Federkontakte am Band
spring contact on carrier strip
1,6
7,62
6,55
5,05
4,3
3,6
3,2
Federkontakt vereinzelt
spring contact isolated
Schnitt A-A
cross section A-A
M 10:1
B
B
Drahtcrimp
1,8
16,48
wire crimp
A
A
,5
Ab
s
Re pulri
el
off chtun
Dir
g
ec t
ion
13,08
Schnitt B-B
cross section B-B
M 10:1
2,5
Isolationscrimp
R0
insulation crimp
0,4
-0,07
+0,03
R0
,7
2,4
2
AWG 20-22
Leiterquerschnitt
500
∅
130
137
Anforder-
ungsstufe
Menge
Spulendurchmesser
Bemerkung
wire cross section
Copyright by ERNI GmbH
Proprietary notice pursuant to ISO 16016 to be observed.
quantity
Tolerances
reel diameter
Scale
class
remark
Information:
2:1
All Dimensions
in mm
All rights reserved.
Only for Information.
To ensure that this is the latest
version of this drawing, please
contact one of the ERNI companies
before using.
d
Index
29.03.2012
Date
Designation
Subject to modification without
prior notice.
Drawing will not be updated.
Federkontakte 2,54 SRC-A BA 2
Spring contact 2,54 SRC-A
www.ERNI.com
Class
104902000001
SRCBUT
K
A3
