SG-8002JFSCC

Description
Oscillator, 1MHz Min, 125MHz Max, 125MHz Nom,
CategoryPassive components    oscillator
File Size80KB,2 Pages
ManufacturerSeiko Epson Corporation
Download Datasheet Parametric View All

SG-8002JFSCC Overview

Oscillator, 1MHz Min, 125MHz Max, 125MHz Nom,

SG-8002JFSCC Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
Objectid102857391
package instructionSMDIP4,.23,200
Reach Compliance Codecompliant
JESD-609 codee0
Installation featuresSURFACE MOUNT
Number of terminals4
Maximum operating frequency125 MHz
Minimum operating frequency1 MHz
Nominal operating frequency125 MHz
Maximum operating temperature70 °C
Minimum operating temperature-20 °C
Maximum output low current8 mA
Package body materialPLASTIC/EPOXY
Encapsulate equivalent codeSMDIP4,.23,200
power supply3.3 V
Certification statusNot Qualified
Nominal supply voltage3.3 V
surface mountYES
Terminal surfaceTin/Lead (Sn/Pb)
Crystal oscillator
PROGRAMMABLE HIGH-FREQUENCY CRYSTAL OSCILLATOR
SG-8002JF series
Wide frequency output by PLL technology.
Quick delivery of samples and short lead mass production time.
Excellent shock resistance and environmental capability.
Output enable function (OE) and stand-by function (ST) can be
used for low current consumption applications.
8002 PROM Writer available to purchase.(Type:PRW-8000A3-M01)
Please contact EPSON or local sales representative.
Actual size
Specifications (characteristics)
Item
Output frequency range
Power source
voltage
Temperature
range
Max. supply voltage
Operating voltage
Storage temperature
Operating temperature
Symbol
f
0
V
DD
-GND
V
DD
T
STG
T
OPR
T
SOL
∆f/f
0
Iop
I
OE
I
ST
t
w
/ t
V
OH
V
OL
N
C
L
V
IH
V
IL
t
TLH
t
THL
t
OSC
fa
S.R.
PT/ST
PH/SH
Specifications
PC/SC
Remarks
1.0000 MHz to
125.0000 MHz
-0.5V to +7.0V
5.0V±0.5V
-55˚C to +125˚C
-20˚C to +70˚C (-40˚C to +85˚C)
3.3
±
0.3V
-40˚C to +85˚C
3.0V ±0.3V: f
0
66.7MHz(PC/SC)
Refer to page 4."Frequency range"
Soldering condition
Frequency stability
Current consumption
Output disable current
Standby current
Duty
High output voltage
Low output voltage
Output load
condition (fan out)
Twice at under 260˚C within 10 sec.
or under 230˚C within 3 min.
B: ±50ppm C: ± 100ppm M: ±100ppm(-40˚C to +85˚C)
-20˚C to +70˚C
No load condition, Max. frequency range
OE=GND(PT,PH,PC)
ST=GND(ST,SH,SC)
C-MOS load: 1/2V
DD
level
TTL load: 1.4V level
I
OH
=-16mA(PT/ST,PH/SH),-8mA(PC/SC)
I
OL
= 16mA(PT/ST,PH/SH), 8mA(PC/SC)
45mA max.
30mA max.
50µA max.
28mA max.
16mA max.
40% to 60%
TTL
C-MOS
Output enable/disable input voltage
Output rise time
Output fall time
C-MOS level
TTL level
C-MOS level
TTL level
40% to 60%
V
DD
-0.4V min.
0.4V max.
5TTL max.
15pF max.
2.0V min.
0.7
×
V
DD
min.
0.8V max.
0.2
×
V
DD
max.
4ns max.
4ns max.
4ns max.
4ns max.
10ms max.
±5ppm/year max.
±20ppm max.
Max. frequency and max. operating voltage range
ST
, OE terminal
C-MOS load: 20
%→
80
%
V
DD
TTL load: 0.4V
2.4V
C-MOS load: 80
%→
20
%
V
DD
TTL load: 2.4V
0.4V
_
Oscillation start up time
Aging
Shock resistance
Note:
Time at minimum operating voltage to be 0 sec.
Ta= 25˚C, V
DD
= 5.0V/3.3V(PC/SC)
Three drops on a hard board from 75 cm or
excitation test with 3000G x 0.3ms x 1/2sine
wave in 3 directions
• Please contact us for inquiries about operating temperature(-40˚C to +85˚C), usable frequencies, duty and output load conditions.
Checking possible by the Frequency Checking Program.
http://www.epson.co.jp/CRYSTAL/
(Unit: mm)
NO.
Pin terminal
1 OE or ST
2
GND
3
OUT
4
V
DD
External dimensions
7.1±0.2
Recommended soldering pattern
1.8
(Unit: mm)
5.3 max.
4.6±0.2
E 125.00C
2PH 9245A
0.4
5.08
0 min.
(0.75)
(0.75)
1.5 max.
4.2
5.08
(Wired-or connection & Jitter specification, please refer to page 13.)
