RL series, low resistance value chip
resistors with long-side electrodes
for high-precision current detection.
A specially designed construction assures small dimensions and repressed surface
temperature increase due to heat radiation and thermal conduction. This construction also
minimizes the thermal effects on peripheral areas. Patent 2963671
Our SMD components contribute to lead-free composition of electronics products.
SPECIFICATIONS
Mechanical
Dimension
(mm)
L
W
P
T
RL3720
(0815)
3.75
2.00
0.40
0.40
0.30
0.20
0.20
0.10
RL3720W
(0815)
3.75
2.00
0.40
0.40
0.30
0.20
0.20
0.15/ 0.10
RL7520W
(0830)
7.50
2.00
0.40
0.40
0.30
0.20
0.20
0.15/ 0.10
L
P
W
T
Equivalent circuit
Electrical
Type
Power
Resistance Tolerance
(code)
Resistance Range ( )
Temperature Coefficient
of Resistance ppm/ C(code)
Resistance Value
Package
RL3720
1/2W
1%(F)
2%(G)
0.022 0.068
0
350
(T)
0.1 2.2
0
200
(S)
0
RL3720W
1W
1%(F)
2%(G)
0.010 0.068
350
(T)
0.1 1.0
0
200
(S)
0
5%(J)
1,2,3m
800
(T)
RL7520W
2W
1%(F)
2%(G)
5,6,9m
0
420
(T)
0.010 0.068
0
350
(T)
0.1 0.47
0
E 6
4,000pcs/reel
200
(S)
E 6
E 6
•
Other resistance values are available.
PART NUMBER
RL 3720(W) T - R10 - F
Resistance Tolerance
Resistance
(1R0 1.0 , R0** less than 0.082 )
Temperature Coefficient of Resistance
Dimensions
Part Code
susumu group catalog
RL series, low resistance value chip resistors
with short-side electrodes for
high-precision current detection.
Original resistance materials assure resistance tolerance of 1% and temperature
coefficient of resistance of 100ppm/ C.
Our SMD components contribute to lead-free composition of electronics products.
SPECIFICATIONS
Mechanical
Dimension
(mm)
L
W
P
T
RL0510
(0402)
1.00
0.50
0.20
0.35
0.10
0.10
0.10
0.10
RL0816
(0603)
1.60
0.80
0.20
0.45
0.10
0.10
0.15
0.10
RL1220
(0805)
2.00
1.25
0.40
0.40
0.20
0.20
0.20
0.20
W
P
L
T
Equivalent circuit
Electrical
Type
Power
Resistance Tolerance
(code)
Resistance Range( )
Temperature Coefficient
of Resistance ppm/ C(code)
Resistance Value
Package
RL0510
1/8W
1%(F)
2%(G)
0.1 4.7
0
200
(S)
E 6
RL0816
1/8W
2%(G)
5%(J)
0.1 0.68
0
200
(S)
E 12
5,000pcs/reel
in RL1220 series are also available.
1%(F)
2%(G)
1 6.8
5%(J)
RL1220
1/4W
2%(G)
5%(J)
0.1 10.0
0
E 12
200
(S)
350
(T)
1%(F)
2%(G)
0.068 0.47
100
(R)
E 6
0.010 0.018 0.022 0.082
0
E 6
10,000pcs/reel
•
TCR of 0 to 200ppm/ C for 10 to 82 m
•
Other resistance values are available.
PART NUMBER
RL 1220 S - 1R0 - F
Resistance Tolerance
Resistance
(1R0 1.0 , R0** less than 0.082 )
Temperature Coefficient of Resistance
Dimensions
Part Code
susumu group catalog
RL series, low resistance value chip
resistors with short-side electrodes
for high-precision current detection.
Original resistance materials assure resistance tolerance of 1% and temperature
coefficient of resistance of 100ppm/ C
Our SMD components contribute to lead-free composition of electronics products.
SPECIFICATIONS
Mechanical
Dimension
(mm)
L
W
P
P
L
T
T
0.50 0.15
0.50 0.15
RL1632
(1206)
3.20 0.20
1.60 0.20
1.00 0.15
RL3264
(2512)
6.40 0.20
3.20 0.20
2.00 0.15
RL-3264-6
(2512)
NEW
6.50 0.33
3.20 0.20
2.50 0.15(1m )
1.90 0.15(2m or less)
0.80 0.15(1m )
0.70 0.15(2m )
0.60 0.15(3m or less)
W
Equivalent circuit
Electrical
Type
Power
Resistance
Tolerance(code)
Resistance Range
( )
RL1632
1/2W
2%(G)
0.01 0.018
0.015 0.022
0
1%(F)
2%(G)
0.027 0.033 0.056
0.047
4.7
0
200
(S)
2%(G)
0.01 0.018
0.015 0.022
0
RL3264
1W
1%(F)
2%(G)
0.027 0.033 0.056
0.047
0.47
350
(T)
0
200
(S)
100
(R)
5%(J)
RL-3264-6
Fixed metal foil
1W
1%(F)
5%(J)
1%(F)
5%(J)
5.1
10m
100
11
47m
50
1,2m 3,4,5m
200
100
Temperature Coefficient
0 500
of Resistance ppm/ C
(T)
(code)
Resistance Value
Package
350
(T)
100 0 500
(R)
(T)
E 24
5,000pcs/reel
E 12
5,000pcs/reel
E 24
2,000pcs/reel
PART NUMBER
RL 1632 S - R033 - F
Resistance Tolerance
Resistance
Temperature Coefficient of Resistance
Power:6(1W)
Dimensions
Part Code
RL - 3264 - 6 - R002 - F
susumu group catalog
High-precision current-detection elements
RL•L series: four-terminal type
Newly released: A four-terminal structure with separate voltage- and current-terminals
assures high-precision TCR of 50ppm/ C and 0.5% tolerance.
NEW
SPECIFICATIONS
Mechanical
L
T
Top side
W
Dimension
(mm)
L
W
T
a
b
RL1632L4
(1206)
3.2 0.2
1.6 0.2
0.5 0.15
1.0 0.2
0.55 0.2
RL2550L4
(2010)
5.0
2.5
0.5
1.7
0.9
0.2
0.2
0.15
0.2
0.2
RL3264L4
(2512)
6.4
3.2
0.5
2.1
1.2
0.2
0.2
0.15
0.2
0.2
a
b
Equivalent circuit
V
I
V
I
V=Voltage Terminal
I =Current Terminal
RL1632L4
1/2W
RL2550L4
3/4W
0.5%(D)
10 500m
Ω
50ppm/ C
10 47m
5 M or less
E-12 series
50, 500m
5,000pcs/reel
50 500m
20 M or less
1%(F)
3 5m
100ppm/ C
3 8m
1 MΩ or less
6 500m
50ppm/ C
10 47m
50 500m
5 M or less
20 M or less
E-12 series
3, 4, 5, 6, 7, 8, 50, 500m
RL3264L4
1W
back side
Electrical
Type
Power
Resistance Tolerance
(code)
Resistance Range
Temperature Coefficient of Resistance
Terminal Resistance
Resistance Value
Package
•
Contact us for even lower resistance values.
PART NUMBER
RL 1632 L4 - R033 - F
Resistance Tolerance
Current-detection resistance values
Number of terminals
Dimensions
Part Code
susumu group catalog
