NLA-PM100D Overview

Multi-functions Power Monitoring and Control Terminal

NLA—PM100D Multi-functions Power

Monitoring and Control Terminal

Introduction

NLA-PM100D is a LonWorks control network and RS-485 bus based

multi-functions power monitoring and control terminal. It can be used to

measure 1,2 or 3 phase voltage, current, active power and reactive power,

power factor, active and reactive energy, frequency, demand and etc, to

control the electrical devices in the single or three phase feeder, and

to monitor the state and the alarms of the electrical devices. The product

has passed the approval test of the Inspection & Center for Electric Power

Automation Equipment of Ministry of Electric Power in P.R.China

Features

Measure single or three phase voltage, current, active and reactive

power, power factor, active energy and reactive energy, frequency, and

etc.

Display single or three phase voltage, current, active and reactive

power, power factor, active energy and reactive energy, frequency,

demand and etc, the states of the digital input and output.

Set up the operating parameters and the control outputs manually on

site.

Isolated voltage and current measurement

input

loops.

3 optical and relay double isolated digital outputs for control and

pulse functions, the width of the pulse can be adjusted.
