H
B±0.30
A±0.25
2.00
0.90
1.00
2.00
0.90
1.00
2.00
Number of
Contacts
4
6
8
Dimensions
A
2.0
4.0
6.0
8.0
10.0
12.0
14.0
16.0
18.0
20.0
22.0
24.0
26.0
28.0
30.0
32.0
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
50.0
52.0
54.0
56.0
58.0
60.0
62.0
64.0
66.0
68.0
B
4.0
6.0
8.0
10.0
12.0
14.0
16.0
18.0
20.0
22.0
24.0
26.0
28.0
30.0
32.0
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
50.0
52.0
54.0
56.0
58.0
60.0
62.0
64.0
66.0
68.0
70.0
C
n/a
2.0
4.0
6.0
8.0
10.0
12.0
14.0
16.0
18.0
20.0
22.0
24.0
26.0
28.0
30.0
32.0
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
50.0
52.0
54.0
56.0
58.0
60.0
62.0
64.0
66.0
Ø1 .
00
Ø1 .
00
4.00
6.80
3.20
6.80
3.20
10
12
14
16
G
Ø 0.
90
0.92
(ref.)
2.00
0.45x0.15 pin
Recommended PCB Layout
Top Entry General Tolerance: ±0.05
Recommended PCB Layout
Bottom Entry
General Tolerance: ±0.05
18
20
22
24
Solder Area
Solder Area
F
0.40
(ref.)
2.80
26
0.15
28
30
2.00
1.30
E
Specifications
规格
Material
物料
Insulator
绝缘½
:
Standard
标准
: Polyamide , Nylon 6T, UL 94V-0
Option
可选
: Polyester, LCP, UL 94V-0
Contact
端子
: Copper Alloy
Plating
电镀
Contact
端子
: See Ordering Grid
C ±0.20
Ø0.80
5.80
32
34
36
38
40
42
D
Ordering Grid
44
BF080
XX
X
X
X
X
Request Samples
and Quotation
46
48
50
52
54
56
58
60
62
64
66
68
70
C
Electrical
电气
Current Rating
电流额定值
: 2 AMP
Insulation Resistance
绝缘电阻值
: 1000 MΩ min.
Contact Resistance
接触电阻值
: 20 mΩ max.
Dielectric Withstand Voltage
寒耐电压
: 500 V AC
Mechanical & Environmental
机械
&
环境
Operating Temperature
工½温度
: -40°C to +105°C
Soldering Process
可焊性
Nylon 6T (Standard
标准物料
) -
IR Reflow
回流焊
: 260°C for 10 sec.
Wave
波峰焊
:230°C for 5-10 sec.
Manual Solder
人工焊接
: 350°C for 3-5 sec
LCP (Option
可选物料
) -
IR Reflow
回流焊
: 260°C for 10 sec.
Wave
波峰焊
:250°C for 5-10 sec.
Manual Solder
人工焊接
: 350°C for 3-5 sec
No. of Contacts
04 to 70
Contact Plating
A = Gold Flash All Over
(Standard)
B = Selective Gold Flash Contact Area/
Tin On Tail
C = Tin All Over
G = 10µ" Gold Contact Area/Tin On Tail
I = 30µ" Gold Contact Area/Tin On Tail
Packing Options
C = Tape and Reel with Film
(Standard)
B = Tape and Reel with Cap
D = Tube
E = Tube with Cap
F = Tube with Film
Insulator Material
N = Nylon 6T
(Standard)
L = LCP
Locating Peg
0 = No Peg
1 = With Peg
B
Mates with
配套之母座
(Subject
to pin length
在端子长度适合的条件下
)
BF030
BF060
BF045
BF135
BF050
BF140
BF055
BF145
Part Number
Product Description
A
For bottom entry applications, stringent soldering
control & pin alignment are required as lead to pad
misalignment could cause incorrect mating.
BF080
Drawing Date
31st October 2007
By
Detail
Revision
Date
AJO
PCN
BF080-001
E1
20/07/15
Length
2.00mm Pitch Socket
Dual Row, Surface Mount, Low Profile, Bottom Entry
Tolerances
(Except as Noted)
Angle
1
2
3
4
5
X. ± 0.30
X.° ± 5°
X.X° ± 3°
X.X ± 0.20
X.XX° ± 2°
X.XX ± 0.15
X.XXX ± 0.10 X.XXX° ± 1°
Units:
Metric (mm)
C
7
3rd Angle Projection
This drawing is confidential and
copyright of Global Connector
Technology, Ltd (GCT).
This drawing must not be copied
or disclosed without written
consent. E & OE
Global Connector Technology
GC
Drawn By
LYH
www.gct.co
Not to
Scale
Sheet No.
1/1
6
8
