOUNT AUDIO JACK
date
11/28/2012
│
page
3 of 3
REVISION HISTORY
rev.
1.0
1.01
description
initial release
added TR package option, updated spec.
date
06/28/2011
11/28/2012
The revision history provided is for informational purposes only and is believed to be accurate.
