OC5-N-25000X-C-B-B-3-R-X

Description
CMOS/TTL Output Clock Oscillator, 25MHz Nom,
CategoryPassive components    oscillator
File Size443KB,3 Pages
ManufacturerWi2Wi
Environmental Compliance
Download Datasheet Parametric View All

OC5-N-25000X-C-B-B-3-R-X Overview

CMOS/TTL Output Clock Oscillator, 25MHz Nom,

OC5-N-25000X-C-B-B-3-R-X Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
Objectid1389912790
Reach Compliance Codecompliant
Other featuresSYMMETRY 55/45% ALSO AVAILABLE; TR, 7 INCH
maximum descent time8 ns
Frequency Adjustment - MechanicalNO
frequency stability25%
JESD-609 codee4
Installation featuresSURFACE MOUNT
Nominal operating frequency25 MHz
Maximum operating temperature70 °C
Minimum operating temperature-20 °C
Oscillator typeCMOS/TTL
Output load10 TTL, 15 pF
physical size5.0mm x 3.2mm x 1.27mm
longest rise time8 ns
Maximum supply voltage3.63 V
Minimum supply voltage2.97 V
Nominal supply voltage3.3 V
surface mountYES
maximum symmetry60/40 %
Terminal surfaceGold (Au)
OC5-Series Specifications
5.00L x 3.20W x 1.27H (mm)
PDI Model
OC5-Series
provides precision timing in a hermetically
sealed package, and is available in both standard and custom frequencies
and configurations. PDI provides quick-turn sampling for your proto-typing
needs, mass production capability, and competitive pricing.
ex)
OC5—T—25000X—C—D—A—3—R—X
*
ENABLE
T
= Tri-State
N
= No/Connect
FREQUENCY
00030X-99999X
=
0.0300 MHz –
99.999 MHz
C10000-C20000
=
100.00 MHz –
200.00 MHz
OUTPUT
C
= TTL/CMOS
O
= LVCMOS
H
= HCMOS
FREQUENCY
STABILITY
B
= ±25 **
C
= ±50
D
= ±100
S
= Special
OPERATING
TEMPERATURE
A
= 0 to +70°C
B
= -20 to +70°C
D
= -40 to +85°C
E
= -55 to +125°C
S
= Special
SUPPLY
VOLTAGE
1
= 1.8
2
= 2.5
F
= 3.0
3
= 3.3
5
= 5.0
PACKAGE
R
= Tape & Reel
** - Not available -55 to +125°C
* - for standard or assigned for customization.
Parameter
Frequency Range
*1
Frequency Stability
*1
Temperature Range
*1
Low
High
All Causes (Maximum )
*2
Operating
Storage
0.030000 to 23.999999 MHz
24.000000 to 49.999999 MHz
50.000000 to 69.999999 MHz
70.000000 to 200.000000 MHz
5.0
Supply Voltage
*1
(±10%)
3.3
3.0
2.5
Units
1.8
V
MHz
ppm
°C
°C
10
12
15
25
mA
Supply Current (Maximum)
Output Options
Load
Duty Cycle (at 50% Vcc)
Rise/Fall Times (Maximum)
Start up Time (Maximum)
Output Voltage Levels
Rise Time (10% to 90% Vcc)
Fall Time (90% to 10% Vcc)
High (Minimum)
Low (Maximum)
High (See below) or Open
Low (See below)
*3
High Value (Minimum)
Low Value (Maximum)
*3
Disable Current (Maximum)
*3
Enable Delay Time (Maximum)
Disable Delay Time (Maximum)
Pin 1 (Tri-State) (Option)
0.030000
166.000
200.000
Per Option
Per Option
- 55 to +125
20
15
15
15
30
20
20
20
40
30
30
30
60
45
45
45
C&H
C&O
15pF/10 TTL gates
40 to 60% (45 to 55% option)
10
8
8
7
10
8
8
7
10
90
10
Enable
Disable
80
80
80
80
20
20
20
20
10
10
10
10
10
150
6
6
ns
ms
% Vcc
80
20
10
% Vcc
% Vcc
uA
ms
ns
*1 - Not all Frequency/Temperature/Voltage combinations are available.
*2 - Inclusive of Tolerance @25°C, Operating Temperature, Supply Voltage, Load, Aging, Shock and Vibration.
*3 - Internal crystal oscillation halted.
REV:
NA
SIZE:
A
CAGE:
0S4G1
1
of
3
